ADTEK CS2-TM User Manual page 25

0049h
004Ah
004Bh
004Ch
004Dh
004Eh
004Fh
0050h
0051h
0052h
0053h
Name Address
0054h
3: Lo Hold(Low Energized Hold)
4: High Hold(High Energized Hold)
5: DO(Digital Output)
6: btCH.n(Batch with N Mode)
7: btCH.r(Batch with R Mode)
8: btCH.C(Batch with C Mode)
9: totL.n(Totalizer with N Mode)
10: totL.r(Totalizer with R Mode)
11: totL.C(Totalizer with C Mode)
0000~5000
Hysteresis of Relay 1
0000~5999
Energized Delay Time of Relay 1
(0.1second)
0000~5999
De-Energized Delay Time of Relay 1
(0.1second)
0~11 Relay 2 Energized Mode
0: oFF(no use);
1: Lo(Low Energized);
2: Hi(High Energized)
3: Lo Hold(Low Energized Hold)
4: High Hold(High Energized Hold)
5: DO(Digital Output)
6: btCH.n(Batch with N Mode)
7: btCH.r(Batch with R Mode)
8: btCH.C(Batch with C Mode)
9: totL.n(Totalizer with N Mode)
10: totL.r(Totalizer with R Mode)
11: totL.C(Totalizer with C Mode)
0000~5000
Hysteresis of Relay 2
0000~5999
Energized Delay Time of Relay 2
(0.1second)
0000~5999
De-Energized Delay Time of Relay 2
(0.1second)
0~11 Relay 3 Energized Mode
0: oFF(no use);
1: Lo(Low Energized);
2: Hi(High Energized)
3: Lo Hold(Low Energized Hold)
4: High Hold(High Energized Hold)
5: DO(Digital Output)
6: btCH.n(Batch with N Mode)
7: btCH.r(Batch with R Mode)
8: btCH.C(Batch with C Mode)
9: totL.n(Totalizer with N Mode)
10: totL.r(Totalizer with R Mode)
11: totL.C(Totalizer with C Mode)
0000~5000
Hysteresis of Relay 3
0000~5999
Energized Delay Time of Relay 3
(0.1second)
0000~5999
De-Energized Delay Time of Relay 3
(0.1second)
Range
0~11 Relay 4 Energized Mode
0: oFF(no use);
1: Lo(Low Energized);
2: Hi(High Energized)
Explain
25 / 27 CS2-TM(Pulse)-Operating Manual 2012-05-10
0 R/W
0 R/W
0 R/W
6 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
0 R/W
Initial Write/Read Note
0 R/W
