ADTEK CS2-TM User Manual page 14

Don't Care about the function
SiGn: Up & down count of Totalizer
▼ ▲
accouding to + or – of PV
100.00 Pv.SPn: Fine Span Adjustment for PV
display;
▼ ▲
Users can get Fine Adjustment by front
key of the meter, and "Just Key In" the
value which user want to show in the
current input signals.
S.CLr: Clear Fine Span Adjustment
for PV display;
▼ ▲
dSPLY: Display Function for down
screen
▼ ▲
The display can be written by RS485
command. At meantime, the display is no
longer according to the input signal. In
past, The meter normally receive
4~20mA or 0~10V from AO card or BCD
card of PLC. We support a new solution
by RS485 writing in so that can be save
cost and wiring into PLC.
Lo.CUt:Low Cut
If the setting value is positive, it means
▼ ▲
the range of absolute value will be 0; PV≤
Setting value, the display will be 0.
If the setting value is negative, it means
the range of under setting value will be 0;
PV≤ -Setting value, the display will be 0.
ito.Md:Input Time Out Mode
In the case of low frequency, the
▼ ▲
totalizer can not to identify that is low
frequency and no input until the next
pulse input. Sometimes, it takes a long
period.
CS2-TM builds in a time out function to
cut out the reading(to be "0"). There are
two modes
selected.
The page will show out, when ito.Md set
to be MAnUL.
▼ ▲
Ito: Input Time Out;
The time setting for Input time out.
Next P.
MAnAL AUto
/ can be
14 / 27
Selectable:
PStvE(Pasitive): Totalizer or
Batch will count increase
when immediate value(PV)
＞0.
dUAL(Dual): Totalizer or Batch
will count increase when
immediate value(PV)＞0.
And, Totalizer or Batch will
count decrease when
immediate value(PV)＜0.
Up Down Enter
Setting Range: -29999~+29999
Shift Up Down
Selectable:
no (No): Do not clear the fine
span adjustment.
yes(Yes): To clear the fine span
adjustment.
Up Down Enter
Selectable:
Pv(PV): Down screen shows
Immediate Value(PV)
bAtCH(Batch): Down screen
shows batch
Mini.H:Minimum Hold for
Immediate Value(PV)
MAX.H:Maximum Hold Immediate
Value(PV)
RS485(RS485): Remote display
from RS485 command of
master.
Up Down Enter
Setting Range: ±29999 counts
Shift Up Down
Selectable:
Auto: The reading will display
"0", when the next pulse
doesn't input during the
time that gave by formular
of meter's firmware.
MAnUL: The reading will display
"0", when the next pulse
doesn't input during the
setting time.
Up Down Enter
Setting Range: 0.0 sec~999.9sec
Shift Up Down
CS2-TM(Pulse)-Operating Manual 2012-05-10
