Replaceable parts
Wire feed rollers

10.1.3 Wire feed rollers for cored wire

Type
FUEL 4R 0.8 MM/0.03 INCH
WHITE/ORANGE
FUEL 4R 1.0 MM/0.04 INCH
BLUE/ORANGE
FUEL 4R 1.2 MM/0.045 INCH
RED/ORANGE
FUEL 4R 1.4 MM/0.052 INCH
GREEN/ORANGE
FUEL 4R 1.6 MM/0.06 INCH
BLACK/ORANGE
FUEL 4R 2.0 MM/0.08 INCH
GREY/ORANGE
FUEL 4R 2.4 MM/0.095 INCH
BROWN/ORANGE

10.1.4 Wire guide

Type
DV X
SET WF 1,6mm eFeed
ON SET WF 2,0-3,2mm
eFeed
SET IG 4x4 1.6mm BL
GUIDE TUBE L105
GuideTube L=102 mm, Ø 4,4
x 5 mm
CAPTUB L=107 mm; Ø ≤ 1,6
mm
CAPTUB L=105 mm; Ø ≤ 2,4
mm
56
Designation
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Drive roll set, 37 mm, 4 rolls, V-groove/knurled for
flux cored wire
Designation
Wire feed roll mount set
Wire feed set for rolls up to 1.6 mm in diameter
Wire feed set for rolls with diameters greater than
1.6 mm
Inlet guide set
Guide tube
Guide tube
Capillary tube
Capillary tube
Item no.
092-002848-00008
092-002848-00010
092-002848-00012
092-002848-00014
092-002848-00016
092-002848-00020
092-002848-00024
Item no.
092-002960-E0000
092-002774-00000
092-019404-00000
092-002780-00000
094-006051-00000
094-020064-00000
094-006634-00000
094-021470-00000
099-005613-EW501
