Nitrogen Plastic Welding
1. Push and hold the Iron Control button.
Iron
Control
2. Push and hold the Hot Air Control button.
Hot Air
Control
3. Place the rod or ribbon perpendicular
to the bumper at the beginning of the
tear as shown.
4. Pull the trigger and angle the gun so the
hot nitrogen is directed at both the bumper
and the rod or ribbon.
5. Once the rod or ribbon begins to melt into the bumper, apply a very slight downward
pressure and begin to work at a backward angle of roughly 45 directing the hot nitrogen
towards where the rod or ribbon meets the bumper.
6. At the end of the tear, use the gun nozzle to melt and tear away the rod or ribbon.
7. Return the gun to its holster and take the soldering iron out.
8. Use the soldering iron to smooth the edges of the rod or ribbon into the bumper until
there is no visible seam between the two.
9. Allow several minutes for the bumper to cool down.
10. Repeat all steps above on the front side of the tear.
11. Use a 120 grit DA sander at low speed to sand the rod or ribbon so that it is ush with the
bumper. If the plastic browns, it means your sander speed is too fast and is burning the plastic.
The LED next to the knob turns
green and the soldering iron
begins to heat up.
The LED next to the knob turns green and hot air ows out of
the gun. If the LED ashes orange, there is not enough
compressed air or nitrogen owing through the gun
.
