Step 5: Alignment of the Feet
If the fl oor is uneven, you can stabilize the equipment by turning the two setting screws under the
main frame.
1. Lift the equipment on the desired side and rotate the setting screws under the main frame.
2. Rotate the screws clockwise in order to remove them and to raise the equipment.
3. Rotate them counterclockwise in order to lower the equipment.
Step 6: Adjustment of the Seat
Height Adjustment (A-1)
⚠ CAUTION
The seat post is marked with "STOP" for the minimum insertion depth. When adjusting, make
sure not to exceed the minimum insertion depth.
1. Loosen and pull the knob (50) to adjust the height of the seat post.
⚠ CAUTION
In the following step, make sure the knob audibly engages in one of the adjustment holes.
2. Release the knob (50).
3. Retighten the knob (50).
Horizontal Adjustment (A-2)
1. Loosen and pull the knob (50) underneath the seat until it can be moved forwards and backwards.
2. Move the seat into the desired position.
⚠ CAUTION
In the following step, make sure the knob audibly engages in one of the adjustment holes.
Release the knob (50).
3. Reighten the knob (50).
Tilt Adjustment (A-3)
1. Loosen the bolt connection underneath the seat until the tilt can be adjusted.
2. Adjust the desired tilt.
3. Retighten the bolt connection.
