- Page 1 Assembly and Operating Instructions max. 220 kg ~ 60 Min. 110 kg L 126 | B 124 | H 212 TF3DSM.01.01 Art. No. TF-3DSM Taurus 3D Smith Machine...
- Page 2 3D Smith Machine...
-
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing... - Page 4 3D Smith Machine...
- Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
- Page 6 This notice indicates potentially hazardous situations which, if not avoided, will result in death or serious injuries! NOTICE This notice indicates further useful information. Retain these instructions in a safe place for future reference, maintenance or when ordering replacement parts. 3D Smith Machine...
-
Page 7: General Information
GENERAL INFORMATION Technical Data Weight and dimensions: Article weight (gross, including packaging): 130 kg Article weight (net, without packaging): 110 kg Packaging dimensions (L x W x H) approx.: 210 cm x 43 cm x 20 cm Set-up dimensions (L x W x H) approx.: 126 cm x 123.8 cm x 211.7 cm Maximum user weight: 220 kg... -
Page 8: Personal Safety
Make sure that nobody is within the range of motion of the equipment during training so as not to endanger you or other persons. ࣑ ATTENTION Do not insert any objects of any kind into the openings of the device. 3D Smith Machine... -
Page 9: Set-Up Place
Set-Up Place WARNING ⚠ Do not place the equipment in main corridors or escape routes. ⚠ CAUTION Choose a location in which to place the equipment such that there is enough free space/ clearance to the front, the rear and to the sides of the equipment. The training room should be well ventilated during training and not be exposed to any draughts. -
Page 10: Assembly
To prevent damage to the equipment and the floor, assemble the equipment on a mat or packaging board. NOTICE In order to make the assembly as simple as possible, some screws and nuts to be used can already be pre-assembled. Ideally, assemble the equipment at its later set-up place. 3D Smith Machine... -
Page 11: Scope Of Delivery
Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠... - Page 12 3D Smith Machine...
- Page 14 3D Smith Machine...
-
Page 16: Assembly
Repeat the last two steps on the other side. Name Specification Qty. reinforcing plate L shape base frame hexagon bolt M10*120 washer Φ10 lock nut slide rod fix plate right rubber cushion Φ60*Φ30*30 connection tube fix plate left allen bolt 3D Smith Machine... - Page 18 (19) on each side. guide rod safety hook right safety hook left hexagon socket screw without head barbell rod sliding sleeve barbell plate holder washer Φ12 spring gasket Φ12 hexagon socket screw M12*40 Limit column Limit nut 3D Smith Machine...
- Page 20 (27) ad one washer (4) on each side. Name Specification Qty. washer Φ10 lock nut out hexagon bolt M10*75 hexagon socket screw chip up bar out hexagon bolt M10*65 butterfly clip L shape connect plate t4.0*100*102.7 3D Smith Machine...
-
Page 22: Storage And Transport
࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 10°C and 35°C. 3D Smith Machine... -
Page 23: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner. -
Page 24: Maintenance And Inspection Calendar
The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. 3D Smith Machine... -
Page 25: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape. -
Page 26: Ordering Spare Parts
The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Multi-gym Model Name: 3D Smith Machine Article Number: TF-3DSM 3D Smith Machine... -
Page 27: Parts List
Parts List Name Specification Qty. reinforcing plate L shape base frame hexagon bolt M10*120 washer Φ10 lock nut slide rod fix plate right rubber cushion Φ60*Φ30*30 connection tube fix plate left allen bolt stand tube out hexagon bolt M10*75 rubber pad out hexagon bolt M10*70 guide rod... -
Page 28: Exploded Drawing
Exploded Drawing 3D Smith Machine... -
Page 29: Warranty
WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline. - Page 30 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. 3D Smith Machine...
-
