TO-S128

Multi-function Smith

Assembly and Operating Instructions

综合训练器

Owner's Manual

max. 150 kg

~ 240 Min.

220 kg

L 120 | W 125 | H 220

FSUKTFMS40.01.01

SKU: TF-MS40

TF-

Taurus

MS40 Pro

Table of Contents

Need help?

Do you have a question about the MS40 Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Taurus MS40 Pro

Page 1 TO-S128 Multi-function Smith Assembly and Operating Instructions 综合训练器 Owner's Manual max. 150 kg ~ 240 Min. 220 kg L 120 | W 125 | H 220 FSUKTFMS40.01.01 SKU: TF-MS40 Taurus MS40 Pro...
Page 2 MS40 Pro...
Page 3: Table Of Contents
Content GENERAL INFORMATION Technical Data Personal Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly STORAGE AND TRANSPORT General Instructions TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions Faults and Fault Diagnosis Maintenance and Inspection Calendar DISPOSAL RECOMMENDED ACCESSORIES ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing...
Page 4 MS40 Pro...
Page 5 European VAT Number: DE813211547 Disclaimer © TAURUS is a registered brand of the company Fitshop GmbH. All rights reserved. Any use of this trademark without the explicit written permission of Fitshop is prohibited. Product and manual are subject to change. Technical data can be changed without advance notice.
Page 6 (person with legal responsibility). Class H (home use): use at home. These stationary training devices are intended for the use in private homes where access to the training device is regulated by the owner (person with legal responsibility). MS40 Pro...
Page 7 Please pay close attention to the safety and maintenance instructions given here. The contract partner cannot be held liable for damage to health, accidents or damage to the equipment when it is not used in accordance with these instructions. The following safety instructions may appear in this manual: ࣑...
Page 8: General Information
120 cm x 60 cm x 220 cm Quantity of weight stacks: Total weight: 90 kg per weight stack Cable length: 1023.5 cm, 411.5 cm Cable material: Steel Cover material: Nylon Transmission ratio: Maximum user weight: Use class: MS40 Pro...
Page 9: Personal Safety
Personal Safety ⚠ DANGER Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.
Page 10: Set-Up Place
(parquet, laminate, cork, carpets) from dents and sweat and can help to level out slight unevenness. For Class S equipment, the exercise equipment may only be used in areas where access, supervision and control are specifically regulated by the owner. MS40 Pro...
Page 11: Assembly
ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.
Page 12: Scope Of Delivery
In the event of complaints, the contractual partner must be contacted directly. ⚠ CAUTION If parts of the scope of delivery are missing or damaged, the assembly must not be carried out. MS40 Pro...
Page 13 Q'TY Q'TY Q'TY 1.Upright Frame-Right 2.Upright Frame-Left 3.Down Side Link Tube 15.Leg Press 10.Middle Link Tube 17.Down Fixing Plate 80.SPring 21.Front Standing Tube-Left 18.Front Standing Tube-Right 26.Rubber Block 27.Sliding Sleeve-Right 28.Guide Rod 32.Sliding Sleeve-Left 39.Ring 36.Up Side Link Tube 35.Up Fixing Plate 33.Thread Pin 34.Chin Up Frame 43.Aluminum Cap...
Page 14 22.Sliding Frame-Right 23.Sliding Frame-Left 71.Hook 29.Rubber Block 30.Lock Sleeve 76.Carabiner And Chain 37.Up Side Link Tube-Left 38.Back Fixing Plate 40.T Shape Pin 41.Barbell Bar 47.Rubber Block 48.Selector Rod 52.Pulley Holder 53.Stainless Steel Rod 61.Rotating Pulley Holder 57.Powder Metallurgy MS40 Pro...
Page 15 Q'TY Q'TY Q'TY 60.Pulley 56.Pulley Cover 64.Weight Cable 70.Outer Shield-Left 69.Inner Shield-Left 68.Outer Shield-Right 72.Plastic Handle 73.Triceps Rope 74.Short Straight Bar 77.Ankle Cuff 78.Lat Pull-Down Bar 79.Long Straight Bar Q'TY 65.Ring Pull Pin 67.Inner Shield-Right 75.Triangle Plate...
Page 16: Assembly
(4) from above, two washers (5) from above, one axle (6), two washers (8) from below and two bolts (7) from below. MS40 Pro ASSEMBLY DRAWING 1 Fix upright frame-right-1 and down side link tube-3 use M10*20 hexagon bolt-4...
Page 17: Assembly Step
ASSEMBLY STEP 1...
Page 18 (1 & 2) using four bolts (14), four washers (13), four washers (8) and four nuts (12). ASSEMBLY DRAWING MS40 Pro ASSEMBLY DRAWING 1 Fix down back link tube-9 on main frame use M10*70 hexagon bolt-11, φ30*φ10*3 big ﬂat...
Page 19 ASSEMBLY STEP 2 DESCRIPTION NOTE Big Flat Washer φ30*φ10*3 Flat Washer φ10 Down Back Link Tube Middle Link Tube Hexagon Bolt M10*70...
Page 20 Sliding frames (22 & 23) - the adjusting units must be pushed onto both the guide rods (28) and the front standing tubes (18 & 21) Rubber block (29) Sliding sleeves (27 & 32) Lock sleeve (30) Bolt (31) DESCR Flat W Lock MS40 Pro Hexag Down Fix Front Standin Feet Internal T...
Page 21 ASSEMBLY STEP 3 DESCRIPTION NOTE Flat Washer φ10 Lock Nut Hexagon Bolt M10*75 Down Fixing Plate t Standing Tube-Right Feet Cover ternal Thread Axle φ12*59.5...
Page 22 Only now tighten the bolts firmly. Step 4：use the axle-20,bolt-24,washer-25 Step 3.2.4 fixed the feet cover on the down fixing plate Attach the feet cover (19) to the two fixing plates (17) using the axle (20), two bolts (24) and two washers (25) MS40 Pro...
Page 23 ASSEMBLY DRAWING ASSEMBLY DRAWING down ﬁxing plate-17 on main frame use M10*75 hexagon bolt-16, φ10 ﬂat washer d M10 lock nut-12.
Page 24 Fit the pull-up bar (34) to the side link tube (36) using a bolt (4), a washer (5), an axle (6) and lock ASSEMBLY DRAWING the pull-up bar (34) to the side link tube (37) using a pin (40). MS40 Pro ASSEMBLY DRAWING 1 Fix up side link tube-36 and up side link tube-left-37 on main frame use M10*20 hexagon...
Page 25 ASSEMBLY STEP 4 DESCRIPTION NOTE Hexagon Bolt M10*20 Big Flat Washer φ30*φ10*3 Internal Thread Axle φ20*85 Flat Washer φ10 Hexagon Bolt M10*70 Lock Nut Hexagon Bolt M10*75 Thread Pin...
Page 26 ASSEMBLY DRAWING ASSEMBLY DRAWING 1 Fix barbell bar-41 on sliding frame-left use M10*25 hexagon socket button head screws-7, φ MS40 Pro 10 spring washer-13 and aluminum cap-43. 2 Fix m 10*20 hexagon socket button head screw on barbell bar-41. 3 Connect barbell bar-41 and sliding frame use locking spring knob-45.
Page 27 ASSEMBLY STEP 5 DESCRIPTION NOTE...
Page 28 Attach the pulley holder (52) to the selector rod (48). Drive the pin (51) into the slot provided on the top weight plate. Insert the pin (50) into any hole in the selector rod (48). ASSEMBLY DRAWING Repeat these steps for the left-hand side. MS40 Pro ASSEMBLY DRAWING...
Page 29 ASSEMBLY STEP 6 90KG配重不用此件 DESCRIPTION NOTE Flat Washer φ10 Weight Support Tube...
Page 30 (12) and guide the cable (64) upwards and attach the end of the cable to the actuator unit using a pin (65). 12. Repeat the steps on the other side. NOTICE The cable length can be adjusted by turning the locking nut. MS40 Pro...
Page 32 MS40 Pro...
Page 33 ASSEMBLY DRAWING regulating screw ASSEMBLY DRAWING 1 As shown in ﬁgure ﬁx φ92 pulley-55 and φ75 pulley-60 on main frame use φ10 ﬂat washer- 8, M10 lock nut-12, M10*75 hexagon bolt-16, M10*45 hexagon bolt-54, pulley cover-56, φ 20*φ16*φ10.5*15 Powder metallurgy-57, M10*65 hexagon bolt-58, φ20*φ16*φ10.5*20.5 Powder metallurgy-59.
Page 34 ASSEMBLY DRAWING 1 Fix inner shield-right-67, outer shield-right-68, inner shield-left-69 and outer shield-left-70 MS40 Pro on main frame use M8*16 hexagon bolt-24 and φ8 ﬂat washer-25. 2 Fix top cover-66 on main frame use M8*16 hexagon bolt-24 and φ8 ﬂat washer-25.
Page 35 ASSEMBLY STEP 8 DESCRIPTION NOTE Hexagon Bolt M8*16 Flat Washer φ8 Top Cover...
Page 36 Hold the barbell bar firmly so that it does not fold down unsecured. Step onto one feet cover (19) at a time to operate the lever and release the stands. Fold both sides together. → The appliance is folded up. MS40 Pro...
Page 37 Accessories: ASSEMBLY DRAWING DESCRIPTION NOTE Carabiner Plastic Handle Triceps Rope Short Straight Bar Triangle Plate Carabiner And Chain Ankle Cuﬀ Lat Pull-Down Bar Long Straight Bar...
Page 38: Storage And Transport
࣑ ATTENTION Make sure that the equipment is protected from moisture, dust and dirt in the selected storage location. The storage location should be dry and well ventilated and have a constant ambient temperature between 10°C and 35°C. MS40 Pro...
Page 39: Troubleshooting, Care And Maintenance
TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. ⚠ CAUTION Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.
Page 40: Maintenance And Inspection Calendar
The materials can be recycled as per their symbols. Through the reuse, recycling of materials or other forms of recovery of old equipment, you make an important contribution to the protection of the environment. MS40 Pro...
Page 41: Recommended Accessories
RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. For training equipment like smith machines, weight benches or racks this could for example be a floor mat, which makes your fitness equipment stand more securely and also protects the floor from sweat but it could be also additional weights, handles, foot straps for leg exercises or triceps ropes.
Page 42: Ordering Spare Parts
NOTICE The serial number of your equipment is unique. It's located on a white sticker. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / multi gym Model Name: MS40 Pro SKU: TF-MS40 MS40 Pro...
Page 43: Parts List
Parts List Name Specification Qty. Upright Frame-Right Upright Frame-Left Down Side Link Tube Hexagon Bolt(Black) M10*20 Big Flat Washer φ30*φ10*3 Internal Thread Axle Φ20*85 Hexagon Socket Button Head M10*25 Screws Flat Washer(Black) φ10 Down Back Link Tube Middle Link Tube Hexagon Bolt M10*70 Lock Nut...
Page 44 10*60 Pulley Holder Stainless Steel Rod Hexagon Bolt M10*45 Pulley φ92 Pulley Cover Powder Metallurgy 20*φ16*φ10.5*15 Hexagon Bolt M10*65 Powder Metallurgy 20*φ16*φ10.5*20.5 Pulley φ75 Rotating Pulley Holder Fly-Bird Cable Carabiner Weight Cable Ring Pull Pin φ10*45 Top Cover MS40 Pro...
Page 45 Inner Shield-Right Outer Shield-Right Inner Shield-Left Outer Shield-Left Hook Plastic Handle Triceps Rope Short Straight Bar Triangle Plate Carabiner And Chain Ankle Cuff Lat Pull-Down Bar Long Straight Bar SPring...
Page 46: Exploded Drawing
Exploded Drawing MS40 Pro...
Page 47: Warranty
WARRANTY Products from Taurus® are subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
Page 48 For that reason, we also want to resolve your queries quickly and in a straightforward manner. Thus, please always keep your customer number and the serial number of the faulty equipment handy. MS40 Pro...
Page 49: Contact
CONTACT �� TECHNIK �� TEKNIK OG SERVICE �� CUSTOMER CARE POWERHOUSE �� +49 4621 4210-900 80 90 16 50 +44 141 737 2249 or �� +44 141 876 3972 �� +49 4621 4210-945 +49 4621 4210-698 �� info@fitshop.dk customercare@fitshop.co.uk ��...
Page 50 The company employs numerous sports scientists, fitness trainers and competitive athletes. Visit us also on our social media platforms or our blog! MS40 Pro...
Page 52 Taurus MS40 Pro...
