Ruijie RG-PF2920 Series Hardware Installation And Reference Manual page 7

RG-PF2920 Hardware Installation and Reference Guide
1. Front Panel
Table 1-3 Description of the Front Panel
No.
1
2
3
4
5
6
7
8
2. Rear Panel
Table 1-4 Description of the Rear Panel
No.
1
Description
Status LED
Console port
Optical port status LED
SPF+ port
LED of the 1G/2.5GBase-T Ethernet port with auto-negotiation
1G/2.5GBase-T Ethernet port with auto-negotiation
LED of the 10/100/1000Base-T Ethernet port with auto-negotiation
10/100/1000Base-T Ethernet port with auto-negotiation
Description
Power status LED
5
Product Description
