Ruijie RG-PF2920 Series Hardware Installation And Reference Manual page 10

RG-PF2920 Hardware Installation and Reference Guide
PoE Output
Maximum
Consumption
Operating
Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Fan Module
Intelligent
Temperature Control
EMC Standard
Safety Standard
Dimensions (W x D x
H)
Weight
Warning
The RG-PF2920-16GT2XS is a class-A product. In a domestic environment, this product may cause radio
interference in which case the user may be required to take adequate measures.
1.2.2 Product Appearance
The RG-PF2920-16GT2XS provides 16 x 10/100/1000M Base-T Ethernet electrical ports, 2 x SFP+ ports, 1 x
console port on the front panel, and the DC power input port on the side panel.
Not supported
Power 20 W
Installation against a wall, in a rack, or on a cable tray: 0º C to 55º C (32° F to 131° F)
at the altitude between 0 m to 1,800 m (0 ft. to 5905.51 ft.)
At the altitude between 1,800 m (5905.51 ft.) and 5,000 m (16404.2 ft.), every
time the altitude increases by 220 m (721.79 ft.), the maximum temperature
decreases by 1° C (1.8° F).
–40° C to +70° C (–40° F to +158° F)
10% to 90% RH (non-condensing)
5% to 95% RH (non-condensing)
Natural heat dissipation for fanless design
Temperature alarm and overheat protection
GB/T 9254.1
GB 4943.1
224 mm x 307.4 mm x 78.8 mm (8.82 in. x 12.10 in. x 3.10 in.) (including the cable
management bracket and mounting brackets)
2.75 kg (6.06 lbs) (including the package)
8
Product Description
