- Page 1 Ruijie RG-S6100 Series Switches S6100_RGOS 12.6(2)B1101 Release Notes Document Version: V1.1 Date: April 10, 2023 Copyright © 2023 Ruijie Networks...
- Page 2 All rights are reserved in this document and this statement. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited.
- Page 3 Preface Intended Audience This document is intended for: Network engineers Technical support and servicing engineers Network administrators Technical Support Ruijie Networks Website: https://www.ruijienetworks.com/ Technical Support Website: https://ruijienetworks.com/support Case Portal: https://caseportal.ruijienetworks.com Community: https://community.ruijienetworks.com ...
- Page 4 Release Notes Version Information Warning An alert that calls attention to important rules and information that if not understood or followed can result in data loss or equipment damage. Caution An alert that calls attention to essential information that if not understood or followed can result in function failure or performance degradation.
-
Page 5: Version Information
New arrivals of multi-GE series products are officially released. Use the show version detail command to check the version number. Ruijie#show version detail System description : Ruijie 10G Ethernet Switch(S6120-24XMG4XS4VS-UP-H) By Ruijie Networks System start time : 2023-02-10 17:42:22 System uptime : 06:22:37:54 System hardware version : 1.00... - Page 6 Release Notes Version Information Boot version : 1.4.27(Master) 1.4.27(Slave) Rboot version : 1.1.39...
- Page 7 After the version was released, the upgrade file may be released (identified by ID) because bugs were found and resolved. Release Date Upgrade File Description February 17, 2023 S6100_RGOS12.6(2)B1101_10141008_install.bin Pilot release for new RG- S6100 series multi-GE switches April 10, 2023 S6100_RGOS12.6(2)B1101_install.bin Official release for new RG-S6100 series multi-GE switches...
-
Page 8: Hardware Support
Release Notes Hardware Support Hardware Support Note The hardware version number is rounded to the first decimal place. The numeral in the second decimal place does not affect software version support. Hardware Type Hardware Model Version Number Chassis S6120-24XMG4XS4VS-UP-H Chassis S6120-48XMG4VS2QXS-UP-H Chassis S6110-24MG4VS-UP... -
Page 9: Resolved Issues
Release Notes Resolved Issues Resolved Issues Notice For details about the preceding bugs, see Warning Notice. - Page 10 Bug ID 881776 Description On Ruijie Cloud, the port rate options of a 25 Gbps port include 1000 Mbps. However, the actual 25 Gbps port on the switch does not support the 1000 Mbps port rate. When the port rate of a 25 Gbps port on Ruijie Cloud is configured as 10Gbps/25G Gbps, a succes message will be displayed on the Ruijie Cloud, but the configruation does not take effect on the switch.
- Page 11 Release Notes Remaining Issues 2. If the packets contain different Layer 2 source and destination MAC addresses or different Layer 3 source and destination IP addresses, the packets will be forwarded by two HG ports and the maximum forwarding bandwidth is 50 Gbps. 3.
- Page 12 Remaining Issues Failure location: Run the show int trans command to display the module with I/O failure on interfaces. Ruijie#show int tf0/49 trans Interface TFGigabitEthernet 0/49 : transceiver info I/O error! Auxiliary failure location method: If you find that the CPU usage is high and its process ID is dfd_core, gdp_power, gdp_fan, unit0_thread, unit1_thread, or fe.ptm.sw, you can use the preceding...
- Page 13 S6100_RGOS12.6(2)B13 Pilot release for new arrivals of 08_install.bin 02_install.bin RG-S6100 series multi-GE switches S6100_RGOS12.6(2)B1101_install.b S6100_RGOS12.6(2)B11 Official release for new arrivals 01_10141008_install.bin of RG-S6100 series multi-GE switches Hardware Support Change Hardware Type Hardware Model Version Number Chassis S6120-24XMG4XS4VS-UP-H Chassis S6120-48XMG4VS2QXS-UP-H Chassis...
-
Page 14: Related Documentation
Release Notes Related Documentation Related Documentation Note You can download the following free documents from the official website of Ruijie Networks https://www.ruijienetworks.com/. File name Description This manual introduces S6100_RGOS12.6(2)B1101 version, Ruijie RG-S6100 Series Switches Release including: version information, hardware support, feature Notes, RGOS 12.6(2)B1101... - Page 15 (1) Run the CLI command on the PC configured with IP address x.x.x.x (The device is connected to the PC through the MGMT port. The following bin file name is just an example.): Ruijie#upgrade download oob_tftp://x.x.x.x/ S6100_RGOS12.6(2)B1101_install.bin *May 14 10:32:20: %UPGRADE-6-INFO: Copy to /data/upgrade_rep/ *May 14 10:32:20: %UPGRADE-6-INFO: Please wait for a moment..
- Page 16 Release Notes Upgrade Instructions Ruijie#reload Reload system?(Y/N)y Ruijie#*May 14 12:51:02: %DP-3-RESET_DEV: Reset device 1 due to SYSMON/4215/CONSOLE/reset system by reload command. *May 14 12:51:02: %DP-3-MACHINE_RESTART: MACHINE_RESTART. [504172.116141] %SYS-0-REBOOT: Rebooting by job: dp_mom_thread/4265 [504172.126545] reboot: Restartin U-Boot 1.4.14-gc4283be (Mar 21 2020 - 21:56:04 +0800)
- Page 17 8.2.2 Upgrade with a USB Flash Disk (1) Run the upgrade usb0:/xxx.bin command on the CLI. R Ruijie#upgrade usb0:/ S6100_RGOS12.6(2)B1101_10141008_install.bin < The terminal is locked by upgrade module > Upgrade start !!!Running this command may take some time, please wait.
- Page 18 “success” is displayed. (2) Restart the device to validate the BIN file. Ruijie#reload Reload system?(Y/N)y Ruijie#*May 14 12:51:02: %DP-3-RESET_DEV: Reset device 1 due to SYSMON/4215/CONSOLE/reset system by reload command. *May 14 12:51:02: %DP-3-MACHINE_RESTART: MACHINE_RESTART. [504172.116141] %SYS-0-REBOOT: Rebooting by job: dp_mom_thread/4265 [504172.126545] reboot: Restartin...
- Page 19 Press RETURN to get started (3) Run the show version detail command on the CLI to confirm the upgrade success. Ruijie#show version detail System description : Ruijie 10G Ethernet Switch(S6120-24XMG4XS4VS-UP-H) By Ruijie Networks System start time : 2023-02-10 17:42:22 System uptime : 06:22:37:54 System hardware version : 1.00...
- Page 20 Release Notes Upgrade Instructions SF: Detected mx25l25635f with page size 256 Bytes, erase size 64 KiB, total 32 32 MiBMMC: Only Support 3.3 voltage sdhci@30400000: 0 Loading Environment from SPI Flash... OK Boot: Master Net: eth0: ethernet@33410000 Press Ctrl+B to enter Boot Menu, Press Ctrl+C to enter Rboot 0 During the reboot, press Ctrl+C immediately when the following message is displayed to ask you to access the Rboot interface.
- Page 21 Release Notes Upgrade Instructions 3. Burn the total FlashROM by this downloaded file. ************************************************ Press a key to run the command: enter the Local IP:[]: Under the address configuration menu, enter the switch IP address, PC IP address, and BIN file name. ************************************************ Press a key to run the command: enter the Local IP:[]:192.12.1.1...
- Page 22 Press RETURN to get started (2) Run the show version detail command on the CLI to check whether the upgrade is successful. Ruijie#show version detail System description : Ruijie 10G Ethernet Switch(S6120-24XMG4XS4VS-UP-H) By Ruijie Networks System start time : 2023-02-10 17:42:22...
- Page 23 : MACC41N000027 Precautions During the upgrade, pay attention to the prompts. If failures occur, please save the log and contact Ruijie Networks technical support. During the upgrade, the message that restart is not allowed will be displayed. You are advised not to power off the device, reset the system, or plug in/unplug any module if the related prompts are displayed.
