RG-PF2920 Hardware Installation and Reference Guide
Ethernet electrical port
LED
SFP+ port LED
Solid green
Solid yellow
Solid red
Off
Solid green
1–16
Blinking green
Off
Solid green
Blinking green
XS1-XS2
Solid red
Solid yellow
11
The switch works properly.
A switch temperature alarm is generated.
Check the operating environment of the
switch.
The temperature exceeds the threshold,
causing the system to restart.
The port is not connected.
The port works at the rate of 10/100/1000
Mbps.
The port is sending or receiving data at the
rate of 10/100/1000 Mbps.
The port is not connected.
The port is connected at the rate of 10
Gbps.
The port is sending or receiving data at the
rate of 10 Gbps.
An error occurs when the optical module
sends signals.
An error occurs when the optical module
receives signals.
Product Description
