Sensor Information - SIGNIFY GARDCO OptiForm Solar Manual

Solar Solution
1
4
DETAIL DESCRIPTION
Sensor Height:
Sensors mounted above 20' to 25' will have reduced detection at the perimeter of the coverage area. Elevating the sensor
higher reduces the diameter of the coverage area. Mounting the sensor lower than 20' also reduces the diameter of the
coverage area.
Terrain:
The terrain within the detection area of the sensor affects the detection and coverage area. If the terrain slopes down
away from the sensor, the detection withing the depressed area will be reduced. If the terrain slopes up away from the
sensor, the coverage area will be reduced in size.
Moving objects such as tree branches within the coverage area can produce false triggering of the sensor.
Air vents such as heat pumps and air conditioning units within or near the coverage area can produce false triggering of the
sensor.
page www.lumec.com
Installation Instructions
Power supply of the system
1. Open the door and secure it with the safety arm.
2. Turn the switch to ''ON'' to turn on the system
3. Verify that the system is operational and that the light
turns on.
4. Once on the ground, check BLE connectivity and validate
configurations using the app on your smartphone.

Sensor Information

Installation:
When included, the optional sensor is provided pre-wired and
installed in the luminaire.
Settings and Adjustments:
There are no settings or adjustments to make.
Ambient temperature :
The temperature of the surrounding air in the coverage area will
affect the sensor detection (sensitivity to detect motion). Hot air
temperatures (above 89°F) will reduce the detection of the
sensor and may require larger movement for detection. Cold air
temperatures (below 39° F) will increase the detection of the
sensor.
