Installation Instructions
SOOW
CABLE
of
the
above
POLE
POLE
SOOW
Pole Assembly
1.
Lay the pole flat on the ground without damaging it.
2.
Pass the SOOW cable through the top of the pole and
bring it out through the hole provided on the pole.
IMPORTANT: Do not install the arm and/or luminaire before
lifting the pole into place. This could damage the arm/luminaire
and could also be dangerous for the user.
3.
Refer to the installation instructions provided with the
pole.
4.
Carefully install the pole on the foundation bolts. Screw
the nuts so that whole thing is snug.
