White Dual Vertical Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012TW
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012t
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012TW
Summary of Contents for Vivo STAND-V012TW
- Page 1 White Dual Vertical Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V012TW Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012t GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) PER ARM Phillips Drill Screwdriver ASSEMBLY STEPS ASSEMBLE POLE SET Thread the Pole Set (A) together as shown below. STEP 1 Option A: Desk Clamp Install Install the clamp brace (C) to the pole (A) using x3 M5x14 bolts (F). - Page 4 STEP 1 (Continued) Option B: Grommet Install If desk does not have an existing grommet hole, drill a 3/8” (10mm) diameter hole at the desired position through the mounting surface. Completely disassemble clamp (B) into individual parts. Set knob (B1) and clamp plate (B2) aside for later use.
- Page 5 STEP 3 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor Attach the VESA plates (E) to the monitors with Attach the VESA plates (E) to the monitors with M4x12 thumb bolts (N). M4x30 bolts (O) and M4 spacers (P). NOTE: Hand tighten screws to avoid stripping NOTE: Gently tighten with a screwdriver.
- Page 6 STEP 5 Tighten the bolt on the side of the tilt joint with the 5mm Allen wrench (M) to fix the tilt angle. Adjust the swivel joints by tightening or loosening the top bolts using the 5mm Allen wrench (M).
- Page 7 STEP 6 Manage cables and store Allen wrenches (M) in wire clip (L1) for future use.
- Page 8 - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
