Dual Monitor Extra Tall Desk Stand
Instruction Manual
SKU: STAND-V012F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012f
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012F
Summary of Contents for Vivo STAND-V012F
- Page 1 Dual Monitor Extra Tall Desk Stand Instruction Manual SKU: STAND-V012F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012f GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) PER ARM Phillips Screwdriver ASSEMBLY STEPS STEP 1 Thread Bottom Pole (A), Middle Pole (B), and Top Pole (C) together as shown below. STEP 2 Assemble Bottom Pole (A) to Base (D) using M5x14mm Screws (S-A) and 3mm Allen Wrench (T-A).
- Page 4 STEP 3 Slide Pole Cable Clips (G) and Arm (E) onto the pole assembly. Secure Arm (E) using 6mm Allen Wrench (T-C). Assemble Arm Cable Clips (H) to Arm (E). STEP 4 (Option A) Flat Back Monitor Assemble VESA Plates (F) to the monitors using M4x12mm Thumbscrews (M-A). NOTE: Hand tighten screws to avoid stripping the plastic screw heads.
- Page 5 STEP 4 (Option B) Curved Back Monitor Assemble VESA Plates (F) to the monitors using M4 Spacers (M-C) and M4x30mm Screws (M-B). Tighten with a Phillips screwdriver. STEP 5 Slide VESA Plates (F) with the monitors onto Arm (E). Secure the monitors in place using Security Nuts (S-B).
- Page 6 STEP 6 Adjust the tilt using 5mm Allen Wrench (T-B). To level the monitors, remove Security Nut (S-B) and turn the adjustment screw with the 3mm Allen Wrench (T-A) to raise or lower the monitor. Adjustment Screw...
- Page 7 STEP 7 Manage cables using Arm Cable Clips (H) and Pole Cable Clips (G). Store Allen wrenches in Pole Cable Clip (G) for future adjustments.
