Dual Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012
Summary of Contents for Vivo STAND-V012
- Page 1 Dual Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V012 Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED 22 lbs DO NOT EXCEED WEIGHT CAPACITY. Per Arm Failure to do so may result in serious injury. (10 kg) Phillips Screwdriver ASSEMBLY STEPS ASSEMBLE POLE SET 1.Remove the grub screws with provid- ed Allen wrench (O). 2.Connect the poles (A) by threads. 3.Install the previously removed grub screws and fasten them with the Allen wrench (M).
- Page 4 STEP 1 (Continued) Option B: Grommet Install If desk does not have an existing grommet hole, drill a 3/8” (10mm) diameter hole at the desired position through the mounting surface. Completely disassemble clamp (B) into individual parts. Set knob (B1) and clamp plate (B2) aside for later use.
- Page 5 STEP 3 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor Attach the VESA plate (E) to the monitor with Attach the VESA plate (E) to the monitor with M4x12 thumb bolts (N). M4x30 bolts (O) and M4 spacers (P). NOTE: Hand tighten screws to avoid over NOTE: Gently tighten using a screwdriver tightening.
- Page 6 STEP 5 Tighten the bolt with the supplied Allen wrench (M) to fix the tilt angle. To level the monitors, remove the nut (H) and turn the bolt with the Allen key (M) to raise or lower the monitor. Replace nut (H) after the adjustment.
- Page 7 STEP 6 Use the supplied Allen key set (M) to make any necessary adjustments. Manage cables and store Allen keys (M) in wire clip (L1) for future use.
- Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
