Dual Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012/W
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012/W
Summary of Contents for Vivo STAND-V012/W
- Page 1 Dual Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V012/W Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012 GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual. -
Page 3: Tools Needed
TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs (10 kg) Failure to do so may result in serious injury. Per Arm Phillips Screwdriver ASSEMBLY STEPS STEP 1 Fully loosen the knob on Clamp (D). STEP 2: Option A - Desk Clamp Connect Clamp (D) to Lower Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). - Page 4 STEP 2: Option B - Grommet Using a phillips screwdriver, remove the screw from Clamp (D) and disassemble. Set Knob (D1) aside. Connect Grommet Plate (H) to Bottom Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Remove adhesive backing from Soft Pad (I) and adhere to Grommet Plate (H). Lower Pole (A) &...
- Page 5 STEP 3 Install Middle Pole (B) and Top Pole (C) to Bottom Pole (A). Slide Pole Cable Clips (L) and Arm (E) onto assembled pole and tighten with 6mm Allen Wrench (T-C). Insert Pole Cap (G) into Top Pole (C). Attach Arm Cable Clips (K) to Arm (E).
- Page 6 STEP 5 Place VESA Plates (F) with monitors on Arm (E) and secure with M6 Security Nuts (S-B). STEP 6 Use Pole Cable Clips (L) and Arm Cable Clips (K) to manage cables as needed.
- Page 7 STEP 7 Adjust the monitor tilt using 5mm Allen Wrench (T-B). Adjust as desired. To level the monitors with each other, remove M6 Security Nut (S-B) and use 3mm Allen Wrench (T-A) to loosen security screw. Adjust as desired. Replace M6 Security Nut (S-B).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
