Single Monitor and Laptop Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012C
Summary of Contents for Vivo STAND-V012C
- Page 1 Single Monitor and Laptop Extra Tall Desk Mount Instruction Manual SKU: STAND-V012C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22lbs Failure to do so may result in serious injury. (9.98kg) Phillips Drill Wrench Screwdriver ASSEMBLY STEPS PRE-ASSEMBLY 1.Remove the grub screws with provid- ed Allen wrench (O). 2.Connect the poles (A) by threads. 3.Install the previously removed grub screws and fasten them with the Allen wrench (M).
- Page 4 STEP 1 (Continued) Option B: Grommet Install If desk does not have an existing grommet hole, drill a 3/8” (10mm) diameter hole at the desired position through the mounting surface. Completely disassemble clamp (B) into individual parts. Set knob (B1) and clamp plate (B2) aside for later use.
- Page 5 STEP 3 FOR LAPTOP Attach VESA plate (E) to laptop tray (Q) using bolts (R) and M4 nuts (S). FOR FLAT BACK MONITOR Attach VESA plate (E) to the monitor using thumb bolts (N). NOTE: Hand tighten screws to avoid over tightening.
- Page 6 STEP 4 Slide the monitor and laptop tray onto the head of Swivel Arm (D) as shown in the diagram. Install the security Nut (H). Make sure the security nut is installed before you rotate the monitor.
- Page 7 STEP 5 Tighten the bolt with the supplied Allen Key (M) to fix the tilt angle. Use the supplied Allen Key (M) to make the necessary adjustments Adjust as Desired...
- Page 8 - 92% within < 3hr www.vivo-us.com AVG. RESOLUTION TIME : < 15 M (within office hrs) Chat live with an agent! 309-278-5303 AVG. RESOLUTION TIME : 5M 4S (within office hrs) FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
