Single Monitor and Laptop Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012C
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012c
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Vivo STAND-V012C
Summary of Contents for Vivo STAND-V012C
- Page 1 Single Monitor and Laptop Extra Tall Desk Mount Instruction Manual SKU: STAND-V012C Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012c GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22lbs Failure to do so may result in serious injury. (9.98kg) Phillips Drill Screwdriver ASSEMBLY STEPS PRE-ASSEMBLY Remove the grub screws by provided Allen Key (o). Connect the poles by threads as below diagram. Install the grub screws and fasten them by provided Allen Key (o).
- Page 4 STEP 1 (Continued) OPTION B: Existing Grommet Base Installation If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before installing the desk mount. Install the Grommet Base Plate (m) to the Pole (a) using 3pcs M5x14 Bolts (f), and tighten using the Allen Key (o), see Figure 4.
- Page 5 STEP 2 Install Swivel Arms (d) to the Pole (a). Fasten the bolt with supplied Allen Key (o). Attach the Wire Clip (n1, n2) to the pole (a) and Swivel Arms (d). STEP 3 FOR LAPTOP Attach VESA plate (e) to laptop tray (t) using bolts (u) and M4 nuts (v).
- Page 6 STEP 3 (continued) FOR CURVED BACK MONITOR Attach VESA plate (e) to the monitor using bolts (r) and spacers (s). STEP 4 Slide the monitor onto the head of Swivel Arm (d) as shown in the diagram. Install the security Nut (h).
- Page 7 STEP 5 Tighten the bolt with the supplied Allen Key (o) to fix the tilt angle. Use the supplied Allen Key (o) to make the necessary adjustments Adjust as Desired...
