Pneumatic Arm Dual Monitor Extra Tall Desk Mount
Instruction Manual
SKU: STAND-V012K
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012k
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo STAND-V012K
Summary of Contents for Vivo STAND-V012K
- Page 1 Pneumatic Arm Dual Monitor Extra Tall Desk Mount Instruction Manual SKU: STAND-V012K Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012k GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
- Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 2.2-19.8lbs Failure to do so may result in serious injury. (1-9kg) PER MONITOR Phillips Screwdriver ASSEMBLY STEPS STEP 1 Insert Pole Cap (F) into the top of Top Pole (D). STEP 2 Loosen the screws and disassemble the Clamp (B) and seperate into Clamp Brace (B1) and Clamp (B2) using 4mm Allen Wrench (T-B).
- Page 4 STEP 3 OPTION B: Grommet Installation OPTION A: Clamp Installation For grommet hole attachment only, cut Soft Pad (M) Attach Clamp Brace (B1) to Bottom Pole (E) along the indentations. Peel the protective film off using the M6x16 Screws (S-B) and the 4mm of Soft Pad (M) and place the pieces onto Grommet Allen Wrench (T-B).
- Page 5 STEP 4 Slide Cable Clip (H) and Arm (A) onto Bottom Pole (E). Tighten Arm (A) using 6mm Allen Wrench (T-C). STEP 5 Attach Top Pole (D) to Bottom Pole (E) using Pole Connector (G). Once poles are fully threaded on, tighten set screws on Pole Connector (G) using 3mm Allen Wrench (T-A).
- Page 6 STEP 7 Slide VESA Plates (C) with monitors over the brackets on Arms (A). Secure using M6x10 Thumbscrews (S-A). STEP 8 Adjust gas spring support in Arms (A) using 6mm Allen wrench (T-C). Turning counter-clockwise increases support, and clockwise decreases. STEP 9 Remove cable management covers from underneath Arms (A).
- Page 7 STEP 9 (Continued) Manage cables by reattching the cable management covers to Arm (A) and Cable Clips (H). STEP 10 Adjust tilt support using 6mm Allen Wrench (T-C).
- Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
