Dual Monitor Extra Tall Desk Stand
Instruction Manual
SKU: STAND-V012F
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012f
help@vivo-us.com
www.vivo-us.com
1-800-371-5654

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STAND-V012F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-V012F

  • Page 1 Dual Monitor Extra Tall Desk Stand Instruction Manual SKU: STAND-V012F Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012f help@vivo-us.com www.vivo-us.com 1-800-371-5654...
  • Page 2 WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3 TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs Failure to do so may result in serious injury. (10 kg) PER ARM Phillips Drill Screwdriver ASSEMBLY STEPS STEP 1 Remove the grub screws from poles (a) using the small Allen Key (m). Connect the poles by threads. Install grub screws and fasten them by provided Allen Key (m).
  • Page 4 STEP 2 (Continued) OPTION B: Grommet Base Installation If the existing grommet hole comes with a plastic protector, remove it to ensure a flat surface before installing the desk mount. Install the Grommet Base Plate (k) to the Pole (a) using 3pcs M5x14 Bolts (e), and tighten using the Allen Key (m), see Figure 3.
  • Page 5 STEP 3 Install Swivel Arm (c) to the Pole (a). Fasten the bolt with supplied Allen Key (m). Attach the Wire Clip (l1,l2) to the Pole (a) and Swivel Arm (c). STEP 4 OPTION A: Flat Back Monitor OPTION B: Curved Back Monitor Attach VESA Plate (d) to back of monitor using Attach VESA Plate (d) to back of monitor using bolts (o).
  • Page 6 STEP 6 Tighten the bolt with the supplied Allen Key (m) to fix the tilt angle. If one monitor is lower, remove the Nut (f) and turn the bolt counter-clockwise with the Allen Key (m) to raise the monitor. Replace Nut (f) after the adjustment.
  • Page 7 STEP 7 Use the supplied Allen Key (m) to make any necessary adjustments. Manage the wires and store the Allen keys (m) in the Wire Clip (l1) for future use.
  • Page 8 Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
