Dual Monitor Desk Mount with Laptop Holder
Instruction Manual
SKU: STAND-V012J
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/stand-v012j
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303

Advertisement

loading
Need help?

Need help?

Do you have a question about the STAND-V012J and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vivo STAND-V012J

  • Page 1 Dual Monitor Desk Mount with Laptop Holder Instruction Manual SKU: STAND-V012J Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/stand-v012j GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
  • Page 2: Package Contents

    WARNING! If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
  • Page 3: Tools Needed

    TOOLS NEEDED DO NOT EXCEED WEIGHT CAPACITY. 22 lbs 11 lbs (10kg) (5kg) Phillips Failure to do so may result in serious injury. Screwdriver Per Arm Laptop Tray ASSEMBLY STEPS STEP 1 Loosen knob on Clamp (C). STEP 2 (Option A) Clamp Installation Mount Clamp (C) to Bottom Pole (A) using M6x16mm Screws (S-A) 3mm Allen Wrench (T-A).
  • Page 4 STEP 2 (Option B) Grommet Installation Using a phillips screwdriver, remove the screw from Clamp (C) and disassemble. Set Knob (C2) aside. Mount Grommet Plate (H) to Bottom Pole (A) using M6x16mm Screws (S-A) and 3mm Allen Wrench (T-A). Remove adhesive backing from Soft Pad (I) and adhere to Grommet Plate (H).
  • Page 5 STEP 3 Slide Pole Cable Clip (K) and Single Arm (E) onto Bottom Pole (A). Secure Single Arm (E) in place using 6mm Allen Wrench (T-C). Thread Top Pole (B) onto Bottom Pole (A). Slide Dual Arm (D) onto Top Pole (B). Secure Dual Arm (E) in place using 6mm Allen Wrench (T-C). Attach Pole Cap (H) to Top Pole (B).
  • Page 6 STEP 4 Attach Arm Cable Clips (L) to Dual Arm (D) and single Arm (E). STEP 5 Assemble Laptop Tray (F) to VESA Plate (G) using M4x8mm Screws (S-A) an M4 Nuts (S-B). Tighten the assembly using Wrench (T-D) and a Phillips screwdriver.
  • Page 7 STEP 6 Slide Tray (F) with VESA Plate (G) onto Single Arm (E). Secure VESA Plate (G) in place using M6 Security Nut (S-B).
  • Page 8 STEP 7 Secure VESA Plates (G) to monitors using M4x12mm Thumbscrews (M-A) or M4x30mm Screws (M-B). M6 Spacers (M-C) may be required.
  • Page 9 STEP 8 Slide monitors with VESA Plates (G) onto Dual Arm (D). Secure VESA Plates (G) in place using M6 Security Nuts (S-B).
  • Page 10 STEP 9 Manage cable using Pole Cable clip (K) and Arm Cable Clip (L).
  • Page 11 STEP 10 Adjust the monitor tilt using 5mm Allen Wrench (T-B). To level monitors, remove M6 Security Nuts (S-B) and tighten or loosen adjustment screws using 3mm Allen Wrench (T-A). Once level, fasten M6 Security Nuts (S-B) back into place.
  • Page 12 LAST UPDATED: 03/03/2023 Love your new VIVO setup and want to share? REV1 Tag us in your photo! @vivo_us Open Monday - Friday 7:00am - 7:00pm CST, our dedicated support team can offer immediate assistance with rapid response times. If any parts are received damaged or defective, please contact us.
