WALLBOX
Assembly manual
Enelion sp. z o.o.
support@enelion.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WALLBOX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Enelion WALLBOX

Summary of Contents for Enelion WALLBOX

  • Page 1 WALLBOX Assembly manual Enelion sp. z o.o. support@enelion.com...
  • Page 2 Copyright Enelion sp. z o.o. The manual may change as the product develops. All rights reserved. Document version: V 6. Number of pages: 24. Release date: 18.01.2024...

  • Page 3: Table Of Contents

    1. Important information. 1.1. General provisions 1.2. Safety Guidelines 2. General informations 2.1. Opening and closing ENELION WALLBOX 3. Design indications of the installation 3.1. Power Supply Network Systems 3.2. RCD B with automatic reclosing device 3.3. Recommended power connection 3.4.
  • Page 4 Enelion Wallbox - Assembly manual 01 - 2024 Congratulations on the purchase of the ENELION charger and thank you for your trust. Before the installation, make sure that the module packages contain all the elements. Current version of the operation manual can be accessed at: https://enelion.com/en/support/...

  • Page 5: Important Information

    1.1. General provisions It is prohibited to use a charger that is mechanically The ENELION charger (here in after referred to as the damaged or indicates a critical error. device, charger, or charging terminal) is a charging station designed for electric vehicle charging within Objects not intended for this purpose must not be the meaning of the ‘Act on Electromobility and Alter-...

  • Page 6: Safety Guidelines

    Enelion Wallbox - Assembly manual 01 - 2024 1.2. Safety Guidelines Do not carry out external installation during atmos- pheric precipitation or strong winds if there is a risk of water or contaminants entering the device. All actions described in this manual should be per- formed after ensuring that there is no voltage in the power cable.

  • Page 7: General Informations

    The 3 mm Allen key is needed to open (or close) device using the included RFID card. The ENELION the ENELION WALLBOX. No other tool is neces- WALLBOX is available in two colors: black and silver. sary for this operation.. INFO Closing of the device is performed by repeating the steps in the reverse order.
  • Page 8 Enelion Wallbox - Assembly manual 01 - 2024 Holding the socket housing, pull the bottom edge of the panel until it is released from the housing and tilted slightly. Turn the key counterclockwise until the locking pin is aligned with the side of the charger. Re- move the Allen key from the hole.
  • Page 9 Enelion WALLBOX - Assembly manual 01 - 2024 The front panel may freely rest next to the ho- using, hanging within the reach of the socket connection wires. Fig. 9: The device open with the access to its interior. INFO The panel is fitted into place by following the above operations in the reverse order.

  • Page 10: Design Indications Of The Installation

    In the TN-C system configuration, you should sepa- rate the PEN conductor into N and PE as shown in the diagram below. ENELION charging stations are designed for five-wire TN-C power supply. In a TN-S 230/400V network, this is the Generator or transformer standard option.

  • Page 11: Rcd B With Automatic Reclosing Device

    Enelion WALLBOX - Assembly manual 01 - 2024 IT 120/230V Generator or transformer Phase-Phase 230 V Phase-PE 120 V High Z L1 L2 L3 N PE EVSE Grounding Grounding It is not possible to power the station from an IT 230/400 V network.

  • Page 12: Recommended Power Connection

    When purchasing an ENELION station with a differential current switch with an automatic reclosing device, the automatic reclosing device will be set to auto mode.”...

  • Page 13: Recommended Communication Network

    (RCDA30 mA/40 A) in the switchboard with the Ethernet CAT 5 or CAT6cable. application of ENELION RCM B – type B Residual For installation, leave about 50 cm of communication Current Monitor, attached to the charging termi- cables from the expected installation position.

  • Page 14: Assembly

    4.2. Selection of bolts and anchors ENELION WALLBOX DUO POWER is mounted on vertical sur-face using bolts. The device has four mounting open-ings. Additionally, the device is equipped with holds fa-cilitating the assembly.

  • Page 15: Cable Routes

    The opening diameter for the communication cable gland is 19 mm. Fig. 16: Additional plug witha nut provided with the product. Fig. 14: Locations of cable entry points in ENELION Fig. 17: Mounting place for the additional plug. WALLBOX. Assembly...

  • Page 16: Mounting The Device

    Enelion Wallbox - Assembly manual 01 - 2024 Open the device as described in section 2.1 Ope- ning and closing ENELION WALLBOX. Put the device in the target position by threading the power cable through the glands. Fasten the device with screws usinga screw-dri- ver with a shaft length of at least 150 mm.

  • Page 17: Connection

    MID meter. 5.1. Power connection ENELION WALLBOX comes in various types. Depending on which type is being installed, the power supply cables may be connected Fig. 19: Diagram of connection variants 1./2.

  • Page 18: Standard Power Connection

    Enelion Wallbox - Assembly manual 01 - 2024 Fig. 20: Diagram of connection variants 2./2. 5.1.1. Standard power connection Prepare the power supply cable.. Remove 200 mm of the main insulation off the power supply cable. Terminate the individual wires of the cable with fork (M4 or M5 size) or sleeve terminals.

  • Page 19: Power Connection In Version With Mid Meter

    01 - 2024 WSKAZÓWKA The colors of the phase wires in the ENELION WALLBOX may not correspond to the colors of the power supply wires while following the guidelines on the ENELION WALLBOX label. This is a nor- mal and expected situation when using the phase rotation feature.

  • Page 20: Rcmb Connection

    PilotBox board. [Fig. 26] 5.2. ENELION Chain The ENELION Chain network is based on a serial, wired CAN bus. For installation, it is recommended to use a CAT5e or better network cable with copper wires, not CCA (Copper Clad Aluminium). Communication utilizes a single twisted pair of wires along with the cable shield.
  • Page 21 Enelion WALLBOX - Assembly manual 01 - 2024 Prepare communication cables (a) For devices at the beginning of the network, select a pair of communication cables. (b) For devices along the network, prepare the cables entering the device by connecting the...
  • Page 22 Enelion Wallbox - Assembly manual 01 - 2024 Connection...

  • Page 23: Internet Connections Via Ethernet Interface In Lan Network

    (variant B) 5.3. Internet connections via Ethernet in- terface in LAN network To provide the Internet connection to a charger equipped with ENELION Bridge module via Ethernet interface: Fig. 33: Termination diagram. Insert the Ethernet cable into the device through the gland for communication cables.

  • Page 24: Maintenance

    Enelion Wallbox - Assembly manual 01 - 2024 6. Maintenance The device is designed to operate in temperatures from -25 C to 55 C. The manufacturer does not guarantee the proper functioning of the charging station in tem- peratures outside the specified range. Chargers that...

  • Page 25: Technical Data

    Enelion WALLBOX - Assembly manual 01 - 2024 7. Technical data 7.1. ENELION WALLBOX Electrical data Routing of the power cord Surface mounted Surface mounted Recommended minimum cross-section) Power cord cross-section 5 x 6,0 mm2 (32 A nominal current) Supply voltage (Europe)
  • Page 26 © 2023 ENELION Pana Tadeusza 50, 80123 Gdańsk, Poland...
