  • Page 1 Wallbox Duo Power Assembly manual Enelion Sp. z o.o. info@enelion.com...
  • Page 2 Copyright, Enelion Sp. z o. o. The manual may change as the product develops. The information provided may not be correct. All rights reserved. Revision: V 3.2 Number of pages: 22 Released: March 2, 2021...
  • Page 3: Table Of Contents

    7.1 Enelion Wallbox Duo Power ........
  • Page 4 Wallbox Duo Power - Assembly manual 3 - 2021 Before the installation, make sure that the module packages contain all the elements. Current version of the operation manual can be accessed at http://enelion.com/en/help/. See the contents of the manual before initiating any activities related to the installation or the activation of the charger.
  • Page 5: Important Information

    Wallbox Duo Power - Assembly manual 3 - 2021 1. Important information 1.1. General Provisions It is forbidden to use any extensions of the charging ca- ble. Installation and servicing of the device must be per- The manufacturer is not responsible for loss of health formed by qualified and authorized persons, and re-...
  • Page 6: General Information

    Wallbox Duo Power - Assembly manual 3 - 2021 2. General information Wallbox Duo Power is a charging station intended for INFO electric road and passenger vehicles. It is made of an aluminum casing, closed at its sides with reinforced For more information, see the “User Guide”.
  • Page 7 Wallbox Duo Power - Assembly manual 3 - 2021 2. Insert the supplied Allen key into the exposed hole. The key should be inserted until resistance is felt, i.e. until it cannot be pushed deeper. Fig. 6: Front panel slightly tilted.
  • Page 8 Wallbox Duo Power - Assembly manual 3 - 2021 Fig. 9: The device open with the access to its in- terior. INFO The panel is fitted into place by following the above operations in the reverse order. WARNING Be careful not to crimple the signal tape while fitting the front panel.
  • Page 9: Design Indications Of The Installation

    (RCD A 30 mA/40 A) in the switchboard with the For Wallbox Adspace devices, a reserve of application of Enelion RCM B – type B Residual about 110 cm of the cable supplying power to Current Monitor, attached to the charging termi- the left socket is recommended.
  • Page 10: Location Selection Criteria

    3. 100 cm clearance below the bottom edge of the device. Enelion devices equipped with the Enelion Bridge mod- ule can use the Internet connection via the Ethernet in- terface in the LAN network. In order to utilize this func-...
  • Page 11: Assembly

    Preparing the installation 1. Place the packaged Enelion Wallbox Duo Power horizontally, in accordance with the markings on Fig. 11: Mounting holes of Enellion Wallbox Duo Power the packaging. Cut the package open along as seen from the back of the device.
  • Page 12: Cable Routes

    490 mm x 96 mm (width x height), 2. mounting holes have a diameter of 5,5 mm, Fig. 15: Locations of cable entry points in Enelion Wall- 3. the device weighs 6,2 kg, box Duo Power.
  • Page 13: Mounting The Device

    3. Make sure that there is no voltage in the power cords. 4. Open the device as described in section 2.1 Opening and closing Enelion Wallbox Duo Power. 5. Put the device in the target position by threading the power cable through the glands.
  • Page 14: Connection

    MID meter. Enelion Wallbox Duo Power devices come in various types. Depending on which type is being installed, the Fig. 16: Diagrams of connection types 1/2.
  • Page 15: Standard Power Connection

    2. Insert the power supply cables into the terminals. INFO For both sockets to operate, the voltage in Ene- lion Wallbox Duo Power must be supplied to the connection clamps of both charging con- trollers. Operations described below should be performed for the terminals of both charging sockets.
  • Page 16: Power Connection In Version With Mid Meter

    Fig. 20: Electrical connection executed correctly. HINT The colors of the phase wires in Enelion Wall- box Duo Power may not match the colors of the power cables, maintaining, however, the guide- lines on Enelion Wallbox Duo Power label. This is a correct and expected situation when using the phase sequence function.
  • Page 17: Connection Of Communication Wires

    5.2. Connection of communication wires HINT As a default, both integrated charging con- trollers in Enelion Wallbox Duo Power are con- nected with the communication cable. When setting up Enelion Chain network, this section Fig. 24: Incoming and outgoing communi-...
  • Page 18: Internet Connections Via Ethernet Interface In Lan Network

    Fig. 31: Enelion Bridge module diagram. Fig. 29: The place of applying the terminating jumper (variant B) 5.4. Internet connections via Ethernet in- terface in LAN network To provide the Internet connection to a charger equipped with Enelion Bridge module via Ethernet in- terface: Connection...
  • Page 19: Maintenance

    Wallbox Duo Power - Assembly manual 3 - 2021 6. Maintenance The device is designed to operate in temperatures from −25 °C to 55 °C. The manufacturer does not guarantee the proper functioning of the charging station in temper- atures outside the specified range. Chargers that are damaged because of exposure to temperatures below −25 °C or above 55 °C are not covered under the war-...
  • Page 20: Technical Data

    Wallbox Duo Power - Assembly manual 3 - 2021 7. Technical data 7.1. Enelion Wallbox Duo Power Electrical data Routing of the power cord Surface mounted Recommended minimum cross-section Power cord cross-section • 2 cables 5 x 6,0 mm (32 A nominal current)
  • Page 21 Wallbox Duo Power - Assembly manual 3 - 2021 Ambient conditions Working temperature from −25 °C to 55 °C Storage temperature range from −40 °C to 80 °C Permitted relative air humidity from 5% to 95% Elevation above the sea level...
  • Page 23 © 2021 ENELION Pana Tadeusza 50, 80-123 Gda ´ nsk, Polska...
