Wallbox Installation guide Enelion Sp. z o.o info@enelion.com September 17, 2018...
Page 2
Copyright by Enelion Sp. z o.o The instruction may be changed as the product develops. There is no guarantee as to the accuracy of the provided information. All rights reserved. Document version: V 1.4 Number of pages: 22 Date of issue: September 17, 2018...
Contents 1 Important information 1.1 General provisions ......... . . 1.2 Protection guidelines .
Page 4
Congratulations on your purchase of Enelion Wallbox charger and thank you for trusting us. Before the installation make sure that the box contains all accessories from the list below: • Enelion Wallbox charger, • a short version of the User Manual, •...
1.1 General provisions The Enelion charger (further called the device, the charger or the charging terminal) is a charging station dedi- cated for charging electric cars as defined in the Act of 11 January 2018 on Electromobility and Alternative Fuels, in Art.
Page 6
• Installing the device in a location with the risk of falling objects which may damage the charger is forbidden. WARNING The manufacturer is not liable for damages resulting from not following the above listed recommendations. Wallbox — Installation guide Page 5 of 22...
2.1 Introductory information Enelion Wallbox weighs 2750 g. The device is not provided with wall anchors/screws. These should be selected according to the device weight and the holes in the wall. The device should be mounted onto a flat vertical, using the 4 holes with 5.5 mm diameter at the back of the device.
Page 8
• The device should be placed on a sta- ble surface. • Next you must carefully remove the sealing plug from the cable gland open- ing with the use of a hammer and fork spanner. Wallbox — Installation guide Page 7 of 22...
TN–C–S Enelion Wallbox is equipped with a device which serves as a RCD Type A 30 mA. It is possible to have another RCD Type A 30 mA security in the electric cabinet on the cable in order to secure it in the cabinet—charger section.
Page 10
Preparing the wiring system June 2018 The wiring system The color in the connector block Blue Yellow and green Brown Black Grey Wallbox — Installation guide Page 9 of 22...
Fixing the device firmly is crucial to its proper operation when in service. 6. Lead the power supply cable through the cable gland, make a connection and tighten the cable gland. You can find the connection diagram below. Wallbox — Installation guide Page 10 of 22...
Page 12
(a) If the device is to be connected in a network of charging terminals, lead the adequate cable through the cable gland for wired communication and connect it to the device following the description in Chapter 6 Connecting the devices into one local network. Wallbox — Installation guide Page 11 of 22...
Page 13
7. Close the charging terminal following the instructions in Chapter 5 Mounting and removing the front panel. INFO Once the device is mounted you may continue to do the steps connected with initiating the device from the User Manual available on www.enelion.com/manuals. Wallbox — Installation guide Page 12 of 22...
2. With about 11 twists to the left unlock the front panel. If you feel strong resistance do not continue to twist the security screw. Wallbox — Installation guide Page 13 of 22...
Page 15
4. Next, pull the bottom part of the panel while hold- ing the socket case until the casing is displaced. 5. Holding the front panel in the same plane, slide it down out of the frame at the top of the device. Wallbox — Installation guide Page 14 of 22...
6 Connecting the devices into one local network The devices produced by Enelion may be connected in a local network regardless of whether they are online or offline. The network uses a bus network with a connection inside each charger. In order to establish communi- cation you need two cables: 1.
3. Twist cables of the same color and put them into the socket to the left of the motherboard in the charger, according to the markings. 4. Each cable is screened and each screen must be connected to the motherboard only at one end. Wallbox — Installation guide Page 16 of 22...
The Enelion chargers may be extended by fitting a communication module. This module turns the charger into an online charger. Installing the communication module in the Enelion Wallbox device is an operation which the users may do on their own.
1. Make sure that the Ethernet cable was led through the cable gland correctly and that it was terminated with a clamping sleeve according to TIA-568A/B to 100BaseT in the following way: Wallbox — Installation guide Page 18 of 22...
Page 20
Extending charger functionality with a communication module June 2018 2. Connect the cable to the WAN outlet and after a few seconds the device should connect to the Internet. Wallbox — Installation guide Page 19 of 22...
Micro SIM card WiFi 802.11 b/g/n, 2.4 GHz, maximum data transfer speed 150 MBps, transmitter capacity 21 dB dB RFID MIFARE cards in compliance with ISO 14443 When the communication module is used Wallbox — Installation guide Page 20 of 22...
Page 22
Environment Working temperature from −20 C to 55 C Storing temperature range from −40 C to 80 C Acceptable relative air humidity from 5 % to 95 % Altitude Altitude 2000 m Wallbox — Installation guide Page 21 of 22...
