  • Page 1 Video tutorial ENELION LUMINA 3 in 1 modular structure — build and upgrade your dreamed solution using the same base module. Quick installation — get your EV charger ready to work online in no more than 15 minutes of the...
  • Page 2 Dear Partner, Congratulations on your purchase of the Enelion charger and thank you for your trust. Up-to-date manuals for users and installers always available at: https://enelion.com/support-lumina/ Please read this manual before installation or prior to the station being commisioned.

  • Page 3: Table Of Contents

    Introduction Additional tools necessary for installation Optional safety screws Features Technical specifications Safety instructions Before the installation How to prepare the device for installation ENELION LUMINA SOCKET ENELION LUMINA SOCKET PREMIUM ENELION LUMINA PREMIUM CABLE Installation Diagrams of connection variants...
  • Page 4 Measuring a 230 V socket. Ethernet connection. Wired communication in ENELION LUMINA. Step by step Start-up and configuration of the station Additional information for the UK market Pen Fault Detection Daily use and operation How do I charge? Interface LED...
  • Page 5 ENELION LUMINA products family ENELION LUMINA BACKPLATE CLOSED ENELION ENELION OPENED LUMINA LUMINA ENELION CABLE SOCKET LUMINA PREMIUM PREMIUM SOCKET...

  • Page 6: Additional Tools Necessary For Installation

    Introduction Additional tools necessary for installation x6 x6 PH2 + PH3 PZ1 + PZ2 + PZ3 5 mm T10 + T15 + T20...

  • Page 7: Optional Safety Screws

    Optional safety screws Each charger kit includes safety screws (additionally secured with a pin to prevent unauthorized access) that can replace the standard screws attaching the top part of the head to the back, if needed. The appropriate bit is optionally available as an accessory or can be purchased separately (size T10H x 25 mm).

  • Page 8: Features

    Features RFID CARD READER LED INTERFACE SOCKET TYPE 2 WI-FI ROOM FOR OPTIONAL ETHERNET MODULE ROOM FOR OPTIONAL CERTIFIED ENERGY METER ROOM FOR OPTIONAL 230 V CEE 7/3 SOCKET...

  • Page 9: Technical Specifications

    Flammability class Enelion LUMINA Socket – Type 2 socket, Charging connector type Enelion LUMINA Cable Premium – Type 2 connector with 5.2 m cord Embedded residual current monitor - Enelion RCMB 6 mA DC Residual current protection Integrated 3-phase energy meter > 99% accuracy Energy metering Impulse* –...
  • Page 10 3 x 400 V AC/230 V AC (±10 %) (TN/IT) Supply voltage Possibility of connecting the cable from the top, bottom and the back of the station • Configuration with no additional tools • Remotely controlled 230V socket (max. 2000W/10A)* Other features •...

  • Page 11: Safety Instructions

    The Enelion charger (hereinafter referred to as the device, charger, or charging terminal) is a The manufacturer is not responsible for damages...
  • Page 12 During the warranty period, the manufacturer allows the purchase of support packages for the device (extended warranty/service) subject to a qualifying review before purchasing the package. Details can be obtained from the Enelion sales department. The charging station does not support ventilation functions.

  • Page 13: Before The Installation

    Charging power is recommended to consider future charging needs before installation. Charging 1 phase 3 phase • The power supply to the Enelion charging current (kW) (kW) terminal must be provided from an electrical switchgear. The switchgear must have the...

  • Page 14: How To Prepare The Device For Installation

    How to prepare the device for installation ENELION LUMINA SOCKET Slide out the head module and remove the housing cover Undo two long bolts and two screws at the bottom (1). Repeat with two screws at the Unscrew the fixing screws and remove...

  • Page 15: Enelion Lumina Socket Premium

    ENELION LUMINA SOCKET PREMIUM Slide out the head module Undo two long bolts at the bottom (1) and two screws at the top (2) Unscrew the fixing screws and remove the transparent cover...

  • Page 16: Enelion Lumina Premium Cable

    ENELION LUMINA PREMIUM CABLE Slide out the head module Dismantle the cable holder (1). Undo two Unscrew the fixing screws and remove long bolts at the bottom (2) and two the transparent cover screws (3) at the top...

  • Page 17: Installation

    This product may only be installed, repaired Enelion Enalion or serviced by an authorized electrician. All LUMINA LUMINA local, regional and national electrical installation Backplate Backplate regulations must be observed.

  • Page 18: Overview Diagrams Of Modules

    Preparation diagrams of modules Charging module Type 2 socket In the box with the Enelion LUMINA charger, with RCMB 6 mA DC you will find an assembly template to help you choose the installation location and prepare the 5x6 mm installation holes.
  • Page 19 It is possible to power the station from other network systems described below: In the TN-C system configuration, you should In the case of an IT network with 120/230 V, as separate the PEN conductor into N and PE as found in Norway, the connection appears as shown in the diagram below.
  • Page 20 It should be noted that one of the phases serves Other, more complex power systems require as the Neutral conductor, which is important technical consultation before purchase. during the installation of RCD (Residual Current Device). In such a network, it is not possible to charge in three phases;...

  • Page 21: Installation Of Mounting Plate

    Installation of Electrical mounting plate connection For maximum charging power, it is recommended to use cables with a conductor cross-section not exceeding 6 mm . This is also the maximum Turn off the power before installation. diameter that can be installed in the connection terminals.
  • Page 22 1-phaze 3-phaze It is recommended to use the existing colour code used in the wiring. Depending on the standard in your country, the cable colours may differ from those shown. 1-phaze Before switching on the power, make sure that the cables are connected correctly. Test this by pulling on each wire.

  • Page 23: Alternative Method For The Insertion Of Power Cables

    Alternative method for the insertion of power cables If it is not feasible to insert the power cables in the standard way, an alternative method can be applied. In the lower part of the rear housing of the station (if it is not equipped with the optional 230 V socket), there is a hole for an M25 cable gland with a blanking plug.

  • Page 24: M20 Gland Adapter

    M20 gland adapter For the alternative method of inserting power cables into the station, an adapter with a hole for M20 gland is available separately – it can be used to install a special gland with an armoured cable in case of a single-phase system.

  • Page 25: Measuring A 230 V Socket

    The charger’s power supply is connected directly to the board presented in chapter 5. Energy meter fuse* socket Energy meter Fuse Distribustion board *0234010.MXP (Cartridge Fuse 250V 10a Medium Acting) Electrical connection of ENELION LUMINA in the case of measuring a 230 V socket.
  • Page 26 We do not recommend using a 230 V socket for charging your car because it may overload the connection. More information related to measuring the 230 V Power connection in the case of measuring the entire ENELION socket can be found in the user manual. LUMINA charger.

  • Page 27: Ethernet Connection

    Ethernet connection. The Ethernet module is installed in ENELION LUMINA chargers on the back of the device on the left side. The Ethernet cable can be routed through a special opening in the back cover and is secured against being pulled out by a special clamp installed in the charger.
  • Page 28 Due to differences in the implementation of CAN communication in ENELION LUMINA chargers and Enelion Wallbox, Vertica, and Stilo chargers, it is not possible to connect them in a single chain. To terminate, use the switch shown in the diagrams in devices located at the beginning and end of the charger chain.

  • Page 29: Step By Step

    Step by step Level the template Drill holes Screw the backplate to – mark the holes – insert pins walls – tighten the cable entry Remove the Connect wires insulation from the cable...
  • Page 30 Enelion LUMINA with optional 230 V CEE 7/3 SOCKET and optional CERTIFIED MODEL LB-32-3-X-1-X-XX-MGR-00 ENERGY METER...
  • Page 31 Enelion LUMINA with optional 230 V CEE 7/3 SOCKET MODEL LB-32-3-X-1-X-XX-GR-00...
  • Page 32 Slide Install the transparent cover Insert SIM card Mount the head on using four screws. Slide from the front Use two long bolts and two Tighten the head – two long Install screws at the bottom and two bolts at the bottom front cover screws at the top and two screws at the top...

  • Page 33: Start-Up And Configuration Of The Station

    Using a smartphone or computer, search for the LUMINA station’s AP with the SSID listed on the back of the charging head. After connecting to the LUMINA station’s AP with...

  • Page 34: Additional Information For The Uk Market

    To follow and be compliant with the regulations specified by IET in clause 722.411.4.1 (iv), Enelion for the UK LUMINA uses a technology that enables you to directly connect your charger to a PME supply. market Enelion LUMINA now includes a safety monitoring system to detect potential earth-neutral faults.

  • Page 35: Daily Use And Operation

    • If access control is configured, block it with a registered RFID tag or disable it in the configuration panel on the Wi-Fi interface. Before each use of the Enelion LUMINA charger: 1. Check that the charging cable and connector are not damaged or contaminated, e.g.

  • Page 36: Interface Led

    Interface LED Maintenance The Enelion LUMINA charging station has an The manufacturer recommends conducting an LED interface that provides the user with basic inspection of the device once every 12 months for safety and maintenance reasons. The inspection information: is not mandatory.

  • Page 37: Practical Details

    Standards Practical Enelion sp. z o.o. hereby declares that this product, the Enelion LUMINA charging station, details complies with: 2014/53/EU (RED); 2011/65/EU (RoHS), 2014/30/EU (EMC) ; 2014/35/EU (LVD); UK SI 2016 No. 1101; UK SI 2016 No. 1091; UK SI 2017 No.
  • Page 38 If your charger requires repair, please contact your distributor. Returns and complaints For product returns and complaints, please contact your distributor or Enelion customer service.
  • Page 39 Download the latest user manuals, useful Customer documents and videos for your product on https://enelion.com/support-lumina/ service This document contains information that is subject to change without notice. © 2023 ENELION 50 Pana Tadeusza St, 80-123 Gdansk, Poland...
  • Page 40 Copyright Enelion sp. z o.o. The manual may change as the product develops. All rights reserved. Revision: V 7 Number of pages: 40 Released: December 29, 2023 Enelion sp. z o.o. | 50 Pana Tadeusza St 80-123 | Gdansk | Poland sales@enelion.com enelion.com...
