WARRIOR SERIES_
3" Dome Surface Mount:
WS1
The Warrior WS1 is built to take punishment and give years of dependable service. Perfect for indoor
or outdoor locations such as schools, correctional facilities, airports, hospitals and more. The WS1 is
available with either fixed or vari-focal lens. And the camera itself is protected by a high-impact,
polycarbonate dome with liner that can withstand the impact of a sledgehammer.
Engineering Specifications (WS1)
The WS1 housing is manufactured from 3/16" thick cast aluminum with an off-white powder coat finish and is environmentally
sealed. One 3/4" conduit opening is located on a side of the housing and one 1/2" conduit opening is located on the back. The
dome is constructed of 1/8" thick polycarbonate measuring 3.875" in diameter. A including a liner, along with a lanyard to
keep the dome from dropping when opened for service. A camera bracket with three-way adjustment is included. Adjustments
include 360º pan of the entire bracket, 180º tilt of the lens bracket, and a 90º tilt of the lower portion of the bracket in instances
where the entire housing must be mounted at an angle.
3" Dome Recessed Mount:
WS2
The WS2 is the recessed version of the WS1. It's designed for ceiling or wall mounting and, with its
recessed body, offers a low profile. Besides use in indoor applications such as schools or hospitals, the
environmentally sealed body allows outdoor use in areas such as loading docks or parking garages.
The back box and lower body of the WS2 are constructed of cast aluminum, while the dome is made
from high-impact polycarbonate and comes with liner. The WS2 comes complete with a color camera,
available with either fixed or vari-focal lens.
Engineering Specifications (WS1)
The WS2 housing back box and lower body are both manufactured from 3/16" thick cast aluminum with an off-white powder
coat finish. The housing is environmentally sealed. The dome is constructed of 1/8" thick polycarbonate. A camera bracket with
three-way adjustment is included. Adjustments include 360º pan of the entire bracket, 180º tilt of the lens bracket, and a 90º
tilt of the lower portion of the bracket in instances where the entire housing must be mounted at an angle. To fully conceal the
back box the use of a standard double gang box is recommended. Available with a high resolution color camera; fixed, fixed iris
vari-focal or auto iris vari-focal lens.
Key Features
•
Includes a choice of cameras
•
Heavy-duty cast aluminum construction
•
Fully adjustable 3-axis camera bracket, allowing 360º
pan,180º tilt
•
Environmentally sealed - designed for NEMA 4, IP65
•
Clear or tinted polycarbonate dome with liner
•
Tamper-resistant fasteners
Key Features
•
Includes a choice of cameras
•
Cast aluminum construction
•
Fully adjustable 3-axis camera bracket, allowing 360º pan,180º tilt
•
Environmentally sealed
•
Clear or tinted dome with liner
•
Mounts to standard double gang box (not provided)
•
Tamper-resistant fasteners
SPECIFICATIONS:
Electrical Specifications
Input Voltage:
15 - 30 VDC or 20 - 28 VAC
Video Connector:
BNC
General Specifications
One 3/4" threaded side conduit opening One 1/2"
Cable Entry:
threaded base conduit opening
Pan/Tilt:
Manual; 360º pan / 180º tilt
Environmental Specifications
Temperature Range:
0º to 120º F
Construction
3/16" thick cast aluminum 1/8" polycarbonate dome
Finish:
Off-white powder coat
Dimensions
Base:
5.25" (H) x 5.25" (W) x 4" (D)
Dome:
3.875" diameter
SPECIFICATIONS:
Electrical Specifications
Input Voltage:
15 - 30 VDC or 20 - 28 VAC
Video Connector:
BNC
General Specifications
Pan/Tilt:
Manual; 360º pan / 180º tilt
Environmental Specifications
Temperature Range:
0º to 120º F
Construction
3/16" thick cast aluminum 1/8" polycarbonate dome
Finish:
Off-white powder coat
Dimensions
Base:
5.25" (H) x 5.25" (W) x 4" (D)
Dome:
3.875" diameter
