81-In5313
Unitized Pan/Tilt/Zoom
FdW8cs
rEVIsIon dAtE: June 8, 2005

tABLE oF contEnts

dEscrIPtIon:

The FDW8CS is a 24 VAC outdoor housing enclosure constructed
of .125 engineered plastic, aluminum and stainless steel. All plastic
components are designed to be UV stable; the housing top is rated
at 94VO. The FDW8CS measures 11.5" (w) x 12.9" (h) x 16" (d), with
a weight of 7 lbs.; measurements for the FDP8CS are 11.5" (w) x
12.9" (h) x 11.5" (d), 7 lbs. Flying leads are provided for all incoming
power, control, and video connections. The leads are supplied with
a standard BNC and (2) screw down connectors. A 25 watt heater
and a circulation blower are also provided. To service, remove the
lower dome and ring assembly.

ELEctrIcAL sPEcIFIcAtIons (outdoor):

!
Power 24VAC, Class 2 Only
55 watts at 24 VAC
27 watts for heater and blower
25 watts for camera
Optional heater/blower assembly: CWKFD2 - 24 VAC cold weather
kit for outdoor FDW(P)8C2 housings
Input Connectors (outdoor units):
BNC
(2) screw-down connectors
notE: This unit is designed for operation in an
upright position. Installing the FusionDome™
upside down may cause damage to the
internal equipment, and will void the war-
ranty.
in Fusion dome
9
10
11
Product InstructIons
GEnErAL InstructIons:
Tools Required: .100" Flat Head Screwdriver
1
1

InstALLInG tHE HousInG AssEMBLY

1
2
For WALL Mount, FdW8cs
2
2
1. FdW8cs
2
A wall mount bracket comes standard with this unit, and a
3
template is included to use as a guide for mounting the bracket
to a wall. Choose the desired location for installation, mark
3
and drill holes using the template. Run approximately 8" of wiring
3
out of the wall.
3
5
2. Open the access door on the bottom of the wall mount by
loosening the screw nearest the mounting plate (Figure 1).
3. Run the wires into the opening on the back of the mount and out
through the access door. Attach the mount and housing to the
wall
with appropriate hardware (no provided).
4. Attach the wires from the wall to the connector provided, using
the
wiring color code chart on page 2 as a guide.
5. Once all wiring connections are made, place the wires inside the
wall mount bracket and close the access door. Secure with the
screw removed earlier.
6. Clean the outside of the dome.
Figure 1
Phillips Head Screwdriver
Access door
