IPPC-9151 Series
Rugged Industrial Panel PC with
Intel® Pentium® 4 or Celeron®
and 15" LCD Display
Users Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPPC-9151 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Advantech IPPC-9151 Series

Summary of Contents for Advantech IPPC-9151 Series

  • Page 1 IPPC-9151 Series Rugged Industrial Panel PC with Intel® Pentium® 4 or Celeron® and 15" LCD Display Users Manual...
  • Page 2 Copyright notice This document is copyrighted 2005, by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 3 FCC Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environ- ment.
  • Page 4 1/4R/S D=6.6 H=1.5 + M3*5L ST Ni x 8 ROUND M6*25 x 4 SP/S D=8 H=1.5 - M4*6L ST Ni x 8 The IPPC-9151 Series of Industrial Panel PCs includes the following models: IPPC-9151G-XAE Rugged Pentium 4 Industrial Panel PC with 15" LCD,180W AC power...
  • Page 5 IPPC-9151F-RAE IPPC-9151F-XAE with resistive touchscreen Additional Information and Assistance Step 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Step 2. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need addi- tional assistance.
  • Page 6 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advan- tech disclaims all responsibility for the accuracy of any statements contained herein. IPPC-9151 Series Users Manual...
  • Page 7 Wichtige Sicherheishinweise 1. Bitte lesen sie Sich diese Hinweise sorgfältig durch. 2. Heben Sie diese Anleitung für den späteren Gebrauch auf. 3. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Verwenden Sie Keine Flüssig-oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.
  • Page 8 Der arbeitsplatzbezogene Schalldruckpegel nach DIN 45 635 Teil 1000 beträgt 70dB(A) oder weiger. Haftungsausschluss: Die Bedienungsanleitungen wurden entsprechend der IEC-704-1 erstellt. Advantech lehnt jegliche Verantwortung für die Richtigkeit der in diesem Zusammenhang getätigten Aussagen ab. IPPC-9151 Series Users Manual viii...

  • Page 9: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Specifications ..............3 1.2.1 General................3 1.2.2 Standard PC Functions............ 3 1.2.3 AGP SVGA/Flat Panel Interface ........4 1.2.4 Audio Function ............... 4 1.2.5 PCI bus Ethernet Interface..........5 1.2.6 PCMCIA interface ............5 1.2.7 Analog Resistive Touchscreen (optional).......
  • Page 10 Further Information ............40 Chapter 7 Audio Setup.............42 Introduction ..............42 Installation of the Audio Driver ........42 7.2.1 Installation for Windows 98/ME/2000/XP ....43 Chapter 8 Touchscreen ........... 46 Introduction ..............46 Touchscreen Specifications..........46 IPPC-9151 Series Users Manual...
  • Page 11 Installing Driver for Windows 2000/XP ......47 Configuring PenMount Windows 2000/XP Driver..52 8.4.1 PenMount Control Panel ..........52 8.4.2 PenMount Monitor Menu Icon ........62 8.4.3 PenMount Rotating Functions ........63 Uninstall the PenMount Windows 2000/XP driver..64 Chapter 9 PCMCIA ............66 Introduction ..............
  • Page 12 Table B.7:Internal speaker connector (CN15).... 102 IR connector (CN24)............. 102 Table B.8:IR connector (CN24)........102 Fan power connector (FAN1 & FAN2) ......102 IPPC-9151 Series Users Manual...
  • Page 13 General Information This chapter gives background information on the IPPC-9151 series Sections include: • Introduction • Specifications • Dimensions...

  • Page 14: Chapter 1 General Information

    Friendly HMI Systems in the IPPC-9151 series are equipped with a 15" LCD screen, which provides high resolution display quality. The result is vivid, bright, and sharp quality images. The panel PC is perfectly suited for Windows OS.

  • Page 15: Specifications

    1.2 Specifications 1.2.1 General • Dimensions (W x H x D): Front Panel: 428 x 310 x 8 mm (16.85" x 12.2" x 0.31") Cabinet: 402 x 290 x 162 mm (15.82" x 11.41"x 6.37") Cut out dimension: 406 x 294 mm (15.98" x 11.57") •...

  • Page 16: Agp Svga/Flat Panel Interface

    • Chipset: Integrated in Intel 845GV ICH4 South Bridge • Audio controller: AC97 Ver.2.0 compliant interface, Multi stream, Direct sound and Direct Sound 3D acceleration • Stereo sound: 18-bit full-duplex codec • Audio interface: Microphone-in, line-in, line-out, and game ports MPU-401. IPPC-9151 Series Users Manual...

  • Page 17: Pci Bus Ethernet Interface

    Supports DOS, Windows 3.1, Windows 98/ME/2000/XP and Win- dows NT 4.0 1.2.8 Optional Accessories • IPPC-9151G-RMKE 19" rack mounting kit for IPPC-9151 series. 1.2.9 Environmental • Operating temperature: 0 ~ 50° C (32 ~ 122° F) • Storage temperature: -20 ~ 60° C (-4 ~ 140° F) •...

  • Page 18: Dimensions

    1.3 Dimensions Figure 1.1: IPPC-9151FA Dimensions Figure 1.2: IPPC-9151GA Dimensions IPPC-9151 Series Users Manual...
  • Page 19 System Setup This chapter details system setup for the IPPC-9151 Series. Sections include: • General • Installing SDRAM • Installing a CPU • Installing a 2.5" HDD • Installing a CD-ROM Drive • Installing Add-on Cards • Mounting Instructions...

  • Page 20: Chapter 2 System Setup

    - Avoid touching metal parts of the motherboard. - Wear an anti-static ring when handling a CPU or SDRAM module. - Put SDRAM modules and the CPU inside an anti-static bag or a similar place before installation. IPPC-9151 Series Users Manual...
  • Page 21 Figure 2.1: Side View • • • • Figure 2.2: Bottom View Chapter 2...

  • Page 22: Ps/2 Mouse And Keyboard

    An external VGA-compatible device may be connected to the system via the 15-pin external port located on the rear of the system unit. The panel PC simultaneously supports an external CRT monitor in addition to its own LCD display. IPPC-9151 Series Users Manual...

  • Page 23: Serial Com Ports

    2.1.4 Serial COM ports There are two serial COM ports on the bottom of the rear cover. You can easily attach a serial device to the panel PC, such as an external modem or mouse. Follow these instructions: 1. Make sure the panel PC and any other peripherial devices you may have connected to the panel PC are turned off.

  • Page 24: Ethernet

    LED stops blinking. (See Pic. #2) 2.1.9 System turn ON/OFF The IPPC-9151 series offers 2 system on/off options, which are: 1. Front Panel system on/off, which is the default setting.(pic) 2. Rear Cover system on/off. If you choose this one, you need to recon- nect the cable.

  • Page 25: Installing Sdram

    2.2 Installing SDRAM You can install from 64 MB to 2 GB (x2) of DDR SDRAM memory. The Panel PC system provides one 184-pin DIMM (Double Inline Memory Module) socket, and supports 2.5 V DDR SDRAM. 1. Unlock the back cover and open it. 2.
  • Page 26 4. Disconnect the HDD cable. 5. Undo the seven screws of the HDD Module so you can install the SDRAM. IPPC-9151 Series Users Manual...

  • Page 27: Installing A Cpu

    6. Push the two white eject levers on each side of the DIMM outward until they are separated from the black vertical posts. 7. Insert the memory module into the socket at an angle of 90 degrees. 8. Push the two eject levers toward the vertical posts at each end of the socket until the module is upright.

  • Page 28: Installing A 3.5" Hdd

    Remove four screws and take off HDD bracket. Insert the HDD into the bracket (see figure 2.4.3) Put the HDD bracket into the Chassis and fasten the four screws. Then attach the HDD flat cable and power cable. IPPC-9151 Series Users Manual...
  • Page 29 Insert the FDD, CD-ROM Module and fix the back cover. Chapter 2...

  • Page 30: Installing Add-On Cards

    3. Use the screws to secure the brackets to the cover. Tighten the screws to secure the monitor to the back panel. 2.6.2 Rack Mounting The monitor can be mounted to a 19" industrial rack with an optional bracket. IPPC-9151 Series Users Manual...

  • Page 31: Jumper Settings

    Jumper Settings and Connectors This chapter tells how to set up the panel PC hardware, including instruc- tions on setting jumpers and connecting peripherals, switches and indicators. Be sure to read all the safety precautions before you begin the installation proce- dures.

  • Page 32: Connectors

    Chapter 3 Jumper Settings & Connectors 3.1 Jumpers and Connectors 3.1.1 Setting jumpers You can configure your panel PC to match the needs of your application by setting jumpers. A jumper is the simplest kind of electrical switch. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.

  • Page 33: Jumpers And Switches

    3.1.2 Jumpers and switches The motherboard of the IPPC-9151 has a number of jumpers that allow you to configure your system to suit your applications. The table below lists the function of each of the board’s jumpers. Table 3.1: Jumpers, switches and their functions Label Function FSB (Front Side Bus) Setting...

  • Page 34: Connectors

    3.1.4 Connectors Onboard connectors link the panel PC to external devices such as hard disk drives or floppy drives. The table below lists the function of each of the board’s connectors. Table 3.2: Panel PC connectors Label Function ATX 20 pin power connector ATX 12V Power connector LVDS connector 1 Invertor Power connector 2...

  • Page 35: Locating Connectors

    3.1.5 Locating connectors Figure 3.2: Connectors on IPPC-9151 motherboard Chapter 3...

  • Page 36: Cpu Installation

    3.2 CPU Installation You can install an Intel Pentium 4 or Celeron CPU without setting any frequency ratio or voltage. Warning! To avoid damaging the computer, always turn off the power supply before setting “Clear CMOS”. Set the jumper back to “Normal operation” before turning on the power supply.

  • Page 37: Com-Port Interface (Jp4, Jp5)

    3.4 COM-port interface (JP4, JP5) The panel PC provides two serial ports. COM1 (RS-232) and COM2 (RS- 232/422/485) in one COM port connector. 3.4.1 COM2 RS-232/422/485 setting (JP4) COM2 can be configured to operate in RS-232, RS-422, or RS-485 mode. This is done via JP6.

  • Page 38: Vga Interface

    Table 3.6: COM 1/2 Pin 9 setting (JP5) Select 5 V *Select Ring * default setting 3.5 VGA interface The panel PC's AGP VGA interface can drive conventional CRT dis- plays. It is also capable of driving a wide range of flat panel displays, including electroluminescent (EL), gas plasma, passive LCD and active LCD displays.
  • Page 39 Intel Chipset This chapter provides information on the Intel chipset configuration. Sections include: • Introduction • Installation of chipset driver for Windows 98/NT/ME/2000/XP • Further Information...

  • Page 40: Chapter 4 Intel Chipset

    You must follow the flow chart instruc- tions and pay attention to the instructions which then appear on your screen. Notes: 1. The CD-ROM drive is designated as "D" throughout this chapter. 2. <Enter> means pressing the "Enter" key on the keyboard. IPPC-9151 Series Users Manual...

  • Page 41: Installation For Windows 98/Nt/Me/2000/Xp

    4.2.1 Installation for Windows 98/NT/ME/2000/XP a. Select "Start", "Run”. b. Enter the driver path "D:\IPPC-9151G& 9171G_DRV&Utility \Chipset Software\IAA Driver\2.3\iaa23_multi.exe". c. Click “OK”. 2. Press "Next" to continue the installation. 3. When you finish the IAA driver installation. Please continue to install the INF driver.

  • Page 42: Further Information

    For further information about the AGP/VGA installation in your IPPC- 9151, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Intel website: www.intel.com Advantech website: www.advantech.com If you need to know more details about installation, please refer to \IPPC-9151G& 9171G_DRV&Utility\Chipset Software IPPC-9151 Series Users Manual...
  • Page 43 PCI Bus Ethernet Inter- face This chapter provides information on Ethernet configuration. Sections include: • Introduction • Installation of Ethernet Driver for Windows 98/NT/ME/2000/XP • Further Information...

  • Page 44: Chapter 5 Pci Bus Ethernet Interface

    Note 1: The CD-ROM drive is designated as "D" through- out this chapter. Note 2: <Enter> means pressing the "Enter" key on the keyboard. IPPC-9151 Series Users Manual...

  • Page 45: Installation For Windows 98/Nt/Me/2000

    5.2.1 Installation for Windows 98/NT/ME/2000 a. Select "Start", "Run" b. Enter the path, "D:\IPPC-9151G& 9171G_DRV&Utility \Intel Lan 6.2\Setup.exe" c. Click "OK" a. Click "Next” Read the license agreement and click "Yes" if you accept the terms and wish to continue. b.
  • Page 46 Click "Next" a. Click "Install" IPPC-9151 Series Users Manual...

  • Page 47: Further Information

    Click "Finish" 5.3 Further Information Intel website: www.intel.com Advantech website: www.advantech.com Chapter 5...
  • Page 48 IPPC-9151 Series Users Manual...
  • Page 49 VGA Setup This chapter provides information on the VGA setup. Sections include: • Introduction • Installation of VGA Drivers - for Windows 98/2000/ME - for Windows NT - for Windows XP • Further Information...

  • Page 50: Chapter 6 Vga Setup

    The system is initially set to simultaneous dis- play mode. If you want to enable the CRT display only or the flat panel display only, please contact Intel, or our sales representative for detailed information. IPPC-9151 Series Users Manual...

  • Page 51: Installation Of The Vga Driver

    6.2 Installation of the VGA Driver Complete the following steps to install the VGA driver. Follow the proce- dures in the flow chart that apply to the operating system that you are using within your IPPC-9151. 6.2.1 Installation for Windows 95/98/ME a.

  • Page 52: Further Information

    The driver will now be loaded. 6.3 Further Information For further information about the AGP/VGA installation in your IPPC- 9151, including driver updates, troubleshooting guides and FAQ lists, visit the following web resources: Intel website: www.intel.com Advantech website: www.advantech.com IPPC-9151 Series Users Manual...
  • Page 53 Audio Setup This chapter provides information on the Audio setup. Sections include: • Introduction • Installation of Audio Driver - for Windows 98/2000/ME - for Windows NT - for Windows XP...

  • Page 54: Chapter 7 Audio Setup

    2. For convenience, the CD-ROM drive is desig- nated as "D" throughout this chapter. 3. <Enter> means pressing the “Enter” key on the keyboard. IPPC-9151 Series Users Manual...

  • Page 55: Installation For Windows 98/Me/2000/Xp

    7.2.1 Installation for Windows 98/ME/2000/XP a. Select "Start", "Run" b. Enter the path "D:\IPPC-9151G& 9171G_DRV&Utility \ALC202\WinXP_2K_Me_9X\Setup.exe" Notes: 1. Installation for Windows 95, please Type the path "D:\IPPC-9151G& 9171G_DRV&Utility \ALC202\win95\Setup.exe" 2. Installation for Windows NT, please Type the path "D:\IPPC-9151G& 9171G_DRV&Utility \ALC202\winnt\Setup.exe"...
  • Page 56 IPPC-9151 Series Users Manual...
  • Page 57 Touchscreen This chapter contains information on the touchscreen, its installation and configuration.

  • Page 58: Chapter 8 Touchscreen

    Chapter 8 Touchscreen 8.1 Introduction The IPPC-9151 Series’ optional touchscreen uses advanced 8-wire resis- tive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards.

  • Page 59: Installing Driver For Windows 2000/Xp

    • Visible light transmission: 75% typical (>74% @ 550 nm test) • Clarity: Clear Finish - 25%, Antiglare Finish - 15% Sensor board • Chemical strengthened glass with 4 H hardness standard. (Test condition: ASTM D3363-92A) Ball drop test • Able to bear a 225 g steel ball dropped from 660 mm elevation without breaking Environmental Specifications •...
  • Page 60 Follow the steps below to install the PenMount Windows 2000/XP driver. When the system first detects the controller board, a screen appears that shows “Unknown Device.” Do not use this hardware wizard. Press Cancel. IPPC-9151 Series Users Manual...
  • Page 61 Insert the PenMount Driver CD-ROM. Go to the Windows 2000- XP Driver folder. Click setup.exe. The screen displays the installation wizard for the PenMount soft- ware. Click “Next”. Appendix 8...
  • Page 62 A License Agreement appears. Click “I accept…” and “Next” The “Ready to Install the Program” screen appears. Select “Install.” IPPC-9151 Series Users Manual...
  • Page 63 The next screen is “Hardware Installation.” Select “Continue Any- way.” The “InstallShield Wizard Completed” appears. Click “Finish.” Appendix 8...

  • Page 64: Configuring Penmount Windows 2000/Xp Driver

    Advanced Calibration uses 4, 9, 16 or 25 points to effec- Calibration tively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ‘ESC’. IPPC-9151 Series Users Manual...
  • Page 65 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Appendix 8...
  • Page 66 IPPC-9151 Series Users Manual...
  • Page 67 Plot Calibra- Check this function and a touch panel linearity com- tion Data parison graph appears when you have finished Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration. Appendix 8...
  • Page 68 Touch the screen with your finger or a stylus and the drawing screen reg- isters touch activity such left, right, up, down, pen up, and pen down. Click Clear Screen to clear the drawing. IPPC-9151 Series Users Manual...
  • Page 69 Multiple Monitors Multiple Monitors supports from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 70 When the mapping screen message appears, click OK. Touch each screen as it displays “Please touch this monitor.” Fol- lowing this sequence and touching each screen is called mapping the touch screens. IPPC-9151 Series Users Manual...
  • Page 71 Touching all screens completes the mapping and the desktop reap- pears on the monitors. Select a display and execute the ‘Calibration’ function. A message to start calibration appears. Click OK. “Touch this screen to start its calibration” appears on one of the screens.
  • Page 72 Beep on Pen Up – beep occurs when pen is lifted up Beep on both of Pen Down/Up – beep occurs on both Beep Frequency – modifies sound frequency Beep Duration – modifies sound duration IPPC-9151 Series Users Manual...
  • Page 73 About This panel displays information about the PenMount controller and driver version. Appendix 8...

  • Page 74: Penmount Monitor Menu Icon

    Right and Left Button functions. Pen Sta- Check this function to reduce cursor vibration for relatively bilizer unstable touch screens, or where there may be excess vibration. Normally this function is not checked. Exit Exits the PenMount Monitor function. IPPC-9151 Series Users Manual...

  • Page 75: Penmount Rotating Functions

    8.4.3 PenMount Rotating Functions The PenMount driver for Windows 2000/XP supports several display rotating software packages. Please see Chapter 5 for more information. The PenMount drivers for Windows 95, Windows 98/Me, Windows 2000/XP, as well as Windows 98 USB and Windows Me/2000/XP sup- port display rotating software packages such as: •...

  • Page 76: Uninstall The Penmount Windows 2000/Xp Driver

    Go to Settings, then Control Panel, and then click Add/Remove program. Select PenMount DMC9000 and click the Add/Remove button. Select PenMount DMC9000 and DMC9100. Click the Remove button. Select ‘Yes’ and “Close” to remove the PenMount Windows 2000/ XP driver, and reboot the system. IPPC-9151 Series Users Manual...
  • Page 77 PCMCIA Sections include: • Introduction • Installation of PCMCIA driver for Windows...

  • Page 78: Chapter 9 Pcmcia

    You must follow the flow chart instruc- tions and pay attention to the instructions which then appear on your screen. Notes: 1. The CD-ROM drive is designated as "D" throughout this chapter. 2. <Enter> means pressing the "Enter" key on the keyboard. IPPC-9151 Series Users Manual...

  • Page 79: Installation For Windows

    9.2.1 Installation for Windows a. In "Start", "Run", type the path: "D:\IPPC-9151G& 9171G_DRV&Utility\CardReader \Drivers\Windows\Setup.exe" a. Click "Next" to continue the installation. a. Click "Yes". Chapter 9...
  • Page 80 IPPC-9151 Series Users Manual...
  • Page 81 Award BIOS Setup This chapter describes how to set BIOS configu- ration data...

  • Page 82: Chapter 10 Award Bios Setup

    This is because the BIOS is revised and updated from time to time. If in doubt, check Advantech's website for the latest BIOS versions and related information. 10.2 CMOS Setup Utility A setup program, built into the system BIOS, is stored in the CMOS RAM that allows the configuration settings to be changed.

  • Page 83: Standard Cmos Setup

    Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Password Integrated Peripherals Save & Exit Setup Power Management Setup Exit without Saving PnP/PCI Configurations Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Time, Date, hard disk Type…...
  • Page 84 Refer to the respective documentation on how to install the drives. IDE HDD Auto-Detection Press Enter Item Help Menu Level IDE Primary Master Auto Auto Access mode Capacity 13022 MB Cylinder 25232 Head Percomp Landing Zone 25231 Sector Figure 10.2: Standard CMOS features IPPC-9151 Series Users Manual...
  • Page 85 Drive A / Drive B Select this field to the type(s) of floppy disk drive(s) installed in your sys- tem. The choices are: 360 KB, 5.25 in; 1.2 MB, 5.25 in; 720 KB, 3.5 in; 1.44 MB, 3.5 in; 2.88 MB, 3.5 in; None.

  • Page 86: Advanced Bios Features

    Choose“Advanced BIOS Features”from the Main Menu and a screen with a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. IPPC-9151 Series Users Manual...
  • Page 87 Virus Warning Disabled Item Help CPU Internal Cache Enabled Menu Level External Cache Enabled CPU L2 Cache ECC Checking Enabled Processor Number Feature Enabled Quick Power On Self Test Enabled First Boot Device Floppy Second Boot Device HDD-0 Third Boot Device CDROM Boot Other Device Enabled...
  • Page 88 Toggle between On or Off to control the state of the NumLock key when the system boots. If On, the numeric keypad is in numeric mode. If off, the numeric keypad is in cursor control mode. IPPC-9151 Series Users Manual...
  • Page 89 Gate A20 Option Gate A20 refers to the way the system addresses memory above 1 MB (extended memory). When set to Fast, the system chipset controls Gate A20. When set to Normal, a pin in the keyboard controller controls Gate A20.

  • Page 90: Advanced Chipset Features

    DRAM Timing by SPD When this item is Enabled, DRAM Timing is set by SPD. SPD (Serial Presence Detect) is located on the memory modules, BIOS reads informa- tion coded in SPD during system boot up. IPPC-9151 Series Users Manual...
  • Page 91 DRAM Clock This item allows you to control the DRAM speed. The choices are : Host Clock, HCLK+33M. SDRAM Cycle Length Select CAS latency time in HCLKs of 2 or 3. The system designer already set the values. Do not change the default value unless you change specifications of the installed DRAM or the installed CPU.
  • Page 92 The choices: Enabled; Disabled. PCI Dynamic Bursting When Enabled, every write transaction goes to the write buffer. Bursting transactions then burst on the PCI bus and non-bursting transactions don’t. The choices: Enabled; Disabled. IPPC-9151 Series Users Manual...

  • Page 93: Integrated Peripherals

    PCI Delay Transaction Leave this field at default. The choice: Enabled, Disabled. PCI Master 0 WS Write When Enabled, writes to the PCI bus are executed with zero wait states. The choice: Enabled, Disabled. PCI # 2 Access # 1 Retry Leave this field at default.
  • Page 94 IDE interface. The choices: Enabled; Disabled. IDE Prefetch Mode The on-board IDE drive supports IDE prefetching for faster drive accesses. If the IDE device doesn’t support prefetching, set this field to Disabled. The choices: Enabled; Disabled. IPPC-9151 Series Users Manual...
  • Page 95 Primary Master / Slave PIO & Secondary Master / Slave PIO Choose Auto or Mode 0~4. The BIOS will detect the HDD mode type automatically when you choose Auto. You need to set to a lower mode than Auto when your hard disk becomes unstable. The choices: Auto;...
  • Page 96 • SB I/O Base Address • SB IRQ Select • SB DMA Select • MPU-401 • MPU-401 I/O Address • Game Port (200-207H) Press <ESC> to return to the Main Menu when you finish setting up all items. IPPC-9151 Series Users Manual...

  • Page 97: Power Management Setup

    10.6 Power Management Setup POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as follows: Choose“Integrated Peripherals”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys.
  • Page 98 Always On Monitor will remain on during power saving modes. Monitor blanked when the systems enters the Suspend ! Off Suspend mode. Monitor blanked when the system enters either All Modes ! Off Suspend or Standby modes. IPPC-9151 Series Users Manual...
  • Page 99 Video Off Method This determines the manner in which the monitor is blanked. This selection will cause the system to turn off the vertical V/H SYNC + Blank and horizontal synchronization ports and write blanks to video buffer. Blank Screen This option only writes blanks to the video buffer.
  • Page 100 Disabled IRQ-11 (Reserved) Disabled IRQ-12 (PS/2 Mouse) Enabled IRQ 13 (Coprocessor) Disabled IRQ 14 (Hard Disk) Enabled IRQ 15 (Reserved) Disabled Press <ESC> to return to the Main Menu when you finish setting up all items. IPPC-9151 Series Users Manual...

  • Page 101: Pnp/Pci Configuration

    10.7 PnP/PCI Configuration PnP/PCI Configuration allows you to modify the system’s power saving functions. Run the PnP/PCI Configuration as follows: Choose“PnP/PCI Configuration”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys.
  • Page 102 Select Enabled if you system has a USB controller and you have one or more USB devices connected. If you are not using your system’s USB controller, select Disabled to free the IRQ resource. Press <ESC> to return to the Main Menu when you finish setting up all items. IPPC-9151 Series Users Manual...

  • Page 103: Pc Health Status

    10.8 PC Health Status This section helps you to get more information about your system includ- ing CPU temperature, FAN speed and voltage. It is recommended that you contact your mainboard supplier to get proper values about the set- ting of the CPU temperature. Run the PC Health Status as follows: Choose“PC Health Status”from the Main Menu and a list of options will appear.

  • Page 104: Frequency/Voltage Control

    “ Load Optimized Defaults (Y/N) ? N ” “Y” is for “Yes”, and “N” is for “No”. Pressing “Y” loads the BIOS default values that are factor settings for optimal performance of system operations. IPPC-9151 Series Users Manual...

  • Page 105: Set Password

    10.11 Set Password These option allows you to set your system passwords. The way to set up the password is as follows: Choose “Change Password” in the Main Menu and press <Enter>. Then following message appears: “Enter Password : “ The first time you run this option, enter your password up to 8 char- acters and press <Enter>.

  • Page 106: Save & Exit Setup

    Main Menu and the following message appears: “Quit Without Saving (Y/N) ? N “ “Y” is for “Yes”, and “N” is for “No”. You may change the prompt to “Y” and press <Enter> key to leave this option . IPPC-9151 Series Users Manual...
  • Page 107 LCD Specifications and Selection Settings...

  • Page 108: Appendix A Lcd Specifications

    However, it may con- tain a few defective pixels which may not always illuminate. With current technology, it is impossi- ble to completely eliminate defective pixels. Advantech is actively working to improve this technology. IPPC-9151 Series Users Manual...
  • Page 109 Pin Assignments...

  • Page 110: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 ATX Power connector 1 (CN1) Table B.1: AT Power connector 1 (CN1) Signal Signal 3.3V 3.3V 3.3V -12V PS-ON PW-OK 5VSB PPC-154 User’s Manual...

  • Page 111: Atx Power Connector 2 (Cn2)

    B.2 ATX power connector 2 (CN2) Table B.2: ATX power connector 2 (CN2) Signal Signal B.3 LVDS connector 1(CN4) Table B.3: LVDS connector 1(CN4) Signal Signal RXIN2+ RXIN2- RXIN1+ RXIN3+ RXIN1- RXIN3- RXIN0+ CLK0+ RXIN0- CLK0- DDC_CLK DDC_DAT Appendix B...

  • Page 112: Lvds Connector 2(Cn6)

    B.4 LVDS connector 2(CN6) Table B.4: Table B.4: LVDS connector 2 (CN6) Signal Signal RXIN6+ RXIN6- RXIN5+ CLK1+ RXIN5- CLK1- RXIN4+ RXIN7+ RXIN4- RXIN7- CONTRAST HPLG_DT B.5 Inverter power connector (CN5) Table B.5: Inverter power connector (CN5) Signal +12V ENABKL Brightness Adj.

  • Page 113: Fdd Connector (Cn9)

    B.6 FDD connector (CN9) Table B.6: FDD connector (CN9) Signal Signal Vcc(+5V) Step Index Vcc(+5V) Write data Drive select Vcc(+5V) Write enable Disk change Track 0 Write protect Motor on Read data Direction Density select Side 1 select Appendix B...

  • Page 114: Internal Speaker Connector (Cn15)

    B.7 Internal speaker connector (CN15) Table B.7: Internal speaker connector (CN15) Signal Speaker out_R - Speaker out_R + Speaker out_L + Speaker out_L - B.8 IR connector (CN24) Table B.8: IR connector (CN24) Signal IR_IN IR_OUT B.9 Fan power connector (FAN1 & FAN2) Table B.9: Fan power connector (FAN1 &...
