- Page 1 User Manual IPPC-9151G Rugged Industrial Panel PC with Intel® Core™ i7/i5/i3 Celeron and 15" XGA TFT LCD LED Backlight and One PCIE Slot IPPC-9171G Rugged Industrial Panel PC with Intel® Core™ i7/i5/i3 Celeron and 17" SXGA TFT LCD LED Backlight and One PCIE Slot...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
-
Page 4: Declaration Of Conformity
Technical Support and Assistance Visit the Advantech web site at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 IPPC-9151G/9171G User Manual...
-
Page 7: Table Of Contents
Dimensions ....................4 Figure 1.1 IPPC-9151G Dimensions ........... 4 Figure 1.2 IPPC-9171G Dimensions ........... 5 Chapter System Setup ........7 A Quick Tour of IPPC-9151G/9171G ............8 2.1.1 Installing CPU ................9 2.1.2 Installing Memory................ 11 2.1.3 Installing PCIe Card ..............12 2.1.4... - Page 8 Boot Setting .................... 44 Security Setting..................45 Save & Exit ..................... 46 Chapter Installing API Software ..... 47 Brightness Control Software (SUSI) ............48 4.1.1 Installing SUSI Software ............. 48 4.1.2 Adjust LCD Brightness with SUSI..........50 IPPC-9151G/9171G User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter provides a general description of the IPPC-9151G/ 9171G. Sections include: Introduction Specifications Dimensions... -
Page 10: Introduction
Introduction The IPPC-9151G/9171G industrial panel PC is especially designed to fit in space-lim- ited environments where expansion is restricted.Its solid structure enables systems to operate under harsh industrial conditions. Sturdy structure The whole system is protected by a firm solid structure. The front panel is made of sturdy aluminum. -
Page 11: Standard Pc Functions
HD HDMI interface: Supports one standard HDMI port LVDS: Default LVDS – - IPPC-9151G: Supports 1024 * 768, 24bit – - IPPC-9171G: Supports 1280 * 1024, 48bit Universal serial bus (USB) port: Supports five USB (version 2.0) ports, four one the rear panel and one on the front panel 1.2.4... -
Page 12: Dimensions
Certifications: CE, CCC, FCC Class A; meets UL, BSMI Dimensions Panel Cut-out Dimension: 404 mm (15.90") x 292 mm (11.49") Figure 1.1 IPPC-9151G Dimensions IPPC-9151G/9171G User Manual... -
Page 13: Figure 1.2 Ippc-9171G Dimensions
Panel Cut-out Dimension: 447 mm (17.618") x 329.50 mm (12.972") Figure 1.2 IPPC-9171G Dimensions IPPC-9151G/9171G User Manual... - Page 14 IPPC-9151G/9171G User Manual...
-
Page 15: Chapter 2 System Setup
Chapter System Setup This chapter details system setup for the IPPC-9151G/9171G Series. Sections include: A Quick Tour of IPPC-9151G/ 9171G Installing CPU Installing Memory Card Installing PCIe Card Installing CFast Card Installing HDD Mounting Instructions... -
Page 16: A Quick Tour Of Ippc-9151G/9171G
A Quick Tour of IPPC-9151G/9171G Before you start the computer, please follow these procedures to set up the system. Connect the wires, cables and accessories. Mount the computer. Install an operating system. Warning! Switch off and unplug the computer every time you access its inte- rior. -
Page 17: Installing Cpu
2.1.1 Installing CPU Unplug power cable of CPU fan. Loosen four screws and take off CPU fan. IPPC-9151G/9171G User Manual... - Page 18 Take thermal grease out of the accessary box and apply evenly on CPU. Insert CPU into the socket (pay attention to the direction of both). Fasten the screws with screwdriver to secure the CPU. IPPC-9151G/9171G User Manual...
-
Page 19: Installing Memory
Re-install the CPU's cooling fan & then attach CPU fan power cable. 2.1.2 Installing Memory Pull the two white eject levers of the ends of the memory socket. Note: select the first socket (DIMMA) if you only want to insert one memory card. IPPC-9151G/9171G User Manual... -
Page 20: Installing Pcie Card
Push the two eject levers toward the vertical posts at each end of the socket until the module is upright. 2.1.3 Installing PCIe Card Remove the screws on PCI cover, then insert PCIe card and fasten the screws. IPPC-9151G/9171G User Manual... -
Page 21: Installing Cfast Card
2.1.4 Installing CFast Card Detach the two screws of CFast cover, then take off the cover. Insert CFast card (notice the direction of the CFast card), (the interior slot), then replace the cover. IPPC-9151G/9171G User Manual... -
Page 22: Installing Hdd
2.1.5 Installing HDD Remove four screws and remove the HDD bracket. Take four M3 screws out of the accessary box and insert HDD into HDD bracket (pay attention to the direction of HDD). IPPC-9151G/9171G User Manual... - Page 23 Put the HDD bracket into the chassis and fasten the four screws. Then attach the HDD flat cable and power cable. IPPC-9151G/9171G User Manual...
-
Page 24: Installing Ps/2 Mouse And Keyboard
An external USB device may be connected to the system via the 4 USB ports located on the bottom side of the system unit and one on the front panel.The USB ports sup- port hot plug-in connection.For high-power USB device, use an external power sup- ply. IPPC-9151G/9171G User Manual... -
Page 25: Ethernet
2.1.13 Connecting Power Cord Remove the power cord bracket, then plug in the standard power cord. Replace the bracket and fasten the screws. Note: Pay attention to the input voltage of the power supply. IPPC-9151G/9171G User Manual... -
Page 26: Ground Connection
2.1.14 Ground Connection For the safety of the operator and the device, connect the ground wire. Location of the ground wire: 2.1.15 ATX Power On Switch IPPC-9151G/9171G User Manual... -
Page 27: Mounting Instructions
Attach the four mounting brackets by inserting the screws into the keyhole slots on the cover of the monitor. Use the screws to secure the brackets to the cover. Tighten the screws to secure the monitor to the back panel. Note! Panel's maximum thickness is 5 mm. IPPC-9151G/9171G User Manual... -
Page 28: Rack Mounting
2.2.2 Rack Mounting IPPC-9151G users can optionally order 19" industrial rack mounting kit. The part number is IPPC-9151G-R1MKE. IPPC-9171G can be directly mounted to a 19" industrial rack. Remove the rubber on the panel. IPPC-9151G/9171G User Manual... -
Page 29: Jumper Settings And Connectors
Linear brightness control 1 and 2 PWM brightness control (default) 2 and 3 2.3.4 JLVDS1 Power Selector - IPPC-9151G: Default 4-6, 3.3 V - IPPC-9171G: Default 2-4, 5 V Close Pins Result JLVDS1 For jumpers of 5 V LVDS panel For jumpers of 3.3V LVDS panel... -
Page 30: Cpu Fan Connector (Cpu_Fan1)
If a fan is used, this connector supports cooling fans of 500 mA (6 W) or less. 2.3.6 System Fan Connector (SYSFAN1/2) Note! System fan has no signal detection, so the fan speed will not show in CMOS. IPPC-9151G/9171G User Manual... -
Page 31: Pwrsw (Power Switch Connector)
If your computer case is equipped with an ATX power supply, you should connect the power on/off button on your computer case to (JFP1/ PWR_SW). 2.3.8 SATA Interface The blue one is for SATA 3.0 interface(1.2), the black one is for SATA2.0 inter- face(3.4). IPPC-9151G/9171G User Manual... -
Page 32: Atx Power Connector (Eatxpwr1, Atx12V1)
Default: SATA1 for HDD SATA2 for CFast board. 2.3.9 ATX Power Connector (EATXPWR1, ATX12V1) IPPC-9151G/9171G User Manual... -
Page 33: Display Backlight Connector (Inv1)
2.3.10 Display Backlight Connector (INV1) 2.3.11 LVDS Port (LVDS1) IPPC-9151G/9171G User Manual... -
Page 34: Gpio Port (Gpio1)
2.3.12 GPIO Port (GPIO1) 2.3.13 PCIe Slot Note! Intel QM67 chipset supports PCIe x16 slot (Gen 2.0), but it still has some compatibility issues with certain interface cards. IPPC-9151G/9171G User Manual... -
Page 35: Chapter 3 Bios Setup
Chapter BIOS Setup... -
Page 36: Bios Introduction
BIOS Introduction IPPC-9151G/9171G has AMI EFI 64 Mbit SPI BIOS, with a CMOS SETUP utility that allows users to configure required settings or to activate certain system features. When the power is turned on, pressing the <Del> button or F2 will take you to the CMOS SETUP screen.Functions of the control keys in CMOS screen:... -
Page 37: Advanced Bios Features
Advanced BIOS Features 3.3.1 ACPI Settings IPPC-9151G/9171G User Manual... -
Page 38: Cpu Configuration
The default setting is “Enabled”. Hardware Prefetcher [Enabled] Hardware detection. The default setting is “Enabled”. Adjacent Cache Line Prefetch [Enabled] This item allows users to enable or disable the adjacent cache line prefetcher feature. The default setting is “Enabled”. IPPC-9151G/9171G User Manual... -
Page 39: Sata Configuration
SATA mode cannot be selected if this item is disabled. SATA Mode Selection SATA Mode Selection. The default setting is “IDE”. It can be configured as other mode (IDE AHCI RAID) if required. Serial ATA Port Serial ATA Port displays all connected HDDs. IPPC-9151G/9171G User Manual... -
Page 40: Amt Configuration
This item allows users to enable or disable Intel AMT password write. The default setting is “Enabled”. AMT Wait Time Set waiting time to enter AMT to 0.The default setting of ASF is “Enabled”.ASF is short for Advanced Streaming Format. IPPC-9151G/9171G User Manual... -
Page 41: Usb Configuration
Device reset time-out[20sec] The default time interval is 20 seconds. The other options include 10sec, 20sec, 30sec and 40sec. Device power-up delay [auto] The default setting is “Auto”. The user can choose “Auto” or “Manual”. IPPC-9151G/9171G User Manual... -
Page 42: Nct3776F Super Io Configuration
NCT3776F Super IO Configuration COM1, COM2 Port Configuration Serial Port1 Configuration COM1 port address configuration Serial Port [Enabled] The default setting is “Enabled”.COM1 address: 3F8h;IRQ=4. Charge Settings [AUTO] The user can change COM1 address as required. IPPC-9151G/9171G User Manual... - Page 43 COM2 address: 2F8h;IRQ=3. Charge Settings [AUTO] The user can change COM2 address as required. Device Mode [Standard Serial Port Mode] The default setting is “Standard Serial Port Mode”.Ths user can change to other modes as required. IPPC-9151G/9171G User Manual...
-
Page 44: H/W Monitor
CPU Warning Temperature [Disabled] This item allows you to set CPU warning temperature. The default setting is “Disabled”. ACPI Shutdown Temperature [Disabled] This item allows you to set ACPI Shutdown Temperature. The default setting is “Disabled”. IPPC-9151G/9171G User Manual... -
Page 45: F81216 Super Io Configuration
3.3.8 F81216 Super IO Configuration COM3 and COM4 configuration. IPPC-9151G/9171G can support four COM ports. Serial Port 3 Configuration COM3 Setting. This user can change COM3 address as required. The default setting is “Auto”. Serial Port 4 Configuration COM4 port address configuration.Ths user can change COM4 address as... -
Page 46: Chipset
Chipset Chipset Configuration Setting 3.4.1 System Agent (SA) Configuration 3.4.1.1 Graphics Configuration IPPC-9151G/9171G User Manual... - Page 47 This item allows users to select LFP configuration. The default setting is LVDS. VBIOS Default values are neither 24 bit nor 48 bit. Choosing “VBIOS Default“ will result in blurred screen. It’s recommended to use the default LVDS. IPPC-9151G/9171G User Manual...
-
Page 48: Nb Pcie Configuration
The default setting is “Disabled”. Users can enable this item when needed. PEG ASPM [Disabled] Active State Power Management. Power management solution supported by WIN7 and VISTA. Power saving mode will be used when the device (PCI Express) is idle.The default setting is “Disabled”. IPPC-9151G/9171G User Manual... -
Page 49: Lan Ports Setting
3.4.3 LAN Ports Setting LAN1 Controller [Enabled] The default setting of LAN1 port is “Enabled”. LAN1 Option-ROM [Disabled] The default setting is “Disabled”. Wake on LAN1 from S5[Disabled] The default setting is “Disabled”. IPPC-9151G/9171G User Manual... - Page 50 SLP-S4 Assertion Width[4-5 Seconds] SLP (Software Licensing and Protection) SLP detection uses 4-5 seconds. Restore AC Power-Loss [Power Off] The computer will not restart when AC power is restored after power-loss. The user can this the setting if required. IPPC-9151G/9171G User Manual...
-
Page 51: Usb Configuration
3.4.4 USB Configuration The default setting off EHCI1 is “Enabled”. The default setting off EHCI2 is “Enabled”. USB Ports Per-Port Disabled Control [Disabled] The default setting is “Disabled”. IPPC-9151G/9171G User Manual... -
Page 52: Boot Setting
When “ON”, the keyboard NumLock state will stay “ON” after booting. The default setting is “ON”. This user can change the setting as required. Option ROM Messages [force BIOS] The default setting is “force BIOS”. Interrupt 19 Capture [Disabled] The default setting is “Disabled”. IPPC-9151G/9171G User Manual... -
Page 53: Security Setting
Show different boot device choices. Hard Drive BBS Priorities Select the main hard disk device type to be a boot hard drive. Security Setting Administrator Password Set the Administrator password. User Password Set the User password. IPPC-9151G/9171G User Manual... -
Page 54: Save & Exit
Discard Changes and Exit Setup Now? Select “OK” or “Cancel”. Restore Default The BIOS automatically configures all setup items to optimal settings when users select this option. Save as User Defaults Save the all current settings as a user default. Restore User Defaults IPPC-9151G/9171G User Manual... -
Page 55: Installing Api Software
Chapter Installing API Software... -
Page 56: Brightness Control Software (Susi)
Brightness Control Software (SUSI) 4.1.1 Installing SUSI Software (SUSI software can be downloaded from our advantech website.) Click “Setup” to install SUSI software. Click “Next”. Select “I accept the terms of the license agreement”, then click “Next”. IPPC-9151G/9171G User Manual... - Page 57 Click “Install”. Select “Yes, i want to restart my computer now” and click “Finish”. IPPC-9151G/9171G User Manual...
-
Page 58: Adjust Lcd Brightness With Susi
4.1.2 Adjust LCD Brightness with SUSI Launch SUSI software. The following screen appears: IPPC-9151G/9171G User Manual... - Page 59 Drag the slider with the mouse or click Up/Down button to adjust the brightness of LVDS display. Note! For IPPC-9151G, the lower the slider is, the brighter LVDS display will be. For IPPC-9171G, the lower the slider is, the darker LVDS display will be.
- Page 60 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2011...
