IPPC-7157 Series
15" XGA TFT LCD Pentium D/
Pentium 4/ Celeron D Industrial
Panel PC with 7 x PCI/PCIe Slots
and Membrane Keypad
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPPC-7157 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech IPPC-7157 Series

Summary of Contents for Advantech IPPC-7157 Series

  • Page 1 IPPC-7157 Series 15" XGA TFT LCD Pentium D/ Pentium 4/ Celeron D Industrial Panel PC with 7 x PCI/PCIe Slots and Membrane Keypad User Manual...
  • Page 2 Copyright notice This document is copyrighted 2007, by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 3 FCC Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environ- ment.
  • Page 4 • 1 x IPPC-7157 Workstation • 1 x Accessory Box, with: • CD ROM for IPPC-7157 Series DRV • Registration and 2 year Warranty card • Startup manual of AIMB-762 mother board •...
  • Page 5 Additional Information and Assistance Step 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Step 2. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance.
  • Page 6 Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.

  • Page 7: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Specifications ..............3 1.2.1 General ................3 1.2.2 System Hardware ............3 1.2.3 LCD Display ..............4 1.2.4 Touchscreen (Optional) ..........4 1.2.5 Environment ..............5 Dimensions................ 5 Chapter 2 System Setup............ 8 A Quick Tour of IPPC-7157 ..........
  • Page 8 Frequency/Voltage Control ..........59 4.10 Load Optimized Defaults ..........60 4.11 Set Password ..............60 4.12 Save & Exit Setup ............61 4.13 Exit Without Saving ............61 Appendix A LCD Specifications........64 IPPC-7157 LCD Specifications ........64 Appendix B Pin Assignments ..........66 ATX Power Connector 1 (CN1) ........
  • Page 9 General Information This chapter gives background information on the IPPC-7157 series Sections include: • Introduction • Specifications • Dimensions...

  • Page 10: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction The IPPC-7157 is an all new designed workstation with 15" TFT LCD and 7 expansion slots. With the new ID Design, IPPC-7157 will be a brand new front panel workstation from existed AWS series.The IPPC- 7157 support ATX industrial mother board and standard motherboard.

  • Page 11: Specifications

    1.2 Specifications 1.2.1 General • Button Control: Membrane Keypad 1: 43 operating keys Membrane Keypad 2: 10 programmable macro function keys • BIOS: Award™ 8 Mbit FWH • Certifications: BSMI, CCC, CE, FCC • Cooling System: 1 x 49 CFM fan w/50,000 hrs MTBF •...

  • Page 12: Lcd Display

    • Keyboard/Mouse: 2 x PS/2 for mouse & keyboard interface • LAN: 2 x 10/100/1000Base-T • Memory: 4 x 240-pin Dual ch DDR2 DIMM sockets (Up to 4 GB, Clock 266) • Parallel Port: 1 x enhanced parallel port Supports SPP/EPP/ECP parallel mode. BIOS configurable to LPT1, LPT2, LPT3 or disabled •...

  • Page 13: Environment

    1.2.5 Environment • Humidity: 5 ~ 85% RH @ 40° C (non-condensing) • Ingress Protection: Front panel NEMA4/IP65 • Operating Temperature: 0 ~ 50° C (32 ~ 122° F) • Storage Temperature: -20 ~ 60° C (-4 ~ 140° F) •...
  • Page 14 IPPC-7157 User Manual...
  • Page 15 System Setup This chapter details system setup for the IPPC-7157 Series. Sections include: • A Quick Tour of IPPC-7157 • Installing a CPU & CPU Cooler • Installing Optional Disk Drives • Rack Mounting...

  • Page 16: Chapter 2 System Setup

    Chapter 2 System Setup 2.1 A Quick Tour of IPPC-7157 Before you start the computer, please follow these procedures to set up the system. 1. Check and adjust jumpers on the motherboard (see Chapter 3) 2. Install SDRAM 3. Install CPU & CPU Cooler 4.

  • Page 17: Figure 2.1:Overviewview

    Figure 2.1: OverviewView Figure 2.2: Side View Chapter 2...

  • Page 18: Ps/2 Mouse And Keyboard

    2.1.1 PS/2 Mouse and Keyboard If you wish to use a full-size desktop keyboard and PS/2 mouse with your Workstation, follow these instructions: Be sure the workstation is turned off. Reattach the original 2 black PS/2 keyboard & mouse cables if they are already connected on the right side of the chassis.

  • Page 19: Serial Com Ports

    2.1.3 Serial COM Ports There are two serial COM ports on the I/O at the right side of worksta- tion. You can easily attach a serial device to the Workstation, such as an external modem or mouse. Follow these instructions: Make sure the Workstation and any other peripherial devices you may have connected to the Workstation are turned off.

  • Page 20: Ethernet

    2.1.6 Ethernet To install Ethernet for your system: 1. Connect the Ethernet cable. 2. Turn on the Workstation. 3. Run the Ethernet driver in the Mother Board Disc to connect up to the program: "E:\Drv_LAN\Intel 82573\Autorun.exe" 2.1.7 Adjusting the LCD Brightness The LCD OSD control key is located behind the front panel module, you have to open the front panel to access it.
  • Page 21 2.1.8 System On/Off The IPPC-7157 has 1 system on/off switch, located inside the chassis. Chapter 2...

  • Page 22: Installing A Cpu & Cpu Cooler

    2.2 Installing a CPU & CPU Cooler The CPU can be upgraded to improve system performance. The 7157 provides Socket 478 architecture which supports Pentium 4 CPU up to 2.8 GHz, and Celeron up to 2.5 GHz. While installing or upgrading the CPU, CPU cooler must be correctly removed.

  • Page 23: Installing Optional Disk Drives

    2.3 Installing Optional Disk Drives The IPPC-7157 provides spaces for two 3.5" hard disk drives, one CD- ROM drive, & one 3.5" floppy disk drive within the chassis. Front-facing FDD & CD-ROM have already been installed. You can access them after opening the front LCD panel.
  • Page 24 IPPC-7157 User Manual...
  • Page 25 Touchscreen This chapter contains information on the touchscreen, its installation and configuration. Sections include: • Introduction • Installing Windows 2000/X Drivers • Configuring PenMount Drivers • Uninstalling PenMount Drivers...

  • Page 26: Chapter 3 Touchscreen

    Chapter 3 Touchscreen 3.1 Introduction The IPPC-7157 Series’ optional touchscreen uses advanced 8-wire resis- tive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards.
  • Page 27 When the system first detects the controller board, a screen appears that shows “Unknown Device.” Do not use this hardware wizard. Press Cancel. Find the Setup.exe in the PenMount Universal Driver Folder: "D:\Touchscreen Drivers\PenMount Windows Universal Driver V1.0.1018_v1.0.0.2Beta" Appendix 3...
  • Page 28 The screen displays the installation wizard for the PenMount soft- ware. Click “Next”. A License Agreement appears. Click “I accept…” and then proceed to next step.” The “Ready to Install the Program” screen appears. Select “Install.” IPPC-7157 User Manual...
  • Page 29 If a pop-up windows shows “Hardware Installation.” Select “Con- tinue Anyway” then proceed. The “InstallShield Wizard Completed” appears. Click “Finish.” Appendix 3...

  • Page 30: Configuring Penmount Drivers

    3.3 Configuring PenMount Drivers Upon rebooting, the computer automatically finds the new 9000 control- ler board. The touch screen is connected but not calibrated. Follow the procedures below to carry out calibration. After installation, click the PenMount Monitor icon “PM” in the menu bar.
  • Page 31 NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Appendix 3...
  • Page 32 IPPC-7157 User Manual...
  • Page 33 Plot Check this function and a touch panel linearity com- Calibration parison graph appears when you have finished Data Advanced Calibration. The blue lines show linearity before calibration and black lines show linearity after calibration. Appendix 3...
  • Page 34 Draw Tests or demonstrates the PenMount touch screen operation. The display shows touch location. Click Draw to start. Touch the screen with your fin- ger or a stylus and the drawing screen registers touch activity such left, right, up, down, pen up, and pen down. Touch the screen with your finger or a stylus and the drawing screen reg- isters touch activity such left, right, up, down, pen up, and pen down.
  • Page 35 Multiple Monitors Multiple Monitors supports from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
  • Page 36 When the mapping screen message appears, click OK. Touch each screen as it displays “Please touch this monitor.” Fol- lowing this sequence and touching each screen is called mapping the touch screens. IPPC-7157 User Manual...
  • Page 37 Touching all screens completes the mapping and the desktop reap- pears on the monitors. Select a display and execute the ‘Calibration’ function. A message to start calibration appears. Click OK. “Touch this screen to start its calibration” appears on one of the screens.
  • Page 38 Note: 1. If you used a single VGA output for multiple monitors, please do not use the Multiple Monitors function. Just follow the regular procedure for calibration on each of your desktop monitors. 2. The Rotating function is disabled if you use the Multiple Monitors function.

  • Page 39: Penmount Monitor Menu Icon

    About This panel displays information about the PenMount controller and driver version. 3.3.2 PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP when you turn on PenMount Monitor in PenMount Utilities. PenMount Monitor has the following functions. Beep Turns beep on or off.

  • Page 40: Penmount Rotating Functions

    3.3.3 PenMount Rotating Functions The PenMount driver for Windows 2000/XP supports several display rotating software packages. Please see Chapter 5 for more information. The PenMount drivers for Windows 95, Windows 98/Me, Windows 2000/XP, as well as Windows 98 USB and Windows Me/2000/XP sup- port display rotating software packages such as: •...

  • Page 41: Uninstalling Penmount Drivers

    3.4 Uninstalling PenMount Drivers Exit the PenMount monitor (PM) in the menu bar. Go to Settings, then Control Panel, and then click Add/Remove program. Select PenMount Universal Driver 1.0 and click the Remove button.. Select ‘Yes’ and “Close” to remove the PenMount Universal Driver, and reboot the system.
  • Page 42 IPPC-7157 User Manual...
  • Page 43 Award BIOS Setup This chapter details the Award BIOS Setup. Sections include: • Award BIOS Setup • CMOS Setup Utility • Advanced BIOS Features • Advanced Chipset Features • Integrated Peripherals • Power Management Setup • PnP/PCI Configuration • PC Health Status •...

  • Page 44: Chapter 4 Award Bios Setup

    This is because the BIOS is revised and updated from time to time. If in doubt, check Advantech's website for the latest BIOS versions and related information. 4.2 CMOS Setup Utility A setup program, built into the system BIOS, is stored in the CMOS RAM that allows the configuration settings to be changed.

  • Page 45: Standard Cmos Setup

    Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Optimized Defaults Advanced Chipset Features Set Password Integrated Peripherals Save & Exit Setup Power Management Setup Exit without Saving PnP/PCI Configurations Esc : Quit ↑↓→← : Select Item F10 : Save & Exit Setup Time, Date, hard disk Type…...

  • Page 46: Figure 4.2:Standard Cmos Features

    Date (mm:dd:yy) The BIOS determines the day of the week from the other date informa- tion. This field is for information only. Press the left or right arrow key to move to the desired field (date, month, year). Press the PgUp or PgDn key to increment the setting, or type the desired value into the field.
  • Page 47 Video Select the type of primary video subsystem in your computer. The BIOS usually detects the correct video type automatically. The BIOS supports a secondary video subsystem, but you do not select it in setup. Halt On During the power-on self-test (POST), the computer stops if the BIOS detects a hardware error.

  • Page 48: Advanced Bios Features

    Total Memory This option shows system memory capacity. Press <ESC> to return to the Main Menu when you finish setting up all items. 4.3 Advanced BIOS Features Advanced BIOS Features improves your system performance or sets up system features according to your preference. Run the ADVANCED BIOS FEATURES as follows: Choose“Advanced BIOS Features”from the Main Menu and a screen with a list of options will appear.
  • Page 49 Virus Warning When enabled, you receive a warning message if a program (specifically, a virus) attempts to write to the boot sector or the partition table of the hard disk drive. You should then run an antivirus program. Keep in mind that this feature protects only the boot sector, not the entire hard drive.
  • Page 50 First/Second/Third/Other Boot Device The BIOS attempts to load the operating system from the devices in the sequence selected in these items. The choices: Floppy; LS/ZIP; HDD; SCSI; CDROM; Disabled. Swap Floppy Drive When enabled, floppy drives A and B will be exchanging without any physical connection and modification on the cables.
  • Page 51 Typematic Rate (Chars / Sec) When the typematic rate setting is enabled, you can select a typematic rate (the rate at which character repeats when you hold down a key) of 6, 8, 10, 12, 15, 20, 24, or 30 characters per second. Typematic Delay (Msec) Choices: 250;...

  • Page 52: Advanced Chipset Features

    4.4 Advanced Chipset Features Advanced Chipset Features is used to modify the values of chipset buff- ers. These buffers control the system options. Run the Advanced Chipset Features as follows: 1. Choose “Advanced Chipset Features” from the Main Menu and a list of options will appear.
  • Page 53 SDRAM Cycle Length Select CAS latency time in HCLKs of 2 or 3. The system designer already set the values. Do not change the default value unless you change specifications of the installed DRAM or the installed CPU. Bank Interleave Please use default setting.
  • Page 54 AGP– 4X Mode This item allows you to enable AGP-4X mode. The choices are: Dis- abled, Enabled AGP Driving Control This item allows you to adjust the AGP driving force. Choose Manual to key in a AGP Driving Value in the next selection. This field is recom- mended to set in Auto for avoiding any error in your system.
  • Page 55 CPU to PCI Write Buffer When this field is Enabled, writes from the CPU to the PCI bus are buff- ered, to compensate for the speed differences between the CPU and the PCI bus. When Disabled, the writes are not buffered and the CPU must wait until the write is complete before starting another write cycle.

  • Page 56: Integrated Peripherals

    4.5 Integrated Peripherals Integrated Peripherals option allows you to get some information inside your system when it is working. Run the INTEGRATED PERIPHERALS as follows: Choose“Integrated Peripherals”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys.
  • Page 57 OnChip IDE Channel 0/1 The chipset contains a PCI IDE interface with support from two IDE channels. Select Enabled to activate the first and/or the second IDE inter- face. Select Disabled to inactivate an interface if you install a primary and/or second add-on IDE interface.
  • Page 58 Onboard FDD Controller Select Enabled if your system has a floppy drive controller (FDC) install- ing in the system board and you want to use it. If you install add-in FDC or the system has no floppy drive, select Disabled in this field. The choices: Enabled;...
  • Page 59 Onboard Paralle Mode Select an operating mode for the onboard parallel (printer) port. Select Normal, Compatible, or SPP unless you are certain your hardware and software both support one of the other available modes. The choices: SPP; EPP; ECP; ECP + EPP. ECP Mode Use DMA Select a DMA channel for the parallel port for use during ECP mode.

  • Page 60: Power Management Setup

    4.6 Power Management Setup POWER MANAGEMENT SETUP allows you to set the system’s power saving functions. Run the POWER MANAGEMENT SETUP as follows: Choose“Integrated Peripherals”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys.
  • Page 61 • Power Management: This option allows you to select the type (or degree) of power saving for Doze, Standby, and Suspend modes. This table describes the power management modes for your reference: Maximum power savings. Only Available for SL CPUs. Max Saving Inactivity period is 1 minute in each mode.
  • Page 62 Video Off Method This determines the manner in which the monitor is blanked. This selection will cause the system to turn off the vertical V/H SYNC + Blank and horizontal synchronization ports and write blanks to video buffer. Blank Screen This option only writes blanks to the video buffer.
  • Page 63 • HDD & FDD: When HDD & FDD is ON, any activity from one of the listed system peripheral devices wakes up the system. • PCI Master: When PCI Master is ON, any activity from one of the listed system peripheral devices wakes up the system. •...

  • Page 64: Pnp/Pci Configuration

    4.7 PnP/PCI Configuration PnP/PCI Configuration allows you to modify the system’s power saving functions. Run the PnP/PCI Configuration as follows: Choose“PnP/PCI Configuration”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys.
  • Page 65 IRQ Resources Press Enter. Please refer to the list below: Ite m H e lp IR Q - 9 a s s i g n e d to P C I/ IS A P n P M e n u L e v e l DMA Resources Press Enter.

  • Page 66: Pc Health Status

    4.8 PC Health Status This section helps you to get more information about your system includ- ing CPU temperature, FAN speed and voltage. It is recommended that you contact your mainboard supplier to get proper values about the set- ting of the CPU temperature. Run the PC Health Status as follows: Choose“PC Health Status”from the Main Menu and a list of options will appear.

  • Page 67: Frequency/Voltage Control

    4.9 Frequency/Voltage Control Run the Frequency/Voltage Control as follows: Choose“Frequency/Voltage Control”from the Main Menu and a list of options will appear. Use one of the arrow keys to move between options and modify the selected options by using PgUp / PgDn / + / - keys. A u to D e c t D IM M / P C I C lk E n a b le d Ite m H e lp...

  • Page 68: Load Optimized Defaults

    4.10 Load Optimized Defaults When you press <Enter> on this item, you will get a confirmation dialog box with a message similar to: “ Load Optimized Defaults (Y/N) ? N ” “Y” is for “Yes”, and “N” is for “No”. Pressing “Y”...

  • Page 69: Save & Exit Setup

    4.12 Save & Exit Setup Save & Exit Setup allows you to save all modifications you have speci- fied into the CMOS memory. Highlight this option on the Main Menu and the following message appears: “Save to CMOS and Exit (Y/N) ? Y “ “Y”...
  • Page 70 IPPC-7157 User Manual...
  • Page 71 LCD Specifications and Selection Settings...

  • Page 72: Appendix A Lcd Specifications

    However, it may con- tain a few defective pixels which may not always illuminate. With current technology, it is impossi- ble to completely eliminate defective pixels. Advantech is actively working to improve this technology. IPPC-7157 User Manual...
  • Page 73 Pin Assignments...

  • Page 74: Appendix B Pin Assignments

    Appendix B Pin Assignments B.1 ATX Power Connector 1 (CN1) Table B.1: AT Power connector 1 (CN1) Signal Signal 3.3V 3.3V 3.3V -12V PS-ON PW-OK 5VSB IPPC-7157 User Manual...

  • Page 75: Atx Power Connector 2 (Cn2)

    B.2 ATX Power Connector 2 (CN2) Table B.2: ATX power connector 2 (CN2) Signal Signal B.3 LVDS Connector 1(CN4) Table B.3: LVDS connector 1(CN4) Signal Signal RXIN2+ RXIN2- RXIN1+ RXIN3+ RXIN1- RXIN3- RXIN0+ CLK0+ RXIN0- CLK0- DDC_CLK DDC_DAT Appendix B...

  • Page 76: Lvds Connector 2 (Cn6)

    B.4 LVDS Connector 2 (CN6) Table B.4: Table B.4: LVDS connector 2 (CN6) Signal Signal RXIN6+ RXIN6- RXIN5+ CLK1+ RXIN5- CLK1- RXIN4+ RXIN7+ RXIN4- RXIN7- CONTRAST HPLG_DT B.5 Inverter Power Connector (CN5) Table B.5: Inverter power connector (CN5) Signal +12V ENABKL Brightness Adj.

  • Page 77: Fdd Connector (Cn9)

    B.6 FDD Connector (CN9) Table B.6: FDD connector (CN9) Signal Signal Vcc(+5V) Step Index Vcc(+5V) Write data Drive select Vcc(+5V) Write enable Disk change Track 0 Write protect Motor on Read data Direction Density select Side 1 select Appendix B...

  • Page 78: Internal Speaker Connector (Cn15)

    B.7 Internal Speaker Connector (CN15) Table B.7: Internal speaker connector (CN15) Signal Speaker out_R - Speaker out_R + Speaker out_L + Speaker out_L - B.8 IR Connector (CN24) Table B.8: IR connector (CN24) Signal IR_IN IR_OUT B.9 Fan Power Connector (FAN1 & FAN2) Table B.9: Fan power connector (FAN1 &...

  • Page 79: Com1 Rs-232 Serial Port (Cn10)

    B.10 COM1 RS-232 serial port (CN10) Table B.10: COM1 RS-232 serial port (CN10) Signal Signal RI (RI/+5V/+12V) B.11 COM2 (CN11) Table B.11: COM2 (CN11) Signal RS-422 RS-485l DATA- DATA+ RI (RI/+5V/+12V) Appendix B...
  • Page 80 IPPC-7157 User Manual...
  • Page 81 Keyboard Translator...

  • Page 82: Appendix C Keyboard Translator

    Appendix C Keyboard Translator C.1 Overview The keyboard translator is an interface that switches the signal from the membrane keypad to the standard AT keyboard. There are six connectors on the board. On top of the board, there are two connectors linking two flat cables to the membrane keypad (as shown in Fig.

  • Page 83: Programming The Front Panel Macro Keys

    Caution: Keyboard Translator(KBT-2002) can't be programmed through the USB keyboard. The step of programming the Macro Key(M1~M10) on the front panel: Open the front panel door, use a PS/2 keyboard connect to the reserved external keyboard terminal of KBT-2002 which on the back of front panel (see figure below).
  • Page 84 C.3 Keyboard Translator Maintenance (KBT-2002) Below is the procedure of replacing the keyboard translator while needed: Switch off the power, and detach the main power cord. Unscrew the screws on front panel and open the front panel door of IPPC-7157. The Keyboard Translator will be located on the back of the front panel, behind the mylar protect.
