  • Page 1 IPPC-7158 Series 15" XGA TFT LCD Industrial Panel PC with 14 x ISA/PCI/ PICMG Slots, Passive Backplane and Membrane Keypad User Manual...
  • Page 2: Copyright Notice

    Copyright Notice This document is copyrighted 2008, by Advantech Co. Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to alter the products described in this manual at any time without notice. No part of this man- ual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech.
  • Page 3 FCC Class A Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environ- ment.
  • Page 4: Packing List

    Packing List Before setting up the system, check that the item is among those listed below and is in good condition. If your Workstation does not match any of those below, please contact your dealer immediately. • CD ROM for IPPC Series •...
  • Page 5 Additional Information and Assistance Step 1. Visit the Advantech web site at www.advantech.com where you can find the latest information about the product. Step 2. Contact your distributor, sales representative, or Advantech's cus- tomer service center for technical support if you need additional assistance.
  • Page 6: Safety Instructions

    Safety Instructions 1. Read these safety instructions carefully. 2. Keep this User's Manual for later reference. 3. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth. Do not use liquid or spray detergents for cleaning. 4. For plug-in equipment, the power outlet socket must be located near the equipment and must be easily accessible.
  • Page 7: Table Of Contents

    Contents Chapter 1 General Information ........2 Introduction ............... 2 Specifications ..............3 1.2.1 General ................3 1.2.2 System Hardware ............3 1.2.3 LCD Display ..............4 1.2.4 Touchscreen (Optional) ..........4 1.2.5 Environment ..............4 Dimensions................ 5 Chapter 2 System Setup............ 8 A Quick Tour of IPPC-7158 ..........
  • Page 8 IPPC-7158 User Manual viii...
  • Page 9 General Information This chapter gives background information on the IPPC-7158 series Sections include: • Introduction • Specifications • Dimensions...
  • Page 10: Chapter 1 General Information

    Chapter 1 General Information 1.1 Introduction The IPPC-7158 features a 15" TFT LCD and 14 expansion slots for PCI, PICMG and ISAand an ATX industrial backplane to support CPU cards. The IPPC-7158 also provides many powerful features such as detahable front panel, front-accessible USB port, 53 membrane key &...
  • Page 11: Specifications

    1.2 Specifications 1.2.1 General • Button Control: Membrane Keypad 1: 43 operating keys Membrane Keypad 2: 10 programmable macro function keys • Certifications: BSMI, CCC, CE, FCC • Cooling System: 1 x 49 CFM fan w/50,000 hrs MTBF • Dimensions (W x H x D): 482 x 354.8 x 162 mm (18.97"...
  • Page 12: Lcd Display

    1.2.3 LCD Display • Backlight Life: 60,000 hrs • Contrast Ratio: 500 : 1 • Display Size: 15" • Display Type: XGA TFT LCD • Luminance: 250 cd/m2 • Max. Colors: 16.2 M (RGB 6-bit + FRC data) • Max. Resolution: 1024x768 •...
  • Page 13: Dimensions

    1.3 Dimensions IPPC-7158A Delete Delete PgUp PgUp PgDn PgDn Back Back Space Space Enter Enter Ctrl Ctrl Shift Shift Space Space Left Left Right Right Figure 1.1: IPPC-7158 Dimensions Chapter 1...
  • Page 14 IPPC-7158 User Manual...
  • Page 15 System Setup This chapter details system setup for the IPPC-7158 Series. Sections include: • A Quick Tour of IPPC-7158 • Installing a CPU & CPU Cooler • Installing Optional Disk Drives • Rack Mounting...
  • Page 16: Chapter 2 System Setup

    Chapter 2 System Setup 2.1 A Quick Tour of IPPC-7158 Before you start the computer, please follow these procedures to set up the system. 1. Check and adjust jumpers on motherboard (optional by each CPU card) 2. Install SDRAM 3. Install CPU & CPU Cooler 4.
  • Page 17: Figure 2.1:Open View

    Figure 2.1: Open View Figure 2.2: Side View Chapter 2...
  • Page 18: Usb Ports

    2.1.1 USB Ports An external USB device may be connected to the system via the USB ports located on the right side of the system unit and also could access from 1 USB port on the front panel of IPPC-7158. Connect the external device to the system.
  • Page 19 2.1.3 System On/Off The IPPC-7158 has 1 system on/off switch, located inside the chassis. Chapter 2...
  • Page 20: Installing Optional Disk Drives

    2.2 Installing Optional Disk Drives The IPPC-7158 provides spaces for one 3.5" hard disk drives, one CD- ROM drive, & one 3.5" floppy disk drive within the chassis. Front-facing FDD & CD-ROM have already been installed. You can access them after opening the front LCD panel.
  • Page 21 Touchscreen This chapter contains information on the touchscreen, its installation and configuration. Sections include: • Introduction • Installing Windows 2000/XP Drivers • Configuring PenMount Drivers • Uninstalling PenMount Drivers...
  • Page 22: Chapter 3 Touchscreen

    Chapter 3 Touchscreen 3.1 Introduction The IPPC-7158 Series’ optional touchscreen uses advanced 8-wire resis- tive technology. It provides more accurate sensing capacity than other technologies. The touchscreen is specially designed for tough industrial environments, and has been approved to FCC Class B standards.
  • Page 23 LCD Specifications and Selection Settings...
  • Page 24: Appendix A Lcd Specifications

    However, it may con- tain a few defective pixels which may not always illuminate. With current technology, it is impossi- ble to completely eliminate defective pixels. Advantech is actively working to improve this technology. IPPC-7158 User Manual...
  • Page 25 Pin Assignments...
  • Page 26: Appendix B Pin Assignments

    Appendix B Pin Assignments Connector Description ISA1, ISA2 ISA Slot ISA3, ISA4 PICMG connector (PCI Slot is PICMG1, PICMG2) PICMG1, PICMG2 PICMG connector PPCI1~PPCI3 32 bit / 33 MHz PCI slot SPCI4~SPCI10 32 bit / 33 MHz PCI slot KB-In or KB-Out connector (90’P) KB2, KB3 KB-In or KB-Out connector (180’P) KB-Out, external connector...
  • Page 27: Connector Pin Definitions

    B.1 Connector Pin Definitions Definition +3.3V +3.3V Power OK +5VSB (Standby) +12V +3.3V -12V PS-ON KB1, KB2, KB3, KB4 Name KBCLK KBDATA KBGND KBVCC Appendix B...
  • Page 28 Name +12V -12V BIG1 Name +12V Name PS-ON 5VSB IPPC-7158 User Manual...
  • Page 29 Name 5VSB +3.3V -12V +12V Name +12V Name +12V Appendix B...
  • Page 30: Pci Routing Table

    B.2 PCI Routing Table Primary PCI Group PCI SLOT ID SEL PCI Interrupt Pin Route INTA INTB INTC INTD PPCI1 P_ AD31 INTB INTC INTD INTA PPCI2 P_ AD30 INTC INTD INTA INTB PPCI3 P_ AD29 INTD INTA INTB INTC Primary PCI Group PCI SLOT ID SEL...
  • Page 31 Keyboard Translator...
  • Page 32: Appendix C Keyboard Translator

    Appendix C Keyboard Translator C.1 Overview The keyboard translator is an interface that switches the signal from the membrane keypad to the standard AT keyboard. There are six connectors on the board. On top of the board, there are two connectors linking two flat cables to the membrane keypad (as shown in Fig.
  • Page 33: Programming The Front Panel Macro Keys

    Caution: Keyboard Translator(KBT-2002) can't be programmed through the USB keyboard. The step of programming the Macro Key(M1~M10) on the front panel: Open the front panel door, use a PS/2 keyboard connect to the reserved external keyboard terminal of KBT-2002 which on the back of front panel (see figure below).
  • Page 34 C.3 Keyboard Translator Maintenance (KBT-2002) Below is the procedure of replacing the keyboard translator while needed: Switch off the power, and detach the main power cord. Unscrew the screws on front panel and open the front panel door of IPPC-7158. The Keyboard Translator will be located on the back of the front panel, behind the mylar protect.
