4.2
Debug authentication trigger
Debug host must run in sequence the two actions depicted below:
1. Debug host uses SWD/JTAG with access point 0 to write 'STDA' character list within
DBGMCU_DBG_AUTH_HOST register.
2. Debug host resets the debug target (STM32H5).
After this sequence STM32H5 starts the debug authentication protocol.
AN6008 - Rev 1
AN6008
Debug authentication activation
page 11/25
