• The safety, operating and maintenance information
of the manufacturer, as well as the dimensions spec-
ified in the technical data, must be observed.
• The relevant accident prevention regulations and
the other generally accepted safety rules must be
observed.
• The saw is only intended for installation indoors.
• Workpieces that are smaller than the saw blade
guard can cause injuries to the hands and fingers.
Use a suitable aid!
• Avoid cramped hand positions when guiding the
workpiece and positions in which the hand would
slip directly into the saw blade.
• Always insert the saw blade so that the teeth point
down towards the saw table.
• Always set the correct blade tension in order to
avoid breaking the saw blades.
• Use extra care when cutting material with irregular
cutting profiles.
• When withdrawing the workpiece, teeth can get
caught in the kerf, especially if the shavings block
the kerf. In this case you should switch off the saw,
pull out the mains plug, open the kerf with a wedge
and remove the workpiece.
• Never leave the work station without setting down
the saw beforehand. Wait until the saw has come
to a standstill.
• Do not place, glue, or assemble any parts on the
work table while the saw is running.
• Do not switch on the saw until the work table is
cleared of material residues and tools. Only leave
the workpiece to be machined and any work aids
(wedges) on the workbench.
• Always wear eye protection.
• Keep fingers at a safe distance from the saw blade.
• Guide the workpiece securely and firmly and do not
let it loose at any point.
• Never leave the work station without setting down
the saw beforehand.
• Do not let your familiarity with the saw lead you to
carelessness. Carelessness can lead to serious in-
juries in a split second.
Keep these safety instructions in a safe place.

6. Technical data

Mains voltage
Power consumption
Stroke rate
Lifting movement
Dimensions L x W x H
Tilting table
Table size
Saw blade length approx.
(between both pins)
Saw arm swing
Cutting height max. at 90°
Cutting height max. at 45°
Protection category
Suction port ø
Weight
*Operating mode S1 (continuous operation)
The machine may be operated continuously with the
specified power.
** Operating mode S6, uninterrupted, periodic op-
eration.
The mode comprises of a start-up period, a time with
constant load and an idle time. The operating time is 10
mins, the duty cycle is 25% of the operating time.
Device emissions values
The noise values have been determined in accordance
with EN 62841-1:2015.
Wear hearing protection.
Excessive noise can result in a loss of hearing.
Sound pressure level L
Uncertainty K
Sound power level L
Uncertainty K
www.scheppach.com
120 W (S6 30%**)
400 - 1600 rpm
612 x 353 x 964 mm
0° to 45° to the left
250 x 415 mm
pA
pA
WA
WA
230 V~/50 Hz
70 W (S1*)
13 mm
1.27 mm
406 mm
48 mm
23 mm
IPX0
35 mm
15 kg
71, dB(A)
3 dB
84 dB(A)
3 dB
