ekwb EK-Loop PCI Bracket Pass-Through User Manual page 4

TECHNICAL SPECIFICATIONS AND MAIN PARTS
3
INSTALLING THE EK-Loop PCI Bracket Pass-Through
PC CHASSIS
SCREW
4
1
5
GPU
EXPANSION
SLOT
STEP 1
Position EAN
1 106837
2 106834
3 106832
2
4 106930
5 5192
STEP 1
First, remove one (1) GPU expansion slot from the PC Chassis. Save
the removed screw for later steps.
For this step, you will need:
Phillips Head Screwdriver
- 4 -
Description
Single slot bracket (Bl.)
Pass Trought nut (Ni)
Pass Through screw (Ni)
Rubber 5.5/8*1 NBR
OR 7 x 1.5 mm
Quantity
1
2
2
1
2
