Summary of Contents for ekwb EK-Velocity sTR4
- Page 1 EK-Velocity sTR4 CPU WATER BLOCK USER GUIDE 1st Revision, January 28th 2019...
- Page 2 The following instructions are subject to change without notice. Please visit our web site at www.ekwb.com for updates. Before installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
-
Page 3: Table Of Contents
TABLE OF CONTENT GENERAL INFORMATION ON WATER BLOCK COMPATIBILITY SUPPORT AND SERVICE WHAT IS ENCLOSED SOCIAL MEDIA QUICK INSTALLATION GUIDE INSTALLING THE WATER BLOCK CONNECTING THE RGB LED STRIP (for full nickel version) CONNECTING THE RGB LED STRIP CONNECTING THE D-RGB MODELS CONNECTING THE D-RGB LED STRIP - 3 -... -
Page 4: General Information On Water Block Compatibility
GENERAL INFORMATION ON WATER BLOCK COMPATIBILITY This CPU liquid cooling unit is pre-assembled for use with modern AMD desktop socket type motherboards. By default (out of the box) this water block supports the following CPU sockets: - AMD TR4 socket - AMD SP3 socket LED cover Water block top... -
Page 5: What Is Enclosed
WHAT IS ENCLOSED The following items are enclosed with each EK-Velocity water block: - EK-Velocity sTR4 CPU water block - Allen (hex) key 2.5mm - Allen (hex) key 2mm - EK-TIM Ectotherm 1g INSTALLING THE WATER BLOCK STEP 1 Cleaning the CPU: Wipe the CPU’s contact surface (by using non–... - Page 6 STEP 2 Align the water block over the mounting screws. Thumb nut Before proceeding with the installation It is mandatory to remove the protective foil from the backside of the water block. Coiled spring Place an enclosed compression spring and thumb nut over each M3,5 thumb screw.
-
Page 7: Connecting The Rgb Led Strip (For Full Nickel Version)
CONNECTING THE RGB LED STRIP (for full nickel version) CONNECTING THE RGB LED STRIP STEP 1 Plug the 4-pin connector from Water block’s and Fan’s RGB LED light to the RGB HEADER on the motherboard. The LED will work if the pin layout on the header is as follows: +12V G R B. -
Page 8: Connecting The D-Rgb Models
CONNECTING THE D-RGB MODELS CONNECTING THE D-RGB LED STRIP STEP 1 Plug the 4-pin connector from Water block’s D-RGB LED light to the DRGB HEADER on the motherboard. The LED will work if the pin layout on the header is as follows: +5V, Digital, empty, Ground. Please ensure that the arrow indicated on the connector is D-RGB Header plugged into the +5V line as indicated on your motherboard. -
Page 9: Support And Service
SUPPORT AND SERVICE For assistance please contact: http://support.ekwb.com/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
