- Page 3 CPU Water Block with AMD plate CPU Backplate mechanism CPU Wasserkühler mit AMD Verpackung CPU Backplate Montagehalterung Thermal compound - grease Radiator Wärmeleitpaste Radiator Lüfter Pump Pump/reservoir holders Reservoir Pumpe Pumpe/Tank Behälter Ausgleichsbehälter Compression fittings CPU mounting mechanism Coolant Klemmverschraubung CPU-Kühler Montagematerial Kühlmittel Tube...
-
Page 5: Step 2: Table Of Content
STEP 1: GENERAL INFORMATION ON PRODUCT STEP 2: TABLE OF CONTENT COMPATIBILITY This water block is pre-assembled for use with modern Intel desktop The following items are enclosed with each EK-Supremacy water socket type motherboards. By default this water block supports the block: following CPU sockets: EK-Supremacy universal CPU water block /w pre-installed... - Page 6 STEP 5: INSTALLING THE WATER BLOCK: STEP 5a: Intel LGA-1366 and AMD socket motherboard: STEP 5b: Intel LGA-115x socket motherboard: 1) Place motherboard on an even surface with front facing down. 1) Place motherboard on an even surface with front facing down. 2) Install backplate rubber gasket - depending on your CPU platform 2) Install backplate rubber gasket - depending on your CPU platform see STEP...
- Page 7 Open PC chassis and remove stock fans. Secure the motherboard by screwing in motherboard mounting Install the necassery spacers and install the motherboard. screws (provided with your PC chassis) Befestigen sie das Mainboard in dem sie die dafür Gehäuse öffnen und Original-Lüfter entfernen vorgesehenen Befestigungsschrauben anbringen (warden mit Ihrem Gehäuse mitgeliefert) Take the fans and put it on the radiator.
- Page 8 Install the fans and the radiator on the spot where normally air cooling Screw in all four M3x6 screws per fan into the threaded holes on the radiator fans take place. casing. Installieren Sie den Radiator sowie die benötigten Lüfter dort wo Befestigen Sie den Radiator mit jeweils vier M3x6-Schrauben pro Lüfter.
- Page 9 Your pump holder fits on any 120mm fan mounting holes. It is essential to Mount your pump on UNI pump holder with four M4x4 screws and PVC mount the pump below the reservoir height in your PC chassis in order to washers.
- Page 10 Attach 3.5’’ drive bay mounting adapter tray to the chassis using four Please observe the minimum height limitation when using 2.5” drive bay M3x6 screws as shown on the drawing above. mounting adapter tray. Befestigen Sie den Laufwerksschacht-Adapert anhand von vier M3x6- Sollten sie 2.5-Zoll-Laufwerkschächte verwenden, dann beachten Sie bitte die Schrauben, wie im Bild oben gezeigt.
- Page 11 Examine the water loop diagram Take a measure of required tubing length. Cut the tube on marked spot. Schauen Sie sich die Wasserkreislaufskitze Von Auge nachmessen, wie lange das Schlauch nach der entsprechenden Länge benötigte Schlauch-Stück sein soll. abschneiden. Install the compression fitting to both G1/4 Install the tube on fitting.
- Page 12 Take the cable with adaptors from the Connect pumps female 4-PIN connector to Connect 4-pin Molex female connector to male Molex pump delivery. male connector of the motherboard. connector of the power supply. Den 3-Pin Anschluss der Pumpe mit dem Kabeladapter aus dem Lieferumfang Schliessen Sie den weiblichen 4-Pin-Molex-Stecker entsprechenden Anschluss des Adapters...
- Page 13 Fill up the liquid while the pump is running Alternately turn off and on (cycle) power supply in Turn on the power supply and stop when the water level reaches 2 cm few second intervals to speed up air bleeding under the edge process.
- Page 14 Cover all exposed hardware with a towel or Unscrew one of the G1/4 fitting rings on the Gently pull the tube off the fitting and direct it into paper towels. Put a container under Reservoir. the container. reservoirs inlet and outlet ports. Alle Hardwareteile mit tüchern oder Ziehen Sie den Schlauch von der Tülle ab und legen G1/4"...
