The means for the fields of "MODBUS RTU" are:
If the field "RS232" is checked the serial line in use is the RS232, otherwise is the "RS485";
In the field "Baud rate" the velocity of the Modbus RTU is defined;
In the field "Parity" the Modbus RTU parity is defined;
"Timeout" is the maximum time that the device attends for the answer from the Slave interrogated;
In the field "RS485 Stop
If the field "Enable delay from last
written in the field below (expressed in ms).

PING DEVICE:

If it is necessary to do a Ping on the net, before pressing the
button.
Note:
In order to do this, the Converter must be in Normal Mode.
Warning:
Under Windows Vista, Seven and 8 you need Administrator Rights to use this command successfully.
bits" the number of Stop-Bit of Modbus RTU is defined;
receive" is checked the Converter, before send another Modbus RTU request, waits the time
"Ping
User Manual Modbus TCP Slave / Modbus Master
Document code: MN67508_ENG
Device" button insert a value in the field on the right and then press the
