PRODUCT STRUCTURE DIAGRAM
Light stand fixing
knob
ON/OFF/COOL Key
Display
Multifunctional coding
knob①: INT/SELECTOR/R
Multifunctional coding
knob②: CCT/HUE/G
Multifunctional coding
knob③: SAT/GM/B
ON/OFF
AC input
DC input
DMX input interface
DMX output interface
BACK
MODE
MENU
MODE
MENU
INT/SELECTOR/R CCT/HUE/G SAT/GM/B
ON 1+ 2-
OFF
5
Accessory lock
Locking screw handle
Harness storage rope
U Shaped bracket
BACK
ON/OFF
COOL
PUSH
DMX-IN DMX-OUT
