Pin number
A7
A8
A9
A10
A11
A12
USB ports
Port
1 x Type-B upstream
2 x Type-A downstream
1 x Type-A downstream
1 x Type-C downstream
Power charging port - the port with
capability if the device is BC1.2 compatible
NOTE: SuperSpeed USB 5 Gbps (USB 3.2 Gen 1) functionality requires a
SuperSpeed USB 5 Gbps (USB 3.2 Gen 1)-capable computer.
NOTE: The USB ports on the monitor work only when the monitor is
turned on or in Standby mode. If you turn off the monitor and then turn it
on, the attached devices may take a few seconds to resume normal
functionality.

Plug-and-Play capability

You can connect the monitor to any Plug-and-Play compatible computer. The
monitor automatically provides the computer with its Extended Display
Identification Data (EDID) using Display Data Channel (DDC) protocols so that
the computer can configure itself and optimize the monitor settings. Most
monitor installations are automatic; you can select different settings as required.
For more information about changing the monitor settings, see
monitor.
28 | About your monitor
Signal name
D-
SBU1
VBUS
RX2-
RX2+
GND
Pin number
B7
B8
B9
B10
B11
B12
Location
Rear
Rear
Bottom
Bottom
icon; supports up to 3 A fast-charging
Signal name
D-
SBU2
VBUS
RX1-
RX1+
GND
Operating the
