Fri-Jado GO Combi Mounting Instruction
How to mount the handshower
Hide thumbs
Also See for GO Combi:
- Service manual (38 pages) ,
- Diagnostics & faultfinding (24 pages) ,
- Mounting instruction (20 pages)
Related Manuals for Fri-Jado GO Combi
Summary of Contents for Fri-Jado GO Combi
- Page 1 GO Combi Mounting instruction How to mount the handshower EN (Original Instruction) Revision 12/2022, SW: 0.3.37...
- Page 2 GO Combi...
-
Page 3: Table Of Contents
Permissions ..................4 Safety information Before replacement Tools ..................... 6 Spare parts ..................6 Oven overview Mounting the handshower Mounting the holder for the handshower ........... 8 Mounting the handshower ..............9 GO Combi mounting instruction, revision 12/2022, SW: 0.3.37... -
Page 4: General Information
GO Combi General information The hand shower kit is designed to fit the Fri-Jado GO with water filters. If the handshower kit is to be mounted without a water filter or with a reverse osmosis system, you must contact your local plumber for installation. -
Page 5: Safety Information
All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified service technicians may result in injury to the operator and/or damage to the oven. GO Combi mounting instruction, revision 12/2022, SW: 0.3.37... -
Page 6: Before Replacement
GO Combi Before replacement • Make sure the required tools are available. • Unpack the spare parts and check if all parts are available. • Make sure the working area is tidied up, clean and safe to prevent personal injury and damage to the equipment. -
Page 7: Oven Overview
Inlet, solenoid valve (fi ltered water) Water fi lter system Inlet, solenoid valve (unfi ltered water) Water inlet hose, 1500 mm Fittings Ball valve Hose, 1500 mm Hose for handshower Hose, 1500 mm Table 1 GO Combi mounting instruction, revision 12/2022, SW: 0.3.37... -
Page 8: Mounting The Handshower
GO Combi Mounting the handshower Mounting the holder for the handshower Locate the two markings on the lower right-hand side of the oven. Drill two holes at the markings using a 3.3 mm drill. Thread the two holes as M4. -
Page 9: Mounting The Handshower
IMPORTANT! Make sure that you turn the holder correctly. Mounting the handshower Click the three hose clips into the oven base frame. Cut 50 mm of the hose for the hand shower. GO Combi mounting instruction, revision 12/2022, SW: 0.3.37... - Page 10 GO Combi Take apart the hoses and the T-fi ttings on the non-fi ltered side of the water fi lter. Use a fl at screw driver for the clips. Twist the blue plastic lock on the fi lter head and remove the T-fi tting.
- Page 11 GO Combi This page is intentionally left empty. GO Combi mounting instruction, revision 12/2022, SW: 0.3.37...
- Page 12 GO Combi Fri-Jado B.V. Fri-Jado France LLC Fri-Jado UK Ltd. Fri-Jado Inc. Blauwhekken 2 31 Parc du Golf – CS 90519 Ashley House 1401 Davey Road 4751 XD Oud Gastel 350 Avenue JRGG de la Lauzière Ashley Road UB8 2GA...
