  • Page 1 GO Combi Service manual Service manual GO Combi WARNING Read the instructions before using the machine. EN (Original Instruction) 9129351 / 2211...
  • Page 2 GO Combi...

  • Page 3: Table Of Contents

    GO Combi Table of contents General information Target group ..........................7 Technical changes ....................... 7 More documentation ......................7 Permissions ........................... 7 Screen dumps ........................... 7 Symbols used in this document ................8 Safety information General safety instructions ..................9 Safety instructions before use ................. 10 Safety instructions during use ...................11...
  • Page 4 GO Combi Displaying the test overlay function ..............19 Setting the oven setup .......................20 Adjusting the temperatures ...................21 Changing the temperature offsets ............... 22 Changing the recipes cooking settings ............23 Enabling the “Demo mode” function ..............23 Resetting the fault log ......................24 Updating software Updating software ......................25...
  • Page 5 GO Combi Technical data Water layout ..........................35 IO board LEDs ...........................37...
  • Page 6 GO Combi This page is intentionally left blank.

  • Page 7: General Information

    GO Combi General information Target group This document is aimed at service technicians who have been trained in installing and servicing the oven. The oven must only be installed and serviced by qualified service technicians. Technical changes This document is subject to changes without notice.

  • Page 8: Symbols Used In This Document

    GO Combi Symbols used in this document DANGER Dangerous situation which will, if not avoided, result in death or serious personal injury. WARNING Dangerous situation which may, if not avoided, result in death or serious personal injury. CAUTION Dangerous situation which will, if not avoided, result in minor or moderate personal injury.

  • Page 9: Safety Information

    GO Combi Safety information Read this document before using, installing or servicing the product. Installation and operation must comply with local regulations and accepted codes of good practice. All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified technicians may result in injury to the operator and/or damage to the oven.

  • Page 10: Safety Instructions Before Use

    GO Combi Safety instructions before use DANGER Risk of electric shock • Install an approved plug or safety switch close to the oven to ensure that the oven can be disconnected during installation and repair. • The safety switch must be compliant with applicable national and local requirements.

  • Page 11: Safety Instructions During Use

    GO Combi Safety instructions during use CAUTION Risk of crushing • Always close the door with one hand on the handle to avoid crushing you fingers. Safety instructions during maintenance and service DANGER Risk of electric shock • Disconnect the oven from the power source during service and when replacing spare parts.

  • Page 12: Setting The Oven

    GO Combi Setting the oven Accessing the settings menu Touch “Settings” in the home screen menu. Touch the locked icon. Touch the key icon. Enter the code for the access rights needed. User role Permissions Code “User” Access to the user menu.

  • Page 13: Testing The Oven

    GO Combi Testing the oven Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Oven test”. Touch “Main contactor”. Touch the buttons with the name of the function you want to test. Value Description “Door 1”...

  • Page 14: Testing The Fan Function

    GO Combi Testing the fan function Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Fan test”. Touch “Main contactor”. Touch the buttons with the name of the function you want to test. Value Description “RPM 1”...

  • Page 15: Testing The Carecycle Functions

    GO Combi Testing the CareCycle functions Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Water test”. Touch “Main contactor”. Touch the buttons with the name of the function you want to test. Value Description “Conductivity”...

  • Page 16: Testing The Alarm Functions

    GO Combi Testing the alarm functions Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Alarm test”. Touch “Main contactor”. Touch the buttons with the name of the function you want to test. Value Description “IO board”...

  • Page 17: Testing The Touch Display Function

    GO Combi Testing the touch display function Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Touch test”. Press a finger to the screen and drag it in any direction. If there are any dead spots in the touch display, you will see a delay or markings that are not related to the markings made by your finger.

  • Page 18: Testing The "Other Test" Function

    GO Combi Testing the “Other test” function Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “Other test”. Value Description “Core temperatures” Display the temperature of each of the three core probe sensors. “IO temp.”...

  • Page 19: Testing The Passtrough Function

    GO Combi Testing the PassTrough function Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Test functions”. Touch “PassThrough test”. Value Description “Displayed time” Shows the time that is displayed on the PassThrough display. “Restart button” Displays if the button on the PassThrough display has been pushed.

  • Page 20: Setting The Oven Setup

    GO Combi Setting the oven setup Touch “Settings” in the home screen menu. Touch “Oven setup”. Touch “Basics”. Value Description “Enter serial number” Enter the serial number of the oven, which you find on the rating plate on the oven.

  • Page 21: Adjusting The Temperatures

    GO Combi Adjusting the temperatures Touch “Settings” in the home screen menu. Touch “Cooking settings”. Touch “Temperature offset”. Touch “Probe”. Touch “Delta-T offset”. Select the preferred offset. Touch “Reset to default” to restore the factory settings on this page.

  • Page 22: Changing The Temperature Offsets

    GO Combi Changing the temperature offsets Touch “Settings” in the home screen menu. Touch “Cooking settings”. Touch “Temperature offsets”. Make the relevant changes. Value Description “Temperature offset” Set the temperature, which is added to the input value. “Core temp offset”...

  • Page 23: Changing The Recipes Cooking Settings

    GO Combi Changing the recipes cooking settings Touch “Settings” in the home screen menu. Touch “Cooking settings”. Touch “Recipes”. Make the relevant changes. Value Description “CookTimeCorrection” In this menu, you can do the following: (CTC) • Toggle the CookTimeCorrection on/off.

  • Page 24: Resetting The Fault Log

    GO Combi Resetting the fault log You can reset the fault log in case there is an active error, which is the case, if there is a warning icon in the upper right-hand side of the user interface. Touch the warning icon the home screen menu.

  • Page 25: Updating Software

    GO Combi Updating software Updating software The latest software version is available on our website. To update the software, you need a USB stick. Verifying the USB stick Before you download the latest software to the USB stick, make sure that the oven recognises the USB stick.

  • Page 26: Updating Software With Usb Stick

    GO Combi Updating software with USB stick Follow the instructions in “Verifying the USB stick” and “Downloading the software”. Insert a USB stick on the right-hand side of the oven. Touch “Settings” in the home screen menu. Log in as “Technician”. The password is 576021.

  • Page 27: Opening The Service Accesses

    GO Combi Opening the service accesses DANGER Risk of electric shock • Disconnect the oven from the power source during service and when replacing spare parts. • Make sure that the service technician can see that the power plug is disconnected at all times during maintenance and repair.

  • Page 28: Dismounting The Side Panel

    GO Combi Closening the front panel Lift the bottom of the front panel and place it. Hold the bottom of the front panel while pushing the top of the front panel in place. Check that the silicone protection plug is in place. Otherwise, insert a new one.

  • Page 29: Mounting The Side Panel

    GO Combi Mounting the side panel Fit the side panel in the two.hooks on the right-hand side. Position the side panel. Fasten the two screws beneath the oven.

  • Page 30: Replacing Parts

    GO Combi Replacing parts DANGER Risk of electric shock • Disconnect the oven from the power source during service and when replacing spare parts. • Make sure that the service technician can see that the power plug is disconnected at all times during maintenance and repair.

  • Page 31: Replacing The Io Board

    GO Combi Replacing the IO board Turn of the power to the oven. Open the front panel. See section “Opening the front panel”. Dismount all cables. Dismount the six clips and the screw. Replace the IO board. Follow the procedure in reverse order Replacing the controller Turn off the power to the oven.

  • Page 32: Replacing The Front Panel

    GO Combi Pinch the four white plastic screws to remove them. Replace the controller. Mount the three cables. Follow the procedure in reverse order. Replacing the front panel Turn off the power to the oven. Open the front panel. See section “Opening the front panel”.

  • Page 33: Replacing The Door Sensor

    GO Combi Replacing the door sensor Dismount the side panel. See section “Dismounting the side panel”. Disconnect the door sensor. Pull out and replace the door sensor. Tie a cord to the old door sensor cable and use it to drag in the new door sensor.
  • Page 34 GO Combi Remove the metal bracket. Pull out the cable. Dismount the cable. Dismount the LED fixture. Replace the LED fixture and cable. Follow the procedure in reverse order.
  • Page 35 GO Combi Technical data Water layout...
  • Page 36 GO Combi Position Description Oven cavity Valve Water to injection steam Drain CareCycle Clean and CareCycle Descale Valve Steam out of oven cavity Pump Washing of the oven cavity Conductivity sensor Water from washing pump Pump Emptying of drain Valve...
  • Page 37 GO Combi IO board LEDs Description and connection of the LEDs on the IO board, which gives an overview of the LEDs and their function. Description Power 3.3 V 5.0 V RS485 RX RS485 TX Cavity safety OK Table 14 Power 3.3 V...
  • Page 38 GO Combi Fri-Jado B.V. Fri-Jado France LLC Fri-Jado UK Ltd. Fri-Jado Inc. Blauwhekken 2 31 Parc du Golf – CS 90519 Ashley House 1401 Davey Road 4751 XD Oud Gastel 350 Avenue JRGG de la Lauzière Ashley Road UB8 2GA...
