GO Combi Table of contents General information Target group ..................5 Technical changes ................5 More documentation ................5 Warranty .................... 5 Permissions ..................5 Safety information Before replacement Tools ..................... 7 Spare parts ..................7 Estimated working time ..............7 Oven overview Stacking kit overview...
Page 4
GO Combi Mounting a Stacking oven Unpacking the ovens and Stacking kit ..........10 Preparing the roof on the bottom oven for Stacking ......10 Mounting the manifold assemblies for exhaust and drain ....11 Mounting the air intake manifold on the bottom oven ...... 13 Mounting the legs on top of the bottom oven ........
GO Combi General information Target group This document is aimed at service technicians who have been trained in installing and servicing the oven. The oven must only be installed and serviced by qualified service technicians. Technical changes This document is subject to changes without notice. More documentation You find more documentation about the oven at our website.
GO Combi Safety information Read this document before using, installing or servicing the product. Installation and operation must comply with local regulations and accepted codes of good practice. Read the safety instructions in the user manual, installation manual and service manual before you perform any work on the oven. All maintenance and repair must be carried out by qualified installation and service technicians only.
GO Combi Before replacement • Make sure the required tools are available. • Unpack the spare parts and check if all parts are available. • Make sure the working area is tidied up, clean and safe to prevent personal injury and damage to the equipment.
GO Combi Mounting a Stacking oven Unpacking the ovens and Stacking kit When transporting the oven, use a pallet lifter or other appropriate lifting equipment. DANGER Risk of squeezing • Never only lift the oven from the left-hand side. Leave the plastic film covering the oven surfaces until the oven is IMPORTANT! installed.
GO Combi Mounting the manifold assemblies for exhaust and drain Remove the lip sealing (1) from the exhaust pipe (2) on the bottom oven. Mount the bracket (3) on the roof of the bottom oven using two hexagon screws M5 L:12 (4). GO Combi mounting instruction, revision 08/2023, SW.
Page 12
GO Combi Place the manifold assembly for drain (4) on the exhaust pipe (5). Apply a silicone-based lubricant on the exhaust pipe to IMPORTANT! assure that the manifold assembly for drain easily slides onto the pipe. Fasten the manifold assembly for drain (4) to the bracket (6) using two hexagon screws M5 L:12 (7).
GO Combi Fasten the manifold assembly for exhaust (12) to the bracket (13) using two hexagon screws M5 L:12 (14). Mounting the air intake manifold on the bottom oven Mount the bracket (1) for the air intake pipe (2) using two hexagon screws M5 L12 (3) Mount the pipe (2) in the hole on the manifold assembly for exhaust (4).
GO Combi Mount the pipe (8) in the hole on the air intake manifold (9). Mounting the legs on top of the bottom oven Mount the leg (1) on the rearmost, left-hand side of the oven using four hexagon screws M5 L:12 (2).
Page 15
GO Combi Mount the leg (3) on the anterior, left-hand side of the oven using four hexagon screws M5 L:12 (4). GO Combi mounting instruction, revision 08/2023, SW. 0.7.1...
Page 16
GO Combi Mount the leg (5) on the rearmost, right-hand side using four hexagon screws M5 L:12 (6). Mount the leg (7) on the anterior, right-hand side using four hexagon screws M5 L:12 (8).
GO Combi Mounting the upper oven on the bottom oven Make sure to mount the stand on the bottom oven before you IMPORTANT! mount the upper oven on the bottom oven. Please refer to the mounting instruction “How to mount a stand”. Remove the four legs (1) from the upper oven.
GO Combi Lead the four Allen screws 10x25 (2) through the holes in the legs on the roof of the bottom oven. Fasten the screws in the holes, where the legs were mounted, on the upper oven. Mounting the pipes for exhaust and drain Place the plate for the exhaust and drain pipes (1) on the exhaust pipe (2).
Page 19
GO Combi Slide the exhaust pipe (3) through the hole of the plate (4) and place it in the manifold assembly for exhaust (5). GO Combi mounting instruction, revision 08/2023, SW. 0.7.1...
Page 20
GO Combi Slide the drain pipe (6) through the hole of the plate (7) and place it in the manifold assembly for drain (8). Place one end of the lower drain pipe (9) in the manifold for drain (10) Place the other end of the lower drain pipe (9) in the drain trap (11). Drill holes on the back plate of the bottom oven in the marked areas using a 4.2 drill and a M5 threaded tap.
GO Combi Mounting the cooling plate Push the cooling plate (1) in place below the air intake filter (2) of the upper oven. GO Combi mounting instruction, revision 08/2023, SW. 0.7.1...
GO Combi Connecting the upper and bottom oven to electricity Follow the instructions in the installation manual regarding how to connect the oven to electricity. Both the upper and bottom oven must be connected to electricity. Connecting the upper and bottom oven to the water supply Follow the instructions in the installation manual regarding how to connect the oven to the water supply.
GO Combi Testing the oven Follow the installation checklist to assure that the drain connection as well as the Stacking installation are tight. GO Combi mounting instruction, revision 08/2023, SW. 0.7.1...
Page 24
GO Combi Fri-Jado B.V. Fri-Jado France LLC Fri-Jado UK Ltd. Fri-Jado Inc. Blauwhekken 2 31 Parc du Golf – CS 90519 Ashley House 1401 Davey Road 4751 XD Oud Gastel 350 Avenue JRGG de la Lauzière Ashley Road UB8 2GA...
