Fri-Jado GO Combi Diagnostics & Faultfinding

Hide thumbs Also See for GO Combi:
Table of Contents

Advertisement

Quick Links

Download this manual
Faultfinding manual
GO Combi
!
WARNING
Read the instructions before using the machine.
EN (Original Instruction)
GO Combi
9129353 / 2211

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO Combi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fri-Jado GO Combi

Summary of Contents for Fri-Jado GO Combi

  • Page 1 GO Combi Faultfinding manual GO Combi WARNING Read the instructions before using the machine. EN (Original Instruction) 9129353 / 2211...
  • Page 2 GO Combi KEEP THIS USER MANUAL FOR FUTURE USE © 2023 Fri-jado B.V. , Oud Gastel, The Netherlands. We advise you to contact your supplier for the guarantee period and conditions. Further we refer to our General Terms and Conditions for Sales and Delivery that are available upon request.

  • Page 3: Table Of Contents

    GO Combi Table of contents General information Target group ..................3 Technical changes ................3 More documentation ............... 3 Permissions ..................3 Safety information Using the faultfinding table Accessing the test functions ............5 Overview of error codes Faultfinding list...

  • Page 4: General Information

    GO Combi General information Target group Target Description group The information that is listed next to this symbol is aimed at the end user of the oven. We recommend that you follow the instructions before you contact your local service partner as, in many cases, you will be able to solve the error yourself.

  • Page 5: Safety Information

    GO Combi Safety information Read this document before using, installing or servicing the product. Installation and operation must comply with local regulations and accepted codes of good practice. Read the safety instructions in the user manual, installation manual and service manual before you perform any work on the oven.

  • Page 6: Accessing The Test Functions

    GO Combi Accessing the test functions 1. Log in as “Technician” (576021). 2. Touch “Settings”. 3. Touch “Oven setup”. 4. Touch “Test functions”. 5. Touch the relevant test function. In each of the error messages in this document, it is described which test function to use to solve the error.

  • Page 7: Overview Of Error Codes

    GO Combi Overview of error codes Error Fault Page “The oven is too hot” “The oven temperature sensor is defective” “The core probe is not connected” “The fan is too slow” “The IO board is too hot” “No communication between the controller and the IO board”...

  • Page 8: Faultfinding List

    GO Combi Faultfinding list Error Fault Cause User Remedy The oven is too hot The oven thermo switch 1. Contact your local service partner. has tripped, because the cavity temperature is above 1. Open the front panel and press the green 350°C.

  • Page 9: "The Core Probe Is Not Connected

    GO Combi Error Fault Cause User Remedy The core probe is A recipe using core 1. Select a recipe without core probe. not connected temperature has been 2. If the error persists, contact your local selected, but no core probe service partner.

  • Page 10: 16 "The Io Board Is Too Hot

    GO Combi Error Fault Cause User Remedy The IO board is too The internal temperature on 1. Clean the air intake filter. the IO board is too high. 2. Restart the oven in the “Settings” menu and wait for five minutes before using the oven again.

  • Page 11: 21 "No Communi-Cation Between The Controller And Server

    GO Combi Error Fault Cause User Remedy No communi- There is no connection 1. Restart the oven. cation between between the controller and 2. Check the internet connection. the controller and server. 3. If the error persists, contact your local server service partner.

  • Page 12: 27 "Combisense Calibration Error

    GO Combi Error Fault Cause User Remedy CombiSense Unable to finish calibration 1. Make sure the water is turned on. calibration error and cool down took too 2. Make sure the door is closed. long. 3. Recalibrate CombiSense. 4. If the error persists, contact your local service partner.

  • Page 13: 29 "Door Sensor Error

    GO Combi Error Fault Cause User Remedy Door sensor error The door sensor does not 1. Go to “Door calibration” in the receive valid values. The “Calibration” menu to check the NOTE! You can oven does not stop working information about the error.

  • Page 14: 31 "Sensor Error

    GO Combi Error Fault Cause User Remedy Sensor error The humidity sensor is not 1. Contact your local service partner. reading valid values 1. Go to the “Settings” menu and restart the oven. 2. Go to “Other tests” in the “Test functions”...

  • Page 15: 40 "The Io Board Is Too Hot

    GO Combi Error Fault Cause User Remedy The IO board is too This is a notification not an 1. Clean the air intake filter. error. 2. Make sure there is no heat sources near The internal temperature on the air intake filter.

  • Page 16: 44 "Exhaust Error

    GO Combi Error Fault Cause User Remedy Exhaust error An error occurs when 1. Make sure nothing blocks the exhaust opening and closing the valve. exhaust valve. 2. Go to the “Settings” menu and restart the oven. 3. Contact your local service partner.

  • Page 17: 72 "Fan I - No Communication

    GO Combi Error Fault Cause User Remedy Fan I - no The IO board cannot 1. Go to the “Settings” menu and restart communication communicate with the fan the oven. motor. 2. If the error persists, contact your local service partner.

  • Page 18: 81 "Forced Wash Is Needed

    GO Combi Error Fault Cause User Remedy Forced wash is Forced wash is needed. 1. Run a CareCycle programme immediately. needed IMPORTANT: You cannot use the oven until the oven has run one of the CareCycle programmes. HydroShield water This is a notification.

  • Page 19: 86 "User Ignored To Change The Hydroshield Water Filter

    GO Combi Error Fault Cause User Remedy User ignored The user did not replace the 1. If you ignore to replace the HydroShield to change the HydroShield water filter. water filter, you risk limescale in your HydroShield water oven, which may dam age the oven.

  • Page 20: Pt1000 Temperature Sensor Table

    GO Combi Error Fault Cause User Remedy Invalid The main voltage or 1. Contact your local service partner. configuration frequency has not been configured. 1. Go to “Heating” in the “Oven setup” This error only appears in menu. Find heating and set the power cases where the controller supply to the specifications of the oven.

  • Page 21: Oven Overview

    GO Combi Oven overview Position Description IO board Thermo switch, oven Air intake filter Table 2...
  • Page 22 GO Combi Position Description Ethernet connection Electrical connection Water inlet (HydroShield water filter or reverse osmosis) Water inlet Drain outlet USB access Table 3...
  • Page 23 GO Combi Position Description Exhaust from drain Air intake Table 4...
  • Page 24 GO Combi Fri-Jado B.V. Fri-Jado France LLC Fri-Jado France LLC Fri-Jado UK Ltd. Fri-Jado Inc. Blauwhekken 2 31 Parc du Golf – CS 90519 31 Parc du Golf – CS 90519 Ashley House 1401 Davey Road 4751 XD Oud Gastel 350 Avenue JRGG de la Lauzière...
