GO Combi
Mounting instruction
How to mount a stand
EN (Original Instruction)
Revision 08/2023, SW: 0.7.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GO Combi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fri-Jado GO Combi

Summary of Contents for Fri-Jado GO Combi

  • Page 1 GO Combi Mounting instruction How to mount a stand EN (Original Instruction) Revision 08/2023, SW: 0.7.1...
  • Page 2 GO Combi...

  • Page 3: Table Of Contents

    Mounting the supports ............... 9 Mounting the oven on a stand ............10 Mounting a oven with fat separation on a stand ....... 13 Mounting HydroShield water filter on the stand ........ 14 Different stand models GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...

  • Page 4: General Information

    GO Combi General information Target group This document is aimed at service technicians who have been trained in installing and servicing the oven. The oven must only be installed and serviced by qualified service technicians. Technical changes This document is subject to changes without notice.

  • Page 5: Safety Information

    All maintenance and repair must be carried out by qualified installation and service technicians only. Installation and/or service by others than qualified service technicians may result in injury to the operator and/or damage to the oven. GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...

  • Page 6: Before Replacement

    GO Combi Before replacement • Make sure the required tools are available. • Unpack the spare parts and check if all parts are available • Make sure the working area is tidied up, clean and safe to prevent personal injury and damage to the equipment.

  • Page 7: Stand Overview

    GO Combi Stand overview Basic stand Stand for table and Stackit GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...

  • Page 8: Mounting The Stand

    GO Combi Mounting the stand Assembling the frame Place the two parts of the frame on a flat surface with the bottom pointing upwards. Push the tow parts of the frame together Fasten the two M5x10 screws on each side using a slotted screwdriver.

  • Page 9: Mounting The Legs On A Stackit And Table Stand

    Fasten the two supports (A) on the right-hand and left-hand side with the FRH M5x12 screws using a flexible socket screwdriver. Fasten the two supports (B) in the front and back in the same way as above. GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...

  • Page 10: Mounting The Oven On A Stand

    GO Combi Mounting the oven on a stand In case of a Stacking kit solution, always mount the bottom oven on the stand before mounting the upper oven on the bottom oven. Detach the hose for the drip tray. If the oven is a table model, remove the four legs from the oven.
  • Page 11 The illustration below shows how to mount the oven on a standard stand. The procedure is the same for mounting a stand on a table or Stacking model. Fasten the two M5x10 screw on both the right-hand and left-hand side of the oven. GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...
  • Page 12 GO Combi Attach the hose for the drip tray.

  • Page 13: Mounting A Oven With Fat Separation On A Stand

    Fasten the oven to the stand using 4 x hex screws and 4 x washers as well as 2 x M5x10 screws. Follow step 5 and 6 in section “Mounting the oven on a stand”. GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...

  • Page 14: Mounting Hydroshield Water Filter On The Stand

    Mounting water fi lter on the stand Not roll-in and Stacking kit. The water fi lter can be mounted on the oven stands for the following oven types: • Fri-Jado GO 6-1/1 GN • Fri-Jado GO 10-1/1 GN • Fri-Jado GO 6-2/1 GN •...
  • Page 15 GO Combi Remove the side plate. Fasten the brack beneath the oven. Use two M5 screws. GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...
  • Page 16 GO Combi Slide the fi lter head into the bracket. Mount the fi lter on the fi lter head by turning the fi lter counterclockwise into the fi lter head. Connect the hoses according to the section “Connecting the oven to a Water...

  • Page 17: Different Stand Models

    You can buy different accessories to the basic stand. The table below shows the different possibilities as well as which pre-drilled holes to use when mounting the racks. Type of rack Position of pre-drilled hole 1/1 GN 2/1 GN GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...
  • Page 18 GO Combi Type of rack Position of pre-drilled hole 400x600 EN US sheet...
  • Page 19 GO Combi Type of rack Position of pre-drilled hole Cabinet Castors Floor mounting feet Rack support locking system Updated section Rack support locking system Table 1 GO Combi mounting instruction, revision 08/2023, SW: 0.7.1...
  • Page 20 GO Combi Fri-Jado B.V. Fri-Jado France LLC Fri-Jado UK Ltd. Fri-Jado Inc. Blauwhekken 2 31 Parc du Golf – CS 90519 Ashley House 1401 Davey Road 4751 XD Oud Gastel 350 Avenue JRGG de la Lauzière Ashley Road UB8 2GA...
