UniStream® Uni-I/O™ Modules
This guide provides specifications for Unitronics' Uni-I/O™ modules UIS-04PTN and UIS-04PTKN.
Those modules comprise:
• 4 RTD inputs
Uni-I/O modules are compatible with UniStream® family of Programmable Logic Controllers. They
may be either snapped onto the back of a UniStream® HMI Panel next to a CPU-for-Panel to create
an all-in-one HMI + PLC controller, or installed on a standard DIN Rail using a Local Expansion
Adapter.
Installation Guides are available in the Unitronics Technical Library at
RTD Inputs
Number of inputs
UIS-04PTN input range
Unitronics
4
Input Type Nominal Values
(1)
PT100 -200°C ≤ T ≤ 850°C
0.00385 (-328°F ≤ T ≤ 1,562°F)
0.00392
0.00391
NI100 -100°C ≤ T ≤ 260°C
0.00618 (-148°F ≤ T ≤ 500°F)
NI100 -60°C ≤ T ≤ 180°C
0.00617 (-76°F ≤ T ≤ 356°F)
NI120 -80°C ≤ T ≤ 260°C
0.00672 (-112°F ≤ T ≤ 500°F)
Resistance 0Ω ≤ R ≤ 390Ω
* Overrflow or Underflow
the Over-range or Under-range boundaries respectively.
Technical Specifications
UIS-04PTN, UIS-04PTKN
www.unitronicsplc.com
Over/Under-range Values *
Under-range:
-220°C ≤ T < -200°C
(-364°F ≤ T < -328°F)
Over-range:
850°C < T ≤ 860°C
(1,562°F < T ≤ 1,580°F)
Under-range:
-150°C ≤ T < -100°C
(-238°F ≤ T < -148°F)
Over-range:
260°C < T ≤ 270°C
(500°F < T ≤ 518°F)
Under-range:
-104°C ≤ T < -60°C
-155.2°F ≤ T < -76°F)
Over-range:
180°C < T ≤ 210°C
(356°F < T ≤ 410°F)
Under-range:
-130°C ≤ T < -80°C
(-202°F ≤ T < -112°F)
Over-range:
260°C < T ≤ 270°C
(500°F < T ≤ 518°F)
390Ω < R ≤ 395.85Ω
is declared when an input value exceeds
(11)
