Unitronics UIS-04PTN User Manual page 10

Cable
Diagnostics (11) (5)
IO/COM Bus
Bus current consumption
LED Indications
Input LEDs
Status LED
Environmental
Protection
Operating
temperature
Storage temperature
Relative Humidity
(RH)
Operating altitude
Shock
Vibration
Unitronics
Shielded, see installation guide for details
Input Overflow or Underflow, sensor connection fault
90mA maximum
Red
On: Input value is in Overflow, Underflow, or a connection
fault occurs
A triple color LED. Indications are as follows:
Color LED State
On
Green
Slow blink
Rapid blink
Green/Red Slow blink
Slow blink
Red
Rapid blink
Orange Rapid Blink
IP20, NEMA1
-20°C to 55°C (-4°F to 131°F)
-30°C to 70°C (-22°F to 158°F)
5% to 95% (non-condensing)
2,000 m (6,562 ft)
IEC 60068-2-27, 15G, 11ms duration
IEC 60068-2-6, 5Hz to 8.4Hz, 3.5mm constant amplitude, 8.4Hz to 150Hz,
1G acceleration
UniStream™
(6) (7)
Status
Operating normally
Boot
OS initialization
Configuration mismatch
No IO exchange
Communication error
OS Upgrade
