Wiring diagram without OEM Remote Start
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Gateway Module
(black connector on OBDII connector)
1
4
Trunk Release
(black or brown connector
at trunk release switch)
6 933.FORD11 2.07.198.12 2013 Ford Fusion
©2023 Directed. All rights
with T-Harness (THFON2 Rev. 2)
THFON2 Rev. 2 (Optional T-Harness)
Refer to the optional starter
disable connection section for
relay and connection details.
2 3
5 6
(-) Trunk Release:
Gray/Yellow, pin 6
Headlight Switch
4-pin Connectors
Type 1
Type 2
NOT USED
(-) Ground When Armed (GWA) Output: Blue/White: 2
(-) Trunk Release Output: Red/White: 4
Hood Pin
Siren
A module can also be used for
8-pin White Connector
this installation.
(+) Siren Output: Brown/Red: 11
(-) Hood Input: Gray: 21
IMPORTANT:
Position the
fuses correctly!
12-pin Black Connector
Slide to open
Legend:
).
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
