Directed DIRECTECHS DS3+ Installation Manual page 14

Module
Conn./Pin Color Description
H4/6 Green Starter Disable (key side)
H4/7 Violet (+) Starter Output (vehicle side)
H4/8 Orange (+) Accessory Output
H4/9 Red/White (+) 12 Volt Input
H4/10 Pink (+) Ignition Input/Output
RF Port harness, 2-pin white connector (H5)
Module
Conn./Pin
H5/1
H5/2
D2D harness, 4-pin white (1) and black (2) connectors (H6)
Module
Conn./Pin
H6/1
H6/2
H6/3
H6/4
Temperature sensor harness, 2-pin black connector (H7)
Module
Conn./Pin Color Description
H7/1 Black Temperature Sensor
H7/2 Black Temperature Sensor
14 933.FORD11 2.07.198.12 2013 Ford Fusion
©2023 Directed. All rights
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
Color
N/A
N/A
Color
Blue
Black
Green
Red
Connects To
Wire Location
(+/-) Wire Color
Description
RF Loop
RF Loop
Description
(Data) TX
(-) Ground
(Data) RX
(+) 12 Volt
(+/-) Wire Color
Connection
Connection
