Crestron Adagio™ AAE

Audio Expander: Adagio AAE

Introduction

Operations Guide – DOC. 6460A

Features and Functions

•
High performance audio distribution, multi-channel amplifier
•
Out-of-the-box functionality (no programming required) if used with
the Adagio Entertainment System
•
Multi-room audio routing for up to six amplified room outputs from as
many of 10 stereo sources
•
Independent software-driven room select, room on-off, volume, bass,
treble, balance, loudness, stereo/mono and mute controls available on
every room output
•
12 channel power amplifier
•
45 watts per channel supports up to six pairs of speakers
•
Compatible with any Crestron 2-Series control system
•
Six powered built-in Cresnet
•
LOOP-THRUs for connection to Adagio control unit or 2-Series
control system and additional AAE units
•
Available in both domestic (AAE) and international (AAEI) versions

Applications

The following diagram shows how an Adagio home entertainment system, using out-
of-the-box functionality, might be configured to include the Adagio AAE Audio
Expander.
Adagio System Showing the AAE in a Typical Application
Audio Expander
®
ports
Audio Expander: Adagio AAE • 1
